Graphite Bars & Plates

Graphite Bars

Extruded Coarse Graphite Bars/Plates
  • Density:  1.55 g/cm3
  • Particle Size:  .25 in
  • Flexural Strength:  1200 PSI
  • Resistivity:  3.0 ohm/in 10 -4
  • Compressive Strength:  4000 PSI
  • CTE:  .0003 ohm/in
  • Operating Temp:  750°F
  • Porosity:  25%
Thickness (in.) Width (in.) Length (in.) Part # Price Each Order Online
1.00 6.00 6.00 KBS-3912 $106.90 Add to Order
1.00 6.00 12.00 KBS-3910 $205.02 Add to Order
1.00 6.00 24.00 KBS-3945 $232.79 Add to Order
1.00 6.00 36.00 KBS-3800 $307.53 Add to Order
2.00 6.00 6.00 KBS-3948 $130.34 Add to Order
2.00 6.00 12.00 KBS-3949 $326.63 Add to Order
Rev. 06-22, 11-21


Isomolded Superfine Ground Finish Carbon Fiber Bars
  • Density 1.82 g/cm3
  • Particle Size: .0004"
  • Compressive Strength:  17,000 PSI
  • Flexural Strength:  8,500 PSI
  • Resistivity:  .00055 ohm/in
  • CTE:  2.5 in/in/F 10 -6
  • Operating Temp:  800°F
  • Porosity:  9%
  • Thermal Conductivity:  48 BTU/(h.ft 2 °F/ft)
  • Thickness Tolerance: +/-.001
  • Width & Length Tolerance: +/-.005
Part # Thickness (in.) Width (in.) Length (in.) Price Each Order Online
KBS-3813 .125 4.0 4.00 $38.03 Add to Order
KBS-3812 .125 4.0 6.00 $83.61 Add to Order
KBS-3811 .125 6.0 6.00 $83.61 Add to Order
KBS-3767 .125 12.0 12.00 $249.57 Add to Order
KBS-3747 .187 4.0 4.00 $44.96 Add to Order
KBS-3749 .187 4.0 6.00 $96.86 Add to Order
KBS-3777 .187 6.0 6.00 $96.86 Add to Order
KBS-3775 .187 12.0 12.00 $297.07 Add to Order
KBS-3774 .250 4.0 4.00 $52.09 Add to Order
KBS-3731 .312 4.0 6.00 $125.15 Add to Order
KBS-3732 .312 4.0 4.00 $58.46 Add to Order
KBS-3730 .312 6.0 6.00 $125.15 Add to Order
KBS-3728 .312 12.0 12.00 $394.54 Add to Order
KBS-3738 .375 4.0 4.00 $64.94 Add to Order
KBS-3726 .375 4.0 6.00 $138.96 Add to Order
KBS-3725 .375 6.0 6.00 $138.96 Add to Order
KBS-3723 .375 12.0 12.00 $443.25 Add to Order
KBS-3720 .435 6.0 6.00 $102.40 Add to Order
KBS-3722 .437 4.0 4.00 $71.89 Add to Order
KBS-3721 .437 4.0 6.00 $102.17 Add to Order
KBS-3737 .437 12.0 12.00 $491.49 Add to Order
KBS-3708 .500 4.0 4.00 $78.35 Add to Order
Rev. 06-22, 11-21
