Santoprene® TPE Tubing
Highly durable, resistant to fatigue,
ozone, ultraviolet, acids, alkalis, oils, lubricants
Flex fatigue performance, extended life cycle performance, material cost savings vs. silicone
tubing, good chemical resistance and drug
compatibility.
64A Technical Data
73A Technical Data
73A FDA Technical Data
| Santoprene® TPE Thermoplastic Elastomer
Tubes and Tubing
64A Tubing is available in Black, Red, Green or Blue. |
||||||
| Inside Diameter (in.) | Outside Diameter (in.) | Wall (in.) | Durometer | Part # | Price Per 50 Foot Coil | Order Online |
|---|---|---|---|---|---|---|
| .063" | .188" | .063" | 64A | KM-215 | $13.54 | Add to Order |
| .125" | .250" | .063" | 64A | KM-217 | $18.38 | Add to Order |
| .188" | .313" | .063" | 64A | KM-220 | $21.46 | Add to Order |
| .188" | .375" | .094" | 64A | KM-221 | $34.85 | Add to Order |
| .250" | .375" | .063" | 64A | KM-224 | $26.24 | Add to Order |
| .250" | .438" | .094" | 64A | KM-225 | $42.89 | Add to Order |
| .250" | .500" | .125" | 64A | KM-226 | $62.01 | Add to Order |
| .250" | .625" | .188" | 64A | KM-227 | $106.99 | Add to Order |
| .313" | .438" | .063" | 64A | KM-228 | $32.56 | Add to Order |
| .313" | .500" | .094" | 64A | KM-229 | $51.68 | Add to Order |
| .375" | .500" | .063" | 64A | KM-232 | $36.20 | Add to Order |
| .375" | .563" | .094" | 64A | KM-233 | $59.33 | Add to Order |
| .375" | .625" | .125" | 64A | KM-234 | $83.25 | Add to Order |
| .438" | .563" | .063" | 64A | KM-236 | $43.25 | Add to Order |
| .500" | .625" | .063" | 64A | KM-238 | $48.02 | Add to Order |
| .500" | .687' | .094" | 64A | KM-239 | $73.82 | Add to Order |
| .500" | .750" | .125" | 64A | KM-240 | $103.48 | Add to Order |
| .625" | .875" | .125" | 64A | KM-242 | $135.16 | Add to Order |
| .750" | 1.00" | .125" | 64A | KM-244 | $142.67 | Add to Order |
| 1.00" | 1.250" | .125" | 64A | KM-245 | $183.80 | Add to Order |
| ↓ 73A: Black Only ↓ | ||||||
| .125" | .250" | .063" | 73A | KM-248 | $16.61 | Add to Order |
| .250" | .375" | .063" | 73A | KM-256 | $26.73 | Add to Order |
| .375" | .625" | .125" | 73A | KM-266 | $82.96 | Add to Order |
| .438" | .563" | .063" | 73A | KM-268 | $43.11 | Add to Order |
| .500" | .688" | .094" | 73A | KM-271 | $73.58 | Add to Order |
| .500" | .750" | .125" | 73A | KM-272 | $103.10 | Add to Order |
| .625" | .875" | .125" | 73A | KM-274 | $122.15 | Add to Order |
| 1.00" | 1.250" | .125" | 73A | KM-277 | $183.15 | Add to Order |
| ↓ 73A-FDA: Natural Color Only ↓ | ||||||
| .063" | .188" | .063" | 73A-FDA | KM-289 | $16.06 | Add to Order |
| .125" | .250" | .063" | 73A-FDA | KM-290 | $20.00 | Add to Order |
| .125" | .375" | .125" | 73A-FDA | KM-292 | $47.18 | Add to Order |
| .188" | .313" | .063" | 73A-FDA | KM-293 | $23.45 | Add to Order |
| .188" | .375" | .094" | 73A-FDA | KM-295 | $38.14 | Add to Order |
| .188" | .563" | .188" | 73A-FDA | KM-296 | $100.08 | Add to Order |
| .250" | .375" | .063" | 73A-FDA | KM-298 | $33.62 | Add to Order |
| .250" | .438" | .094" | 73A-FDA | KM-299 | $46.96 | Add to Order |
| .250" | .500" | .125" | 73A-FDA | KM-300 | $67.93 | Add to Order |
| .250" | .625" | .188" | 73A-FDA | KM-301 | $117.32 | Add to Order |
| .313" | .438" | .063" | 73A-FDA | KM-302 | $35.48 | Add to Order |
| .313" | .500" | .094" | 73A-FDA | KM-303 | $56.50 | Add to Order |
| .375" | .500" | .063" | 73A-FDA | KM-306 | $39.60 | Add to Order |
| .375" | .563" | .094" | 73A-FDA | KM-307 | $64.87 | Add to Order |
| .375" | .625" | .125" | 73A-FDA | KM-308 | $91.15 | Add to Order |
| .500" | .625" | .063" | 73A-FDA | KM-311 | $52.45 | Add to Order |
| .500" | .688" | .094" | 73A-FDA | KM-313 | $80.77 | Add to Order |
| .500" | .750" | .125" | 73A-FDA | KM-314 | $113.33 | Add to Order |
| .625" | .875" | .125" | 73A-FDA | KM-316 | $134.33 | Add to Order |
| .750" | 1.00" | .125" | 73A-FDA | KM-318 | $156.38 | Add to Order |
| 1.00" | 1.250" | .125" | 73A-FDA | KM-319 | $201.53 | Add to Order |
| Rev. 01-24, 04-23, 03-22, 02-22 | ||||||
Santoprene® is a registered trademark of Advanced Elastomer Systems
