L and LE Linen Fabric Reinforced Phenolic Tubing .500" Wall Thickness

Linen Phenolic Tubing LE .500 Inch Wall Thickness

Linen L and LE (Elecritical Grade) Linen Fabric Reinforced Phenolic Tubing - natural (light tan to brown) Technical Data Sheet
This grade is composed of a continuous Linen woven cloth impregnated with a phenolic resin binder. This grade contains a fine weave linen and, like the canvas phenolic, is known for it's mechanical properties. The finer weave allows for machining more intricate details than Canvas, like gear teeth. This grade is not recommended for primary insulation.

NEMA grades L and LE Linen Cotton-Cloth Reinforced Phenolic -- natural color is typically light tan to brown. This grade is composed of a continuous cotton woven cloth impregnated with a phenolic resin binder. This grade contains a fine weave linen and, like the canvas phenolic, is known for its mechanical properties. The finer weave allows for machining more intricate details than canvas grade, such as gear teeth, etc. These grades are not recommended for primary electrical insulation, but grade LE exhibits superior moisture resistance to grades L, C and CE, and thus is an adequate insulator for a fair number of applications.

NEMA L certs to MIL-I-24768/15- FBI, IEC 60893-3 Type 4 PF CC 305
NEMA LE certs to MIL-I-24768/13 FBE, IEC 60893-3 Type 4 PF CC 305

Chemical Resistance Chart

Click Here For L/LE Rods or Sheets

Select L and LE Tubing Wall Thickness
.031" .062" .093"
.125" .187" .250"
.375" .500" .750"
1.00"



L or LE Linen Fabric Reinforced Phenolic Tubing

.500 Wall Thickness

Lead Times May Apply for Non Stocked Items

Stock # OD Inches ID Inches Min Ft To Purchase  Price Per Foot Purchase Online
KM-15781 1.500 .500 9 $57.96 Buy Now
KM-15782 1.562 .562 9 $60.38 Buy Now
KM-15783 1.625 .625 9 $63.25 Buy Now
KM-15784 1.688 .687 9 $66.08 Buy Now
KM-15785 1.750 .750 9 $68.85 Buy Now
KM-15786 1.812 .812 9 $70.77 Buy Now
KM-15797 1.875 .875 9 $72.52 Buy Now
KM-15788 1.937 .937 9 $75.01 Buy Now
KM-15780 2.000 1.000 9 $78.26 Buy Now
KM-15790 2.062 1.062 9 $81.52 Buy Now
KM-15791 2.125 1.125 6 $84.77 Buy Now
KM-15792 2.188 1.187 6 $88.03 Buy Now
KM-15793 2.250 1.250 6 $91.32 Buy Now
KM-15794 2.312 1.312 6 $94.57 Buy Now
KM-15795 2.375 1.375 6 $97.83 Buy Now
KM-15772 2.437 1.437 6 $101.08 Buy Now
KM-2245 2.500 1.500 6 $104.34 Buy Now
KM-15789 2.562 1.562 6 $107.59 Buy Now
KM-15787 2.625 1.625 6 $110.85 Buy Now
KM-15764 2.688 1.687 6 $114.14 Buy Now
KM-2250 2.750 1.750 6 $117.39 Buy Now
KM-15765 2.812 1.812 6 $120.65 Buy Now
KM-15766 2.875 1.875 6 $123.90 Buy Now
KM-15767 2.937 1.937 6 $127.16 Buy Now
KM-2255 3.000 2.000 6 $133.70 Buy Now
KM-15768 3.062 2.062 6 $133.70 Buy Now
KM-15769 3.125 2.125 6 $136.96 Buy Now
KM-15779 3.188 2.187 6 $140.21 Buy Now
KM-2260 3.250 2.250 6 $143.47 Buy Now
KM-15771 3.312 2.312 6 $146.72 Buy Now
KM-15763 3.375 2.375 6 $149.98 Buy Now
KM-15773 3.437 2.437 6 $153.27 Buy Now
KM-2265 3.500 2.500 6 $156.52 Buy Now
KM-15774 3.562 2.562 3 $159.78 Buy Now
KM-15775 3.625 2.625 3 $163.03 Buy Now
KM-15776 3.687 2.687 3 $166.29 Buy Now
KM-2270 3.750 2.750 3 $169.54 Buy Now
KM-15777 3.812 2.812 3 $172.83 Buy Now
KM-15778 3.875 2.875 3 $176.09 Buy Now
KM-15799 3.937 2.937 3 $179.34 Buy Now
KM-2275 4.000 3.000 3 $182.60 Buy Now
KM-15825 4.062 3.062 3 $185.85 Buy Now
KM-15796 4.125 3.125 3 $189.11 Buy Now
KM-15818 4.187 3.187 3 $192.40 Buy Now
KM-2280 4.250 3.250 3 $195.65 Buy Now
KM-15819 4.312 3.312 3 $198.91 Buy Now
KM-15820 4.375 3.375 3 $202.16 Buy Now
KM-15821 4.437 3.437 3 $205.42 Buy Now
KM-2285 4.500 3.500 3 $208.67 Buy Now
KM-15822 4.562 3.562 3 $211.93 Buy Now
KM-15833 4.625 3.625 3 $215.22 Buy Now
KM-15824 4.687 3.687 3 $218.47 Buy Now
KM-2290 4.750 3.750 3 $221.73 Buy Now
KM-15816 4.812 3.812 3 $224.98 Buy Now
KM-15826 4.875 3.875 3 $228.24 Buy Now
KM-15827 4.937 3.937 3 $231.49 Buy Now
KM-2294 5.000 4.000 3 $234.78 Buy Now
KM-15828 5.062 4.062 3 $238.04 Buy Now
KM-15829 5.125 4.125 3 $241.29 Buy Now
KM-15830 5.187 4.187 3 $244.55 Buy Now
KM-15831 5.250 4.250 3 $247.80 Buy Now
KM-15832 5.312 4.312 3 $251.06 Buy Now
KM-15807 5.375 4.375 3 $254.35 Buy Now
KM-15805 5.437 4.438 3 $257.60 Buy Now
KM-2299 5.500 4.500 3 $260.86 Buy Now
KM-15823 5.562 4.562 3 $264.11 Buy Now
KM-15800 5.625 4.625 3 $267.37 Buy Now
KM-15801 5.688 4.687 3 $270.62 Buy Now
KM-15802 5.750 4.750 3 $273.91 Buy Now
KM-15803 5.812 4.812 3 $277.17 Buy Now
KM-15804 5.875 4.875 3 $280.42 Buy Now
KM-15815 5.938 4.937 3 $283.68 Buy Now
KM-2304 6.000 5.000 3 $286.93 Buy Now
KM-15806 6.063 5.062 3 $290.19 Buy Now
KM-15798 6.125 5.125 3 $293.48 Buy Now
KM-15808 6.187 5.187 3 $296.73 Buy Now
KM-15809 6.250 5.250 3 $299.99 Buy Now
KM-15810 6.312 5.313 3 $303.24 Buy Now
KM-15886 6.375 5.375 3 $306.50 Buy Now
KM-15812 6.437 5.437 3 $309.75 Buy Now
KM-2310 6.500 5.500 3 $313.01 Buy Now
KM-15817 6.562 5.562 3 $316.30 Buy Now
KM-15814 6.625 5.625 3 $319.55 Buy Now
KM-15746 6.688 5.687 3 $322.81 Buy Now
KM-15699 6.750 5.750 3 $326.06 Buy Now
KM-15770 6.812 5.812 3 $329.32 Buy Now
KM-15711 6.875 5.875 3 $332.57 Buy Now
KM-15712 6.938 5.937 3 $335.86 Buy Now
KM-2316 7.000 6.000 3 $339.12 Buy Now
KM-15713 7.062 6.062 3 $342.37 Buy Now
KM-15714 7.125 6.125 3 $345.63 Buy Now
KM-15715 7.187 6.187 3 $348.88 Buy Now
KM-15726 7.250 6.250 3 $352.14 Buy Now
KM-15717 7.312 6.312 3 $355.43 Buy Now
KM-15709 7.375 6.375 3 $358.68 Buy Now
KM-15719 7.437 6.437 3 $361.94 Buy Now
KM-15720 7.500 6.500 3 $365.19 Buy Now
KM-15721 7.562 6.562 3 $368.45 Buy Now
KM-15722 7.625 6.625 3 $371.70 Buy Now
KM-15577 7.688 6.687 3 $374.99 Buy Now
KM-15578 7.750 6.750 3 $378.25 Buy Now
KM-15579 7.812 6.812 3 $381.50 Buy Now
KM-15580 7.875 6.875 3 $384.76 Buy Now
KM-15581 7.938 6.938 3 $388.01 Buy Now
KM-15558 8.000 7.000 3 $391.27 Buy Now
KM-15575 8.062 7.062 3 $394.56 Buy Now
KM-15573 8.125 7.125 3 $397.81 Buy Now
KM-15550 8.188 7.187 3 $401.07 Buy Now
KM-15551 8.250 7.250 3 $404.32 Buy Now
KM-15900 8.312 7.312 3 $407.58 Buy Now
KM-15901 8.375 7.375 3 $410.83 Buy Now
KM-15902 8.437 7.437 3 $414.09 Buy Now
KM-15903 8.500 7.500 3 $417.38 Buy Now
KM-15904 8.562 7.562 3 $420.63 Buy Now
KM-15879 8.625 7.625 3 $423.89 Buy Now
KM-15877 8.688 7.687 3 $427.14 Buy Now
KM-15895 8.750 7.750 3 $430.40 Buy Now
KM-15872 8.812 7.812 3 $433.65 Buy Now
KM-15873 8.875 7.875 3 $436.94 Buy Now
KM-15874 8.938 7.937 3 $440.20 Buy Now
KM-15875 9.000 8.000 3 $443.45 Buy Now
KM-15876 9.062 8.062 3 $446.71 Buy Now
KM-15887 9.125 8.125 3 $449.96 Buy Now
KM-15878 9.188 8.187 3 $453.22 Buy Now
KM-15870 9.250 8.250 3 $456.51 Buy Now
KM-15880 9.312 8.312 3 $459.76 Buy Now
KM-15881 9.375 8.375 3 $463.02 Buy Now
KM-15882 9.437 8.437 3 $466.27 Buy Now
KM-15883 9.500 8.500 3 $469.53 Buy Now
KM-15884 9.563 8.562 3 $472.78 Buy Now
KM-15885 9.625 8.625 3 $476.07 Buy Now
KM-15813 9.688 8.687 3 $479.33 Buy Now
KM-15457 9.750 8.75 3 $482.58 Buy Now
KM-15496 9.812 8.812 3 $485.84 Buy Now
KM-15497 9.875 8.875 3 $489.09 Buy Now
KM-15498 9.937 8.937 3 $492.35 Buy Now
KM-15499 10.000 9.000 3 $566.44 Buy Now
KM-15500 10.062 9.062 3 $570.16 Buy Now
KM-15501 10.125 9.125 3 $573.88 Buy Now
KM-15512 10.187 9.187 3 $577.60 Buy Now
KM-15503 10.250 9.250 3 $581.32 Buy Now
KM-15495 10.313 9.312 3 $585.04 Buy Now
KM-15505 10.375 9.375 3 $588.76 Buy Now
KM-15506 10.437 9.437 3 $592.52 Buy Now
KM-15507 10.500 9.500 3 $596.24 Buy Now
KM-15508 10.563 9.562 3 $599.96 Buy Now
KM-15509 10.625 9.625 3 $603.68 Buy Now
KM-15510 10.688 9.687 3 $607.40 Buy Now
KM-15511 10.750 9.750 3 $611.12 Buy Now
KM-15723 10.813 9.813 3 $614.88 Buy Now
KM-15724 10.875 9.875 3 $618.60 Buy Now
KM-15701 10.937 9.937 3 $622.32 Buy Now
KM-15718 11.000 10.00 3 $626.04 Buy Now
KM-15716 11.062 10.062 3 $629.76 Buy Now
KM-15693 11.125 10.125 3 $633.48 Buy Now
KM-15694 11.188 10.187 3 $637.24 Buy Now
KM-15695 11.250 10.250 3 $640.96 Buy Now
KM-15696 11.313 10.312 3 $644.68 Buy Now
KM-15697 11.375 10.375 3 $648.40 Buy Now
KM-15698 11.437 10.437 3 $652.12 Buy Now
KM-15708 11.500 10.500 3 $655.84 Buy Now
KM-15700 11.562 10.562 3 $659.60 Buy Now
KM-15692 11.625 10.625 3 $663.32 Buy Now
KM-15702 11.687 10.687 3 $667.04 Buy Now
KM-15703 11.750 10.750 3 $670.76 Buy Now
KM-15704 11.812 10.812 3 $674.48 Buy Now
KM-15705 11.875 10.875 3 $678.20 Buy Now
KM-15706 11.937 10.937 3 $681.96 Buy Now
KM-15707 12.000 11.000 3 $685.68 Buy Now
KM-15728 12.062 11.062 3 $689.40 Buy Now
KM-15754 12.125 11.125 3 $693.12 Buy Now
KM-15725 12.187 11.187 3 $696.84 Buy Now
KM-15747 12.250 11.250 3 $700.56 Buy Now
KM-15748 12.313 11.312 3 $704.28 Buy Now
KM-15749 12.375 11.375 3 $708.04 Buy Now
KM-15750 12.437 11.437 3 $711.76 Buy Now
KM-15751 12.500 11.500 3 $715.48 Buy Now
KM-15762 12.562 11.562 3 $719.20 Buy Now
KM-15753 12.625 11.625 3 $722.92 Buy Now
KM-15745 12.687 11.687 3 $726.64 Buy Now
KM-15755 12.750 11.750 3 $730.40 Buy Now
KM-15756 12.812 11.812 3 $734.12 Buy Now
KM-15757 12.875 11.875 3 $737.84 Buy Now
KM-15758 12.937 11.937 3 $741.56 Buy Now
KM-15759 13.000 12.000 3 $745.28 Buy Now
KM-15760 13.062 12.062 3 $749.00 Buy Now
KM-15761 13.125 12.125 3 $752.76 Buy Now
KM-15736 13.187 12.187 3 $756.48 Buy Now
KM-15734 13.250 12.250 3 $760.20 Buy Now
KM-15752 13.312 12.312 3 $763.92 Buy Now
KM-15729 13.375 12.375 3 $767.64 Buy Now
KM-15730 13.437 12.437 3 $771.36 Buy Now
KM-15731 13.500 12.500 3 $775.12 Buy Now
KM-15732 13.562 12.562 3 $778.84 Buy Now
KM-15733 13.625 12.625 3 $782.56 Buy Now
KM-15744 13.687 12.687 3 $786.28 Buy Now
KM-15735 13.750 12.750 3 $790.00 Buy Now
KM-15727 13.812 12.813 3 $793.72 Buy Now
KM-15737 13.875 12.875 3 $797.48 Buy Now
KM-15738 13.937 12.937 3 $801.20 Buy Now
KM-15739 14.000 13.000 3 $804.92 Buy Now
KM-15740 14.062 13.062 3 $808.64 Buy Now
KM-15741 14.125 13.125 3 $812.36 Buy Now
KM-15742 14.187 13.187 3 $816.08 Buy Now
KM-15743 14.250 13.250 3 $819.80 Buy Now
KM-15710 14.312 13.312 3 $823.56 Buy Now
KM-15853 14.375 13.375 3 $827.28 Buy Now
KM-15925 14.437 13.437 3 $831.00 Buy Now
KM-15926 14.500 13.500 3 $834.72 Buy Now
KM-15927 14.562 13.562 3 $838.44 Buy Now
KM-15928 14.625 13.625 3 $842.16 Buy Now
KM-15929 14.687 13.687 3 $845.92 Buy Now
KM-15930 14.750 13.750 3 $849.64 Buy Now
KM-15941 14.812 13.812 3 $853.36 Buy Now
KM-15932 14.875 13.875 3 $857.08 Buy Now
KM-15924 14.937 13.937 3 $860.80 Buy Now
KM-15934 15.000 14.000 3 $864.52 Buy Now
KM-15935 15.062 14.062 3 $868.28 Buy Now
KM-15936 15.125 14.125 3 $872.00 Buy Now
KM-15937 15.187 14.187 3 $875.72 Buy Now
KM-15938 15.250 14.250 3 $879.44 Buy Now
KM-15939 15.312 14.312 3 $883.16 Buy Now
KM-15940 15.375 14.375 3 $886.88 Buy Now
KM-15915 15.437 14.437 3 $890.64 Buy Now
KM-15913 15.500 14.500 3 $894.36 Buy Now
KM-15931 15.562 14.562 3 $898.08 Buy Now
KM-15908 15.625 14.625 3 $901.80 Buy Now
KM-15909 15.687 14.687 3 $905.52 Buy Now
KM-15910 15.750 14.750 3 $909.24 Buy Now
KM-15911 15.812 14.812 3 $913.00 Buy Now
KM-15912 15.875 14.875 3 $916.72 Buy Now
KM-15923 15.937 14.937 3 $920.44 Buy Now
KM-15914 16.000 15.000 3 $924.16 Buy Now
KM-15906 16.062 15.062 3 $927.88 Buy Now
KM-15916 16.125 15.125 3 $931.60 Buy Now
KM-15917 16.187 15.187 3 $935.32 Buy Now
KM-15918 16.250 15.250 3 $939.08 Buy Now
KM-15919 16.312 15.312 3 $942.80 Buy Now
KM-15920 16.375 15.375 3 $946.52 Buy Now
KM-15921 16.437 15.437 3 $950.24 Buy Now
KM-15943 16.500 15.500 3 $953.96 Buy Now
KM-15907 16.562 15.562 3 $957.68 Buy Now
KM-15933 16.625 15.625 3 $961.44 Buy Now
KM-15960 16.687 15.687 3 $965.16 Buy Now
KM-15961 16.750 15.750 3 $968.88 Buy Now
KM-15962 16.812 15.812 3 $972.60 Buy Now
KM-15963 16.875 15.875 3 $976.32 Buy Now
KM-15964 16.937 15.937 3 $980.04 Buy Now
KM-15976 17.000 16.000 3 $983.80 Buy Now
KM-15966 17.062 16.062 3 $987.52 Buy Now
KM-15959 17.125 16.125 3 $991.24 Buy Now
KM-15968 17.187 16.187 3 $994.96 Buy Now
KM-15969 17.250 16.250 3 $998.68 Buy Now
KM-15970 17.312 16.312 3 $1,002.40 Buy Now
KM-15971 17.375 16.375 3 $1,006.16 Buy Now
KM-15972 17.437 16.437 3 $1,009.88 Buy Now
KM-15973 17.500 16.500 3 $1,013.60 Buy Now
KM-15974 17.562 16.562 3 $1,017.32 Buy Now
KM-15975 17.625 16.625 3 $1,021.04 Buy Now
KM-15967 17.687 16.687 3 $1,024.76 Buy Now
KM-15951 17.750 16.750 3 $1,028.52 Buy Now
KM-15949 17.812 16.812 3 $1,032.24 Buy Now
KM-15965 17.875 16.875 3 $1,035.96 Buy Now
KM-15944 17.937 16.937 3 $1,039.68 Buy Now
KM-15945 18.000 17.000 3 $1,043.40 Buy Now
KM-15946 18.062 17.062 3 $1,047.12 Buy Now
KM-15947 18.125 17.125 3 $1,050.84 Buy Now
KM-15948 18.187 17.187 3 $1,054.60 Buy Now
KM-15958 18.250 17.250 3 $1,058.32 Buy Now
KM-15950 18.312 17.312 3 $1,062.04 Buy Now
KM-15942 18.375 17.375 3 $1,065.76 Buy Now
KM-15952 18.437 17.437 3 $1,069.48 Buy Now
KM-15953 18.500 17.500 3 $1,073.20 Buy Now
KM-15954 18.562 17.562 3 $1,076.96 Buy Now
KM-15955 18.625 17.625 3 $1,080.68 Buy Now
KM-15956 18.687 17.687 3 $1,084.40 Buy Now
KM-15957 18.750 17.750 3 $1,088.12 Buy Now
KM-15897 18.812 17.812 3 $1,091.84 Buy Now
KM-15850 18.875 17.875 3 $1,095.56 Buy Now
KM-15922 18.937 17.937 3 $1,099.32 Buy Now
KM-15854 19.000 18.000 3 $1,103.04 Buy Now
KM-15855 19.062 18.062 3 $1,106.76 Buy Now
KM-15856 19.125 18.125 3 $1,110.48 Buy Now
KM-15857 19.187 18.187 3 $1,114.20 Buy Now
KM-15858 19.250 18.250 3 $1,117.92 Buy Now
KM-15869 19.312 18.312 3 $1,121.68 Buy Now
KM-15860 19.375 18.375 3 $1,125.40 Buy Now
KM-15852 19.437 18.437 3 $1,129.12 Buy Now
KM-15862 19.500 18.500 3 $1,132.84 Buy Now
KM-15863 19.562 18.563 3 $1,136.56 Buy Now
KM-15864 19.625 18.625 3 $1,140.28 Buy Now
KM-15865 19.687 19.687 3 $1,144.04 Buy Now
KM-15866 19.750 18.750 3 $1,147.76 Buy Now
KM-15867 19.812 18.812 3 $1,151.48 Buy Now
KM-15868 19.875 18.875 3 $1,155.20 Buy Now
KM-15843 19.937 18.937 3 $1,158.92 Buy Now
KM-15841 20.000 19.000 3 $1,162.64 Buy Now



nominal inches,
diameter

plus or minus (±) tolerance, inches

ID inside diameter

OD outside diameter

steel
mandrel

built-up
mandrel

.125" -.749"

.003"

-

.005"

.750" - 1.999"

.004"

-

.005"

2.000" - 4.000"

.006"

-

.008"



*turned

*as wound

4.001" - 12.000"

.010"

-

.025"

plus only

12.001" - 18.000"

.030"

.060"

.030"

plus only

18.001" - 24.000"

.040"

.075"

.035"

plus only

24.001" - 48.000"

.060"

.090"

.040"

plus only

*Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request)
