Paper X, XX, XXX Reinforced Phenolic Laminate Tubes - .062" Wall Thickness

Paper Phenolic Tubes .062 inch wall

Paper X/XX/XXX Reinforced Phenolic Tubes - natural (tan) Technical Data Sheet
This grade is composed of a paper base impregnated with a phenolic resin binder. It has good electric strength properties with fair mechanical strength. Outstanding for use as template material and or backup material.
NEMA X certs to MIL-I-24768/12 PBM, IEC 60893-3 Type 4 PF CP 201
NEMA XX certs to MIL-I-24768/11 PBG, IEC 60893-3 Type 4 PF CP 203
NEMA XXX certs to MIL-I-24768/10 PBE, IEC 60893-3 Type 4 PF CP 201

NEMA grades X, XX and XXX Paper Reinforced Phenolic -- natural color is typically light tan to brown. These grades are composed of a paper base impregnated with a phenolic resin binder. (Phenolics are the oldest, best-known general purpose thermoset resins. They are among the lowest in cost and easiest to process. Phenolics are quite adequate for a fair percentage of electrical applications. Generally speaking, they are not equivalent to epoxies in resistance to moisture, humidity, dimensional stability, shrinkage and retention of electrical properties in extreme environments.) The paper reinforced phenolic has good electric strength properties with fair mechanical strength and are outstanding for use as template material and/or back-up material.

Click Here for X, XX, XXX  or Sheets Bar Stock

Chemical Resistance Chart

Select X, XX, XXX Tubing Wall Thickness
.031" .062" .093"
.125" .187" .250"
.375" .500" .750"
1.00"



Paper Phenolic Tubes .062" Wall Thickness
Stock # OD Inch ID Inch Min Purchase Feet  Price/Ft Purchase Online
KM-1864 .313 .187 60 $6.18 Buy Now
KM-1868 .375 .250 60 $6.28 Buy Now
KM-1872 .438 .312 60 $6.35 Buy Now
KM-22889 .500 .375 57 $6.75 Buy Now
KM-1876 .563 .437 54 $6.95 Buy Now
KM-1880 .625 .500 51 $7.23 Buy Now
KM-1886 .688 .562 51 $7.38 Buy Now
KM-1891 .750 .625 51 $7.43 Buy Now
KM-1897 .813 .687 48 $7.70 Buy Now
KM-1900 .875 .750 48 $8.35 Buy Now
KM-22882 .938 .812 45 $8.55 Buy Now
KM-1906 1.000 .875 42 $9.15 Buy Now
KM-22880 1.062 .937 39 $9.70 Buy Now
KM-1912 1.125 1.000 39 $9.72 Buy Now
KM-1146X 1.187 1.062 36 $9.74 Buy Now
KM-22926 1.250 1.125 33  $10.48 Buy Now
KM-1150W 1.312 1.187 33  $10.60 Buy Now
KM-1917 1.375 1.250 30  $12.30 Buy Now
KM-22913BQ 1.437 1.312 30  $12.78 Buy Now
KM-1198 1.500 1.375 30  $13.28 Buy Now
KM-22911 1.562 1.437 27  $13.75 Buy Now
KM-1922 1.625 1.50 27  $14.23 Buy Now
KM-23046 1.687 1.562 27  $14.68 Buy Now
KM-4778 1.750 1.625 24  $15.13 Buy Now
KM-22897BQ 1.812 1.687 24  $15.58 Buy Now
KM-1927 1.875 1.750 24  $16.03 Buy Now
KM-6591 1.937 1.781 24  $16.45 Buy Now
KM-1207 2.000 1.875 24  $16.85 Buy Now
KM-1928W 2.062 1.937 21  $17.28 Buy Now
KM-1932 2.125 2.000 21  $17.68 Buy Now
KM-22901 2.188 2.062 21  $18.08 Buy Now
KM-22900 2.250 2.125 21  $18.45 Buy Now
KM-22899BQ 2.312 2.187 21  $18.85 Buy Now
KM-1937 2.375 2.250 21  $19.20 Buy Now
KM-22905 2.437 2.312 21  $19.58 Buy Now
KM-22907BQ 2.500 2.375 21  $19.93 Buy Now
KM-22933BQ 2.562 2.437 18  $20.28 Buy Now
KM-1942 2.625 2.500 18  $20.60 Buy Now
KM-22931 2.688 2.562 18  $20.95 Buy Now
KM-22930BQ 2.750 2.625 18  $21.28 Buy Now
KM-22929 2.812 2.687 18  $21.58 Buy Now
KM-1947 2.875 2.750 18  $21.88 Buy Now
KM-22927BQ 2.937 2.812 18  $22.18 Buy Now
KM-22916 3.000 2.875 18  $22.48 Buy Now
KM-22925 3.062 2.937 18  $22.75 Buy Now
KM-1952 3.125 2.000 18  $23.03 Buy Now
KM-22923 3.188 3.062 18  $23.28 Buy Now
KM-22922BQ 3.250 3.125 18  $23.55 Buy Now
KM-22921BQ 3.312 3.187 18  $23.80 Buy Now
KM-1957 3.375 3.250 15  $24.03 Buy Now
KM-22919BQ 3.437 3.312 15  $24.43 Buy Now
KM-22918 3.500 3.375 15  $24.80 Buy Now
KM-22917 3.562 3.437 15  $25.18 Buy Now
KM-1962 3.625 3.500 15  $25.55 Buy Now
KM-19264 3.687 3.562 15  $25.93 Buy Now
KM-19680 3.750 3.625 15  $26.30 Buy Now
KM-19679 3.812 3.687 15  $26.68 Buy Now
KM-1967 3.875 3.750 15  $27.05 Buy Now
KM-19677 3.937 3.812 15  $27.40 Buy Now
KM-19676 4.000 3.875 15  $27.78 Buy Now
KM-19675 4.062 3.937 15  $28.13 Buy Now
KM-1972 4.125 4.000 15  $28.50 Buy Now
KM-19663 4.187 4.062 15  $28.85 Buy Now
KM-19672 4.250 4.125 15  $29.20 Buy Now
KM-19681 4.312 4.187 15  $29.55 Buy Now
KM-19670 4.375 4.250 15  $29.90 Buy Now
KM-19669 4.437 4.312 12  $30.25 Buy Now
KM-19668 4.500 4.375 12  $30.58 Buy Now
KM-19667 4.562 4.438 12  $30.93 Buy Now
KM-1977 4.625 4.500 12  $31.25 Buy Now
KM-19665 4.687 4.562 12  $31.60 Buy Now
KM-19690 4.750 4.625 12  $31.93 Buy Now
KM-19671 4.812 4.687 12  $32.25 Buy Now
KM-19673 4.875 4.750 12  $32.58 Buy Now
KM-19699 4.937 4.812 12  $32.90 Buy Now
KM-19698 5.000 4.875 12  $33.23 Buy Now
KM-19697 5.062 4.937 12  $33.55 Buy Now
KM-1982 5.125 5.000 12  $33.88 Buy Now
KM-19695 5.187 5.062 12  $34.18 Buy Now
KM-19694 5.250 5.125 12  $34.50 Buy Now
KM-19693 5.312 5.187 12  $34.80 Buy Now
KM-19682 5.375 5.250 12  $35.13 Buy Now
KM-19691 5.437 5.250 12  $35.43 Buy Now
KM-19700 5.500 5.375 12  $35.73 Buy Now
KM-19689 5.562 5.437 12  $36.03 Buy Now
KM-1988 5.625 5.500 12  $36.33 Buy Now
KM-19688 5.688 5.562 12  $36.63 Buy Now
KM-19687 5.750 5.625 12  $36.80 Buy Now
KM-19686 5.812 5.687 12  $37.05 Buy Now
KM-19685 5.875 5.750 12  $37.28 Buy Now
KM-19684 5.938 5.812 12  $37.53 Buy Now
KM-19683 6.000 5.875 12  $37.75 Buy Now
KM-19654 6.063 5.937 12  $37.98 Buy Now
KM-1994 6.125 6.000 12  $38.23 Buy Now
KM-19664 6.187 6.062 12  $38.35 Buy Now
KM-19641 6.250 6.125 12  $38.65 Buy Now
KM-19640 6.312 6.187 12  $38.88 Buy Now
KM-19639 6.375 6.250 12  $39.10 Buy Now
KM-19638 6.437 6.312 12  $39.30 Buy Now
KM-19637 6.500 6.375 12  $39.50 Buy Now
KM-19636 6.562 6.437 12  $39.73 Buy Now
KM-19625 6.625 6.500 9  $39.93 Buy Now
KM-19634 6.688 6.562 9  $40.10 Buy Now
KM-19643 6.750 6.625 9  $40.30 Buy Now
KM-19631 6.812 6.687 9  $40.50 Buy Now
KM-19630 6.875 6.750 9  $40.68 Buy Now
KM-19629 6.938 6.812 9  $40.88 Buy Now
KM-19628 7.000 6.875 9  $41.05 Buy Now
KM-19627 7.062 6.938 9  $41.23 Buy Now
KM-19652 7.125 7.000 9  $41.40 Buy Now
KM-19633 7.187 7.062 9  $41.55 Buy Now
KM-19635 7.250 7.125 9  $41.73 Buy Now
KM-19661 7.312 7.187 9  $41.90 Buy Now
KM-19660 7.375 7.250 9  $42.05 Buy Now
KM-19659 7.437 7.312 9  $42.20 Buy Now
KM-19658 7.500 7.375 9  $42.35 Buy Now
KM-19657 7.562 7.437 9  $42.50 Buy Now
KM-19656 7.625 7.500 9  $42.65 Buy Now
KM-19655 7.688 7.562 9  $42.80 Buy Now
KM-19644 7.750 7.625 9  $42.93 Buy Now
KM-19653 7.812 7.687 9  $43.08 Buy Now
KM-19662 7.875 7.750 9  $43.20 Buy Now
KM-19651 7.938 7.812 9  $43.33 Buy Now
KM-19650 8.000 7.875 9  $43.45 Buy Now
KM-21201 8.062 7.937 9  $43.58 Buy Now
KM-19649 8.125 8.000 9  $43.68 Buy Now
KM-21732 8.188 8.062 9  $43.80 Buy Now
KM-19647 8.250 8.125 9  $43.93 Buy Now
KM-19646 8.312 8.187 9  $44.05 Buy Now
KM-19718 8.375 8.250 9  $44.18 Buy Now
KM-19642 8.437 8.312 9  $44.30 Buy Now
KM-19692 8.500 8.375 9  $44.63 Buy Now
KM-19756 8.562 8.437 9  $44.95 Buy Now
KM-19755 8.625 8.500 9  $45.28 Buy Now
KM-19754 8.688 8.625 9  $45.63 Buy Now
KM-19753 8.750 8.687 9  $45.95 Buy Now
KM-19752 8.812 8.750 9  $46.28 Buy Now
KM-19751 8.875 8.812 9  $46.60 Buy Now
KM-23045 8.937 8.813 9  $46.93 Buy Now



diameter

plus or minus (±) tolerance, inches

ID inside diameter

OD outside diameter

steel
mandrel

built-up
mandrel

.125" -.749"

.003"

-

.005"

.750" - 1.999"

.004"

-

.005"

2.000" - 4.000"

.006"

-

.008"



*turned

*as wound

4.001" - 12.000"

.010"

-

.025"

plus only

12.001" - 18.000"

.030"

.060"

.030"

plus only

18.001" - 24.000"

.040"

.075"

.035"

plus only

24.001" - 48.000"

.060"

.090"

.040"

plus only

*Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request)
