Polycarbonate Anti-Static Sheets - PC-300™

Static Dissipative Plastic

Description

PC-300™ Polycarbonate is a plastic sheet product designed to control static electricity for a wide range of end uses. It is a premium quality polycarbonate sheet which has been surfaced with SciCron Technologies proprietary, clear, C-300™ static dissipative surfacing. This unique technology prevents charge generation on the sheet surfaces, thereby controlling particulate attraction and preventing electrostatic discharge (ESD) events. This performance is permanent and totally independent of humidity. PC-300 Polycarbonate offers exceptional design versatility since it fabricates simply, is light in weight and is available in large sheet sizes. It also exhibits superior impact resistance and flame spread properties, plus excellent clarity, chemical resistance, and mar resistance.

Applications

PC-300 Polycarbonate resists tribo charging under all circumstances and cannot generate a charge when properly grounded. This makes it ideal for sensitive electronic components where it can help prevent both immediate and latent ESD caused defects. Since it resists charge build-up it does not attract contaminants. The product also provides protection for static charge sensitive manufacturing devices and control of spark discharge in explosive environments.

PC300 Antistatic Polycarbonate Sheets

PC-300™ Anti Static Polycarbonate Sheet - Clear
PC-300™ Technical Data

 Full Sheets Must Ship on Truck

Thickness (in.) Width (in.) Length (in.) Part # Price Per Sheet Order Online
0.125 12 12 KS-6182 $100.41 Add to Order
0.125 12 24 KS-6183 $131.08 Add to Order
0.125 24 24 KS-6184 $296.40 Add to Order
0.125 24 48 KS-6185 $515.48 Add to Order
0.125 48 96 KS-6187 $1,308.00 Add to Order
0.187 12 12 KS-6188 $117.78 Add to Order
0.187 12 24 KS-6189 $155.70 Add to Order
0.187 24 24 KS-6190 $356.26 Add to Order
0.187 24 48 KS-6191 $599.64 Add to Order
0.250 12 12 KS-6194 $62.76 Add to Order
0.250 12 24 KS-6195 $100.44 Add to Order
0.250 24 24 KS-6196 $167.38 Add to Order
0.250 24 48 KS-6197 $334.76 Add to Order
0.250 48 96 KS-6199 $1,339.06 Add to Order
0.375 12 12 KS-6200 $71.01 Add to Order
0.375 12 24 KS-6201 $129.13 Add to Order
0.375 24 24 KS-6202 $258.23 Add to Order
0.375 24 48 KS-6203 $413.18 Add to Order
0.375 48 96 KS-6205 $1,652.70 Add to Order
0.500 12 12 KS-6206 $89.70 Add to Order
0.500 12 24 KS-6207 $164.45 Add to Order
0.500 24 24 KS-6208 $299.00 Add to Order
0.500 24 48 KS-6209 $538.20 Add to Order
0.500 48 96 KS-6211 $1,913.56 Add to Order
Rev. 10-23, 04-23, 10-22, 05-22
