Polycarbonate GE Lexan® 9034 Plastic Sheet


In thicknesses of .125", Lexan® 9034 sheet will transmit 86% of the light. Lexan® 9034 is UV stabilized, has a heat deflection temperature of 270 degrees F at 264 PSI,

 and has a smoke density rating less than 75. Lexan® 9034 is engineered for window glazing as well as for sign applications. In addition to colorless (clear),

Lexan® 9034 is available in solar gray and bronze in thicknesses from .080" to .500".

Lexan® 9034 uncoated polycarbonate sheet is the standard grade of Lexan® sheet for general purpose applications.

High-impact Lexan® 9034 can be used for economical protection against breakage or intrusion.

A better insulator than glass, it contributes to lower energy costs.

Technical Data

Chemical Resistant Chart

Lexan® Translucent Grey Lexan® Translucent Bronze
Actual Colors may appear different than shown due to different monitor setting.



Polycarbonate GE Lexan® 9034 Sheet
Standard tolerances estimated +/-10%.

Full Sheets Must Ship By Truck

**Note:  All Sheets larger than 48" x 48" Ship Via Truck.**

Thickness (in.) Length (in.) Width (in.) Color Part # Price Order Online
.062 48 96 Clear KS-9377 $143.04 Add to Order
.094 48 96 Clear KS-5128Q $289.92 Add to Order
.125 48 96 Translucent Bronze KS-2595 $649.60 Add to Order
.125 48 96 Translucent Grey KS-2590 $649.60 Add to Order
.125 48 96 Clear KS-6111 $290.00 Add to Order
.125 60 96 Clear KS-3262V $355.20 Add to Order
.125 72 96 Clear KS-1159L $395.52 Add to Order
.188 48 96 Translucent Bronze KS-2597 $899.56 Add to Order
.188 48 96 Clear KS-6112 $443.24 Add to Order
.188 48 96 Translucent Grey KS-2591 $899.56 Add to Order
.250 48 96 Translucent Grey KS-2592 $902.04 Add to Order
.250 48 96 Clear KS-6114 $458.96 Add to Order
.250 48 96 Translucent Bronze KS-2596 $949.52 Add to Order
.250 48 120 Clear KS-5568J $582.40 Add to Order
.250 60 96 Clear KS-2564J $568.40 Add to Order
.375 48 96 Clear KS-6113 $823.45 Add to Order
.500 48 96 Clear KS-3110U $1,226.86 Add to Order
.500 60 96 Clear KS-2936Z $1,278.07 Add to Order
.500 72 96 Clear KS-6288 $1,697.45 Add to Order



Lexan® 9034 sheet Approved plastic material for light transmitting applications.
Minimum thickness 2mm,

Burglary resisting.
Glazing Standard 972.
Minimum thickness 2mm

Meets safety standard for architectural glazing materials categories I & II

CC 1/ASTM D635
CC-2/ASTM D635
Urban Mass Transit Admin. flammability and smoke guidelines
