Paper Reinforced Phenolic Laminate Tubes - 3/16" Wall

Paper Phenolic Tubes .187 Inch Wall

NEMA grades X, XX and XXX Paper Reinforced Phenolic has a typical natural color of light tan to brown. These grades are composed of a paper base impregnated with a phenolic resin binder. Phenolics are the oldest, best-known general purpose thermoset resins. They are among the lowest in cost and easiest to process. Phenolics are quite adequate for a fair percentage of electrical applications. Generally speaking, they are not equivalent to epoxies in resistance to moisture, humidity, dimensional stability, shrinkage and retention of electrical properties in extreme environments. The paper reinforced phenolic has good electric strength properties with fair mechanical strength and are outstanding as template material or back-up material.

NEMA X certs to MIL-I-24768/12 PBM, IEC 60893-3 Type 4 PF CP 201
NEMA XX certs to MIL-I-24768/11 PBG, IEC 60893-3 Type 4 PF CP 203
NEMA XXX certs to MIL-I-24768/10 PBE, IEC 60893-3 Type 4 PF CP 201
Tube Tolerances  •  Technical Data Sheet  •  Chemical Resistance Chart

Tubes are manufactured in random lengths from 30" to 36".
Our pricing and minimum orders are based on the 36".

Tubes can also be produced in 42" to 48" random lengths for the same per-foot price.
Measured lengths of 36"±1" and 48"±1" are also available (call for pricing)

Paper Phenolic Tubes .187" Wall Thickness
Part # OD (in.) ID (in.) Minimum to Order Price Per Foot Order Online
KM-1159 .563 .187 36 Feet $28.68 Add to Order
KM-1163 .625 .250 36 Feet $29.80 Add to Order
KM-23050 .813 .437 30 Feet $35.80 Add to Order
KM-1883 .875 .500 27 Feet $38.22 Add to Order
KM-1888 .938 .562 27 Feet $40.68 Add to Order
KM-1894 1.000 .625 24 Feet $43.10 Add to Order
KM-22999 1.062 .687 24 Feet $45.53 Add to Order
KM-1903 1.125 .750 21 Feet $47.98 Add to Order
KM-22997BQ 1.187 .812 21 Feet $50.40 Add to Order
KM-1909 1.250 .875 21 Feet $52.85 Add to Order
KM-22995BQ 1.312 .937 21 Feet $55.28 Add to Order
KM-1915 1.375 1.000 18 Feet $57.70 Add to Order
KM-22301 1.500 1.125 18 Feet $62.58 Add to Order
KM-22991 1.562 1.187 18 Feet $65.00 Add to Order
KM-1919 1.625 1.250 15 Feet $74.20 Add to Order
KM-22989Q 1.688 1.312 15 Feet $76.88 Add to Order
KM-22988BQ 1.750 1.375 15 Feet $79.57 Add to Order
KM-22987 1.812 1.437 15 Feet $82.23 Add to Order
KM-1205 1.875 1.500 12 Feet $84.93 Add to Order
KM-22992BQ 1.937 1.562 12 Feet $87.58 Add to Order
KM-22994 2.000 1.625 12 Feet $90.28 Add to Order
KM-22317 2.062 1.687 12 Feet $92.93 Add to Order
KM-22316 2.125 1.750 12 Feet $95.63 Add to Order
KM-22315 2.188 1.812 12 Feet $98.30 Add to Order
KM-22314 2.250 1.875 12 Feet $101.00 Add to Order
KM-22313 2.312 1.937 12 Feet $103.65 Add to Order
KM-22312 2.375 2.000 12 Feet $106.35 Add to Order
KM-22310Q 2.500 2.125 9 Feet $111.70 Add to Order
KM-22318 2.562 2.187 9 Feet $114.38 Add to Order
KM-22308 2.625 2.250 9 Feet $117.07 Add to Order
KM-22307 2.688 2.312 9 Feet $119.73 Add to Order
KM-22306Q 2.750 2.375 9 Feet $122.43 Add to Order
KM-22305 2.812 2.437 9 Feet $125.08 Add to Order
KM-22304 2.875 2.500 9 Feet $127.78 Add to Order
KM-22303 2.937 2.562 9 Feet $130.45 Add to Order
KM-22977BQ 3.000 2.625 9 Feet $133.15 Add to Order
KM-22952BQ 3.062 2.687 9 Feet $135.80 Add to Order
KM-22986 3.125 2.750 9 Feet $138.50 Add to Order
KM-22965 3.188 2.812 9 Feet $141.15 Add to Order
KM-22964BQ 3.250 2.875 9 Feet $143.85 Add to Order
KM-22963BQ 3.312 2.937 9 Feet $146.50 Add to Order
KM-22962BQ 3.375 3.000 9 Feet $149.20 Add to Order
KM-22961BQ 3.437 3.062 9 Feet $151.88 Add to Order
KM-22951BQ 3.500 3.125 9 Feet $154.58 Add to Order
KM-22959 3.562 3.187 9 Feet $157.23 Add to Order
KM-22967 3.625 3.250 9 Feet $159.93 Add to Order
KM-22957BQ 3.687 3.312 9 Feet $162.58 Add to Order
KM-22956BQ 3.750 3.375 9 Feet $165.28 Add to Order
KM-22955 3.812 3.437 6 Feet $167.95 Add to Order
KM-22954 3.875 3.500 6 Feet $170.65 Add to Order
KM-22953 3.937 3.562 6 Feet $173.30 Add to Order
KM-22975BQ 4.000 3.625 6 Feet $176.00 Add to Order
KM-22958BQ 4.062 3.687 6 Feet $178.65 Add to Order
KM-22960BQ 4.125 3.750 6 Feet $181.35 Add to Order
KM-22983 4.187 3.812 6 Feet $184.03 Add to Order
KM-22982 4.250 3.875 6 Feet $186.73 Add to Order
KM-22981 4.312 3.937 6 Feet $189.38 Add to Order
KM-22980BV 4.375 4.000 6 Feet $192.08 Add to Order
KM-22979 4.437 4.062 6 Feet $194.73 Add to Order
KM-22978BQ 4.500 4.125 6 Feet $197.43 Add to Order
KM-22968BQ 4.562 4.187 6 Feet $200.08 Add to Order
KM-22976BQ 4.625 4.250 6 Feet $202.78 Add to Order
KM-22984BQ 4.687 4.312 6 Feet $205.45 Add to Order
KM-22974 4.750 4.375 6 Feet $208.15 Add to Order
KM-22973BQ 4.812 4.438 6 Feet $210.80 Add to Order
KM-22972BQ 4.875 4.500 6 Feet $213.50 Add to Order
KM-22971BQ 4.937 4.562 6 Feet $216.15 Add to Order
KM-22970 5.000 4.625 6 Feet $218.85 Add to Order
KM-22334 5.062 4.687 6 Feet $221.53 Add to Order
KM-22966BQ 5.125 4.750 6 Feet $224.23 Add to Order
KM-22311 5.187 4.812 6 Feet $226.88 Add to Order
KM-22368 5.250 4.875 6 Feet $229.58 Add to Order
KM-22367Q 5.312 4.937 6 Feet $232.23 Add to Order
KM-22366 5.375 5.000 6 Feet $234.93 Add to Order
KM-22365 5.437 5.062 6 Feet $237.60 Add to Order
KM-22364 5.500 5.125 6 Feet $240.30 Add to Order
KM-22363 5.562 5.187 6 Feet $242.95 Add to Order
KM-19648 5.625 5.250 6 Feet $245.65 Add to Order
KM-22353 5.688 5.313 6 Feet $248.30 Add to Order
KM-5416R 5.750 5.375 6 Feet $251.00 Add to Order
KM-22369 5.812 5.437 6 Feet $253.65 Add to Order
KM-22359 5.875 5.500 6 Feet $256.35 Add to Order
KM-22358 5.938 5.562 6 Feet $259.03 Add to Order
KM-22357 6.000 5.625 6 Feet $261.73 Add to Order
KM-22356Q 6.063 5.687 6 Feet $264.38 Add to Order
KM-22355 6.125 5.750 6 Feet $267.08 Add to Order
KM-22377 6.187 5.812 6 Feet $269.73 Add to Order
KM-22360 6.250 5.875 6 Feet $272.43 Add to Order
KM-22362 6.312 5.937 6 Feet $275.10 Add to Order
KM-22385 6.375 6.000 6 Feet $277.80 Add to Order
KM-22384 6.437 6.062 6 Feet $249.68 Add to Order
KM-22383 6.500 6.125 6 Feet $252.20 Add to Order
KM-22382Q 6.562 6.187 6 Feet $254.68 Add to Order
KM-22381 6.625 6.250 6 Feet $257.20 Add to Order
KM-22380Q 6.688 6.312 6 Feet $259.68 Add to Order
KM-22370 6.750 6.375 6 Feet $262.20 Add to Order
KM-22378 6.812 6.437 6 Feet $264.68 Add to Order
KM-22376Q 6.938 6.562 6 Feet $269.65 Add to Order
KM-22375 7.000 6.625 6 Feet $272.18 Add to Order
KM-22374 7.062 6.687 6 Feet $274.65 Add to Order
KM-22373 7.125 6.750 6 Feet $277.18 Add to Order
KM-22372 7.187 6.812 6 Feet $279.65 Add to Order
KM-22371 7.250 6.875 6 Feet $282.18 Add to Order
KM-22345Q 7.312 6.938 6 Feet $284.65 Add to Order
KM-22320 7.375 7.000 6 Feet $287.15 Add to Order
KM-22354 7.437 7.062 6 Feet $289.63 Add to Order
KM-22333Q 7.500 7.125 6 Feet $292.15 Add to Order
KM-22332Q 7.562 7.187 6 Feet $294.63 Add to Order
KM-22331 7.625 7.250 6 Feet $297.15 Add to Order
KM-22330 7.688 7.312 6 Feet $299.63 Add to Order
KM-22329 7.750 7.375 6 Feet $302.15 Add to Order
KM-22319 7.812 7.437 6 Feet $304.63 Add to Order
KM-22327Q 7.875 7.500 6 Feet $307.13 Add to Order
KM-22335 7.938 7.562 6 Feet $309.60 Add to Order
KM-22325 8.000 7.625 6 Feet $312.13 Add to Order
KM-22324 8.062 7.687 6 Feet $314.60 Add to Order
KM-22323 8.125 7.750 6 Feet $317.13 Add to Order
KM-22322 8.188 7.812 6 Feet $319.60 Add to Order
KM-22321 8.250 7.875 6 Feet $322.13 Add to Order
KM-22343Q 8.312 7.937 6 Feet $324.60 Add to Order
KM-22326 8.375 8.000 6 Feet $327.10 Add to Order
KM-22328 8.437 8.062 6 Feet $329.58 Add to Order
KM-22351 8.500 8.125 6 Feet $332.10 Add to Order
KM-22350 8.562 8.187 3 Feet $334.58 Add to Order
KM-22349 8.625 8.250 3 Feet $337.10 Add to Order
KM-22348 8.688 8.312 3 Feet $339.58 Add to Order
KM-22347 8.750 8.375 3 Feet $342.10 Add to Order
KM-22346 8.812 8.437 3 Feet $344.58 Add to Order
KM-22336Q 8.875 8.500 3 Feet $347.08 Add to Order
KM-22344Q 8.938 8.562 3 Feet $349.58 Add to Order
KM-22352 9.000 8.625 3 Feet $352.08 Add to Order
KM-22342Q 9.062 8.687 3 Feet $354.55 Add to Order
KM-22341 9.125 8.750 3 Feet $357.08 Add to Order
KM-22340Q 9.188 8.812 3 Feet $359.55 Add to Order
KM-22339TS 9.250 8.875 3 Feet $362.08 Add to Order
KM-22338Q 9.312 8.937 3 Feet $364.55 Add to Order
KM-22542Q 9.375 9.000 3 Feet $367.08 Add to Order
KM-22969 9.437 9.062 3 Feet $369.55 Add to Order
KM-22473Q 9.500 9.125 3 Feet $372.05 Add to Order
KM-22709 9.563 9.187 3 Feet $374.53 Add to Order
KM-22708 9.625 9.250 3 Feet $377.05 Add to Order
KM-22707BQ 9.688 9.312 3 Feet $379.53 Add to Order
KM-22706BQ 9.750 9.375 3 Feet $382.05 Add to Order
KM-22705BQ 9.812 9.437 3 Feet $384.53 Add to Order
KM-22704BQ 9.875 9.500 3 Feet $387.05 Add to Order
KM-22694 9.937 9.562 3 Feet $389.53 Add to Order
KM-22702 10.000 9.625 3 Feet $392.03 Add to Order
KM-22710 10.062 9.687 3 Feet $394.50 Add to Order
KM-22700BQ 10.125 9.750 3 Feet $397.03 Add to Order
KM-22699BQ 10.187 9.813 3 Feet $399.50 Add to Order
KM-22698BQ 10.250 9.875 3 Feet $402.03 Add to Order
KM-22697 10.313 9.937 3 Feet $404.50 Add to Order
KM-22696BQ 10.375 10.000 3 Feet $407.03 Add to Order
KM-22718 10.437 10.062 3 Feet $409.50 Add to Order
KM-22701 10.500 10.125 3 Feet $412.00 Add to Order
KM-22703 10.563 10.187 3 Feet $414.47 Add to Order
KM-22726BQ 10.625 10.250 3 Feet $417.00 Add to Order
KM-22725BQ 10.688 10.312 3 Feet $419.47 Add to Order
KM-22724 10.750 10.375 3 Feet $422.00 Add to Order
KM-22723 10.813 10.437 3 Feet $424.47 Add to Order
KM-22722BQ 10.875 10.500 3 Feet $427.00 Add to Order
KM-22721BQ 10.937 10.562 3 Feet $429.47 Add to Order
KM-22711BQ 11.000 10.625 3 Feet $431.97 Add to Order
KM-22719BQ 11.062 10.687 3 Feet $434.47 Add to Order
KM-22727 11.125 10.750 3 Feet $436.97 Add to Order
KM-22717 11.188 10.812 3 Feet $439.45 Add to Order
KM-22716BQ 11.250 10.875 3 Feet $441.97 Add to Order
KM-22715 11.313 10.937 3 Feet $444.45 Add to Order
KM-22714 11.375 11.000 3 Feet $446.97 Add to Order
KM-22713BQ 11.437 11.062 3 Feet $449.45 Add to Order
KM-22712 11.500 11.125 3 Feet $451.95 Add to Order
KM-23036 11.562 11.187 3 Feet $454.45 Add to Order
KM-22686 11.625 11.250 3 Feet $456.95 Add to Order
KM-22661 11.687 11.312 3 Feet $459.43 Add to Order
KM-22695BQ 11.750 11.375 3 Feet $461.95 Add to Order
KM-22674 11.812 11.437 3 Feet $464.43 Add to Order
KM-22673 11.875 11.500 3 Feet $466.95 Add to Order
KM-22672BQ 11.937 11.562 3 Feet $469.43 Add to Order
KM-22671 12.000 11.625 3 Feet $471.95 Add to Order
KM-22670BQ 12.062 11.687 3 Feet $474.43 Add to Order
KM-22660 12.125 11.750 3 Feet $476.93 Add to Order
KM-22668BQ 12.187 11.812 3 Feet $479.40 Add to Order
KM-22676BQ 12.250 11.875 3 Feet $481.93 Add to Order
KM-22666BQ 12.313 11.937 3 Feet $484.40 Add to Order
KM-22665BQ 12.375 12.000 3 Feet $486.93 Add to Order
KM-22664 12.437 12.062 3 Feet $489.40 Add to Order
KM-22663 12.500 12.125 3 Feet $491.93 Add to Order
KM-22662 12.562 12.187 3 Feet $494.40 Add to Order
KM-22684BQ 12.625 12.250 3 Feet $496.90 Add to Order
KM-22667 12.687 12.312 3 Feet $499.38 Add to Order
KM-22669 12.750 12.375 3 Feet $501.90 Add to Order
KM-22692BQ 12.812 12.437 3 Feet $504.38 Add to Order
KM-22691BQ 12.875 12.500 3 Feet $506.90 Add to Order
KM-22689 13.000 12.625 3 Feet $511.90 Add to Order
KM-22688BQ 13.062 12.687 3 Feet $514.38 Add to Order
KM-22687BQ 13.125 12.750 3 Feet $516.88 Add to Order
KM-22677 13.187 12.813 3 Feet $519.35 Add to Order
KM-22685BQ 13.250 12.875 3 Feet $521.88 Add to Order
KM-22693 13.312 12.937 3 Feet $524.35 Add to Order
KM-22683 13.375 13.000 3 Feet $526.88 Add to Order
KM-22682 13.437 13.062 3 Feet $529.35 Add to Order
KM-22681BQ 13.500 13.125 3 Feet $531.88 Add to Order
KM-22680 13.562 13.187 3 Feet $534.35 Add to Order
KM-22679BQ 13.625 13.250 3 Feet $536.85 Add to Order
KM-22678BQ 13.687 13.312 3 Feet $539.35 Add to Order
KM-22729 13.750 13.375 3 Feet $541.85 Add to Order
KM-22780 13.812 13.437 3 Feet $544.32 Add to Order
KM-22720BQ 13.875 13.500 3 Feet $546.85 Add to Order
KM-22776 13.937 13.562 3 Feet $549.32 Add to Order
KM-22775 14.000 13.625 3 Feet $551.85 Add to Order
KM-22774BQ 14.062 13.687 3 Feet $554.32 Add to Order
KM-22773 14.125 13.750 3 Feet $556.82 Add to Order
KM-22772 14.187 13.812 3 Feet $559.32 Add to Order
KM-22762BQ 14.250 13.875 3 Feet $561.82 Add to Order
KM-22770 14.312 13.937 3 Feet $564.30 Add to Order
KM-22778BQ 14.375 14.000 3 Feet $566.82 Add to Order
KM-22768 14.437 14.062 3 Feet $569.30 Add to Order
KM-22767 14.500 14.125 3 Feet $571.82 Add to Order
KM-22766 14.562 14.187 3 Feet $574.30 Add to Order
KM-22765 14.625 14.250 3 Feet $576.82 Add to Order
KM-22764 14.687 14.312 3 Feet $579.30 Add to Order
KM-22763BQ 14.750 14.375 3 Feet $581.80 Add to Order
KM-22786BQ 14.812 14.437 3 Feet $584.28 Add to Order
KM-22788BQ 14.875 14.500 3 Feet $586.80 Add to Order
KM-22771 14.937 14.562 3 Feet $589.28 Add to Order
KM-22794 15.000 14.625 3 Feet $591.80 Add to Order
KM-22793BQ 15.062 14.687 3 Feet $594.28 Add to Order
KM-22792 15.125 14.750 3 Feet $596.80 Add to Order
KM-22791 15.187 14.812 3 Feet $599.28 Add to Order
KM-22790BQ 15.250 14.875 3 Feet $601.78 Add to Order
KM-22789 15.312 14.937 3 Feet $604.25 Add to Order
KM-22779BQ 15.375 15.000 3 Feet $606.78 Add to Order
KM-22787BQ 15.437 15.062 3 Feet $609.25 Add to Order
KM-22796BQ 15.500 15.125 3 Feet $611.78 Add to Order
KM-22785 15.562 15.187 3 Feet $614.25 Add to Order
KM-22784BQ 15.625 15.250 3 Feet $616.78 Add to Order
KM-22783BQ 15.687 15.312 3 Feet $619.25 Add to Order
KM-22782 15.750 15.375 3 Feet $621.75 Add to Order
KM-22781 15.812 15.437 3 Feet $624.23 Add to Order
KM-22754BQ 15.875 15.500 3 Feet $626.75 Add to Order
KM-22795BQ 15.937 15.562 3 Feet $629.23 Add to Order
KM-22769 16.000 15.625 3 Feet $631.75 Add to Order
KM-22743BQ 16.062 15.687 3 Feet $634.23 Add to Order
KM-22742 16.125 15.750 3 Feet $636.75 Add to Order
KM-22741BQ 16.187 15.812 3 Feet $639.23 Add to Order
KM-22740 16.250 15.875 3 Feet $641.73 Add to Order
KM-22739 16.312 15.937 3 Feet $644.23 Add to Order
KM-22738Q 16.375 16.000 3 Feet $646.73 Add to Order
KM-22728BQ 16.437 16.062 3 Feet $649.20 Add to Order
KM-22736 16.500 16.125 3 Feet $651.73 Add to Order
KM-22744BQ 16.562 16.187 3 Feet $654.20 Add to Order
KM-22734 16.625 16.250 3 Feet $656.73 Add to Order
KM-22733 16.687 16.312 3 Feet $659.20 Add to Order
KM-22732BQ 16.750 16.375 3 Feet $661.70 Add to Order
KM-22731 16.812 16.437 3 Feet $664.20 Add to Order
KM-22730BQ 16.875 16.500 3 Feet $666.70 Add to Order
KM-22752 16.937 16.562 3 Feet $669.18 Add to Order
KM-22735 17.000 16.625 3 Feet $671.70 Add to Order
KM-22737 17.062 16.687 3 Feet $674.18 Add to Order
KM-22760 17.125 16.750 3 Feet $676.70 Add to Order
KM-22759 17.187 16.812 3 Feet $679.18 Add to Order
KM-22758 17.250 16.875 3 Feet $681.70 Add to Order
KM-22757BQ 17.312 16.937 3 Feet $684.18 Add to Order
KM-22756 17.375 17.000 3 Feet $686.68 Add to Order
KM-22755 17.437 17.062 3 Feet $689.15 Add to Order
KM-22745 17.500 17.125 3 Feet $691.68 Add to Order
KM-22753 17.562 17.187 3 Feet $694.15 Add to Order
KM-22761 17.625 17.250 3 Feet $696.68 Add to Order
KM-22751BQ 17.687 17.312 3 Feet $699.15 Add to Order
KM-22750BQ 17.750 17.375 3 Feet $701.68 Add to Order
KM-22749 17.812 17.437 3 Feet $704.15 Add to Order
KM-22748BQ 17.875 17.500 3 Feet $706.65 Add to Order
KM-22747BQ 17.937 17.562 3 Feet $709.13 Add to Order
KM-22652BQ 18.000 17.625 3 Feet $711.65 Add to Order
KM-22777 18.062 17.687 3 Feet $714.13 Add to Order
KM-22675 18.125 17.750 3 Feet $716.65 Add to Order
KM-22573 18.187 17.812 3 Feet $719.13 Add to Order
KM-22572Q 18.250 17.875 3 Feet $721.65 Add to Order
KM-22571 18.312 17.937 3 Feet $724.13 Add to Order
KM-22570 18.375 18.000 3 Feet $726.63 Add to Order
KM-22569Q 18.437 18.062 3 Feet $729.10 Add to Order
KM-22568TS 18.500 18.125 3 Feet $731.63 Add to Order
KM-22558TS 18.562 18.187 3 Feet $734.10 Add to Order
KM-22566TS 18.625 18.250 3 Feet $736.63 Add to Order
KM-22574TS 18.687 18.312 3 Feet $739.10 Add to Order
KM-22564TS 18.750 18.375 3 Feet $741.63 Add to Order
KM-22563TS 18.812 18.437 3 Feet $744.10 Add to Order
KM-22562TS 18.875 18.500 3 Feet $746.60 Add to Order
KM-22561TS 18.937 18.563 3 Feet $749.10 Add to Order
KM-22560TS 19.000 18.625 3 Feet $751.60 Add to Order
KM-22582TS 19.062 18.687 3 Feet $754.08 Add to Order
KM-22565TS 19.125 18.750 3 Feet $756.60 Add to Order
KM-22567TS 19.187 18.812 3 Feet $759.08 Add to Order
KM-22590TS 19.250 18.875 3 Feet $761.60 Add to Order
KM-22589TS 19.312 18.937 3 Feet $764.08 Add to Order
KM-22588TS 19.375 19.000 3 Feet $766.58 Add to Order
KM-22587TS 19.437 19.062 3 Feet $769.08 Add to Order
KM-22586TS 19.500 19.125 3 Feet $771.58 Add to Order
KM-22585Q 19.625 19.250 3 Feet $776.58 Add to Order
KM-22110 19.687 19.312 3 Feet $779.05 Add to Order
KM-22575TS 19.687 19.312 3 Feet $779.05 Add to Order
KM-22115 19.750 19.375 3 Feet $781.58 Add to Order
KM-22114 19.812 19.437 3 Feet $784.05 Add to Order
KM-22113 19.875 19.500 3 Feet $786.58 Add to Order
KM-22112 19.937 19.562 3 Feet $789.05 Add to Order
KM-22111 20.000 19.625 3 Feet $791.55 Add to Order
Rev. 12-22, 08-22, 06-22, 04-22
