G7 Glass Reinforced Silicone Tubes - .500" Wall Thickness

G7 Phenolic Tube .500 inch wall

G7 Glass Reinforced Silicone Tubes- natural (cream to white)

Technical Data Sheet    Chemical Resistance Chart
Composed of a continuous glass woven cloth base impregnated with a silicone resin binder, this grade has excellent heat and arc resistance. It has extremely good dielectric loss properties under dry conditions and good electrical properties under humid conditions, although the percentage of change is high.
NEMA G-7 certs to MIL-I-24768/17 GSG, IEC 60893-3 Type 6 SI GC 201

NEMA grade G7 Glass-Cloth Reinforced Silicone -- natural color is typically cream to white. Composed of a continuous glass woven clothe base impregnated with a silicone resin binder, this grade has excellent heat and arc resistance. (Silicone thermosetting resins are among the best of all polymer materials in resistance to temperature. Hence, silicone is broadly used for high temperature electronic applications requiring low electrical losses. Silicone isn't as strong as epoxies and phenolics upon aging at lower temperatures but is stronger upon aging over 400° F.) G7 has extremely good dielectric loss properties under dry conditions and good electrical properties under humid conditions, although the percentage of change is high.

G7 Sheets    G7 Rods



Select G7 Tube Wall Thickness

.031" .187" .750"
.062" .250" 1.00"
.093" .375"
.125" .500"



G7 Tubes .500" Wall Thickness
Stock # OD Inch ID Inch Min. Feet to Order  Price/Ft Purchase Online
KM-12447 1.500 .500 6 $89.44 Buy Now
KM-12455 1.563 .562 6 $95.02 Buy Now
KM-12454 1.625 .625 6 $100.62 Buy Now
KM-12453 1.688 .687 6 $106.20 Buy Now
KM-12452 1.750 .750 6 $111.80 Buy Now
KM-12451 1.813 .812 6 $117.38 Buy Now
KM-12450 1.875 .875 6 $122.98 Buy Now
KM-12622 1.937 .938 6 $128.56 Buy Now
KM-12448 2.000 1.000 6 $129.18 Buy Now
KM-12565 2.062 1.063 6 $134.56 Buy Now
KM-12446 2.125 1.125 6 $139.94 Buy Now
KM-12433 2.188 1.188 6 $145.34 Buy Now
KM-12444 2.250 1.250 6 $150.72 Buy Now
KM-12456 2.313 1.313 6 $156.10 Buy Now
KM-12442 2.375 1.375 6 $161.48 Buy Now
KM-12441 2.438 1.438 3 $166.86 Buy Now
KM-12440 2.500 1.500 3 $172.24 Buy Now
KM-12449 2.563 1.563 3 $177.62 Buy Now
KM-11985 2.625 1.625 3 $183.02 Buy Now
KM-12398 2.688 1.688 3 $188.40 Buy Now
KM-12639 2.750 1.750 3 $193.78 Buy Now
KM-11977 2.813 1.813 3 $199.16 Buy Now
KM-11978 2.875 1.875 3 $204.54 Buy Now
KM-11979 2.938 1.938 3 $209.92 Buy Now
KM-11980 3.000 2.000 3 $215.30 Buy Now
KM-11981 3.063 2.063 3 $220.68 Buy Now
KM-12599 3.125 2.125 3 $226.08 Buy Now
KM-11984 3.188 2.188 3 $231.46 Buy Now
KM-12723 3.250 2.250 3 $236.84 Buy Now
KM-11999 3.313 2.313 3 $242.22 Buy Now
KM-12625 3.375 2.375 3 $247.60 Buy Now
KM-11957 3.437 2.438 3 $252.98 Buy Now
KM-12611 3.500 2.500 3 $248.44 Buy Now
KM-12627 3.563 2.563 3 $253.60 Buy Now
KM-12722 3.625 2.625 3 $258.78 Buy Now
KM-12437 3.688 2.688 3 $258.78 Buy Now
KM-11982 3.750 2.750 3 $269.14 Buy Now
KM-12406 3.813 2.813 3 $274.30 Buy Now
KM-12439 3.875 2.875 3 $279.48 Buy Now
KM-12462 3.938 2.938 3 $284.48 Buy Now
KM-12461 4.000 3.000 3 $289.84 Buy Now
KM-12460 4.063 3.063 3 $295.02 Buy Now
KM-12459 4.125 3.125 3 $301.18 Buy Now
KM-12458 4.188 3.188 3 $305.36 Buy Now
KM-12421 4.250 3.250 3 $310.54 Buy Now
KM-12464 4.313 3.313 3 $315.72 Buy Now
KM-12434 4.375 3.375 3 $320.88 Buy Now
KM-12465 4.438 3.438 3 $326.06 Buy Now
KM-12405 4.500 3.500 3 $333.24 Buy Now
KM-12404 4.563 3.563 3 $336.42 Buy Now
KM-12403 4.625 3.625 3 $341.60 Buy Now
KM-12402 4.688 3.688 3 $346.76 Buy Now
KM-12401 4.750 3.750 3 $351.94 Buy Now
KM-12400 4.813 3.813 3 $357.12 Buy Now
KM-11831 4.875 3.875 3 $362.30 Buy Now
KM-12386 4.938 3.938 3 $367.46 Buy Now
KM-12473 5.000 4.000 3 $372.64 Buy Now
KM-12645 5.063 4.062 3 $377.82 Buy Now
KM-12436 5.125 4.125 3 $383.00 Buy Now
KM-12435 5.188 4.188 3 $388.18 Buy Now
KM-12467 5.250 4.250 3 $393.34 Buy Now
KM-12443 5.312 4.313 3 $398.52 Buy Now
KM-12445 5.375 4.375 3 $403.70 Buy Now
KM-12476 5.437 4.438 3 $408.88 Buy Now
KM-12463 5.500 4.500 3 $414.06 Buy Now
KM-12474 5.563 4.563 3 $419.22 Buy Now
KM-12438 5.625 4.625 3 $424.40 Buy Now
KM-12472 5.688 4.688 3 $429.58 Buy Now
KM-12471 5.750 4.750 3 $434.76 Buy Now
KM-12470 5.812 4.813 3 $439.92 Buy Now
KM-12457 5.875 4.875 3 $446.28
KM-12468 5.937 4.938 3 $450.28 Buy Now
KM-12480 6.000 5.000 3 $455.46 Buy Now
KM-12466 6.063 5.063 3 $460.64 Buy Now
KM-12475 6.125 5.125 3 $465.80 Buy Now
KM-12884 6.187 5.188 3 $470.98 Buy Now
KM-12876 6.250 5.250 3 $476.16 Buy Now
KM-12877 6.313 5.313 3 $481.34 Buy Now
KM-12878 6.375 5.375 3 $486.50 Buy Now
KM-12879 6.438 5.438 3 $491.68 Buy Now
KM-12880 6.500 5.500 3 $496.86 Buy Now
KM-12881 6.563 5.563 3 $502.04 Buy Now
KM-12623 6.625 5.625 3 $507.22 Buy Now
KM-12883 6.688 5.688 3 $512.38 Buy Now
KM-12986 6.750 5.750 3 $517.56 Buy Now
KM-12900 6.813 5.813 3 $522.74 Buy Now
KM-12886 6.875 5.875 3 $527.92 Buy Now
KM-12872 6.938 5.938 3 $533.08 Buy Now
KM-12888 7.000 6.000 3 $538.26 Buy Now
KM-12889 7.063 6.063 3 $565.18 Buy Now
KM-12890 7.125 6.125 3 $570.56 Buy Now
KM-12891 7.187 6.188 3 $575.94 Buy Now
KM-12882 7.250 6.250 3 $581.32 Buy Now
KM-11820 7.312 6.313 3 $586.70 Buy Now
KM-11830 7.375 6.375 3 $592.10 Buy Now
KM-11829 7.438 6.438 3 $597.48 Buy Now
KM-11828 7.500 6.500 3 $602.86 Buy Now
KM-11827 7.562 6.563 3 $608.24 Buy Now
KM-11825 7.625 6.625 3 $613.62 Buy Now
KM-11814 7.687 6.688 3 $619.00 Buy Now
KM-11823 7.750 6.750 3 $624.38 Buy Now
KM-12875 7.813 6.813 3 $629.78 Buy Now
KM-11821 7.875 6.875 3 $635.16 Buy Now
KM-12874 7.938 6.938 3 $640.54 Buy Now
KM-11819 8.000 7.000 3 $645.92 Buy Now
KM-11818 8.063 7.063 3 $651.30 Buy Now
KM-11817 8.125 7.125 3 $656.68 Buy Now
KM-11816 8.188 7.188 3 $662.06 Buy Now
KM-12945 8.250 7.250 3 $667.44 Buy Now
KM-12870 8.313 7.313 3 $672.84 Buy Now
KM-12894 8.375 7.375 3 $678.22 Buy Now
KM-11833 8.437 7.438 3 $683.60 Buy Now
KM-12838 8.500 7.500 3 $688.98 Buy Now
KM-12892 8.563 7.563 3 $694.36 Buy Now
KM-13372 8.625 7.625 3 $699.74 Buy Now
KM-13151 8.688 7.688 3 $705.12 Buy Now
KM-13357 8.750 7.750 3 $710.50 Buy Now
KM-13358 8.813 7.813 3 $715.90 Buy Now
KM-13359 8.875 7.875 3 $721.28 Buy Now
KM-13360 8.938 7.938 3 $726.66 Buy Now
KM-13356 9.000 8.000 3 $732.04 Buy Now
KM-13362 9.063 8.063 3 $879.24 Buy Now
KM-12724 9.125 8.125 3 $885.66 Buy Now
KM-12787 9.188 8.188 3 $892.08 Buy Now
KM-12794 9.250 8.250 3 $898.48 Buy Now
KM-12801 9.312 8.313 3 $904.90 Buy Now
KM-12802 9.375 8.375 3 $911.32 Buy Now
KM-12808 9.438 8.438 3 $917.74 Buy Now
KM-12809 9.500 8.500 3 $924.16 Buy Now
KM-12754 9.563 8.563 3 $930.58 Buy Now
KM-13361 9.625 8.625 3 $937.00 Buy Now
KM-13245 9.687 8.688 3 $943.42 Buy Now
KM-12385 9.750 8.750 3 $949.84 Buy Now
KM-12895 9.813 8.813 3 $956.24 Buy Now
KM-12896 9.875 8.875 3 $962.66 Buy Now
KM-12897 9.937 8.938 3 $969.08 Buy Now
KM-12898 10.000 9.000 3 $975.50 Buy Now
KM-12899 10.062 9.063 3 $981.92 Buy Now
KM-12858 10.125 9.125 3 $988.34 Buy Now
KM-13364 10.187 9.188 3 $994.76 Buy Now
KM-13243 10.250 9.250 3 $1,001.18 Buy Now
KM-12893 10.313 9.313 3 $1,007.60 Buy Now
KM-13017 10.375 9.375 3 $1,014.00 Buy Now
KM-13367 10.437 9.438 3 $1,020.42 Buy Now
KM-13366 10.500 9.500 3 $1,026.84 Buy Now
KM-12996 10.563 9.563 3 $1,033.26 Buy Now
KM-12990 10.625 9.625 3 $1,039.68 Buy Now
KM-12694 10.688 9.688 3 $1,046.10 Buy Now
KM-12693 10.750 9.750 3 $1,052.52 Buy Now
KM-13260 10.813 9.813 3 $1,058.94 Buy Now
KM-12487 10.875 9.875 3 $1,065.36 Buy Now
KM-12527 10.937 9.938 3 $1,071.76 Buy Now
KM-12493 11.000 10.000 3 $1,078.18 Buy Now
KM-12491 11.062 10.063 3 $1,084.60 Buy Now
KM-12515 11.125 10.125 3 $1,091.02 Buy Now
KM-12483 11.188 10.188 3 $1,097.44 Buy Now
KM-12484 11.250 10.250 3 $1,103.86 Buy Now
KM-12506 11.312 10.313 3 $1,110.28 Buy Now
KM-12486 11.375 10.375 3 $1,116.70 Buy Now
KM-12524 11.437 10.438 3 $1,123.12 Buy Now
KM-12488 11.500 10.500 3 $1,129.52 Buy Now
KM-12489 11.625 10.625 3 $1,135.94 Buy Now
KM-12490 11.687 10.688 3 $1,142.36 Buy Now
KM-12504 11.750 10.750 3 $1,148.78 Buy Now
KM-12492 11.813 10.813 3 $1,155.20 Buy Now
KM-12481 11.875 10.875 3 $1,161.62 Buy Now
KM-12494 11.938 10.938 3 $1,168.04 Buy Now
KM-12485 12.000 11.000 3 $1,174.46 Buy Now
KM-12505 12.063 11.063 3 $1,180.88 Buy Now
KM-12399 12.125 11.125 3 $1,187.28 Buy Now
KM-12508 12.187 11.188 3 $1,193.70 Buy Now
KM-12509 12.250 11.250 3 $1,200.12 Buy Now
KM-12510 12.313 11.313 3 $1,206.54 Buy Now
KM-12511 12.375 11.375 3 $1,212.96 Buy Now
KM-12512 12.438 11.438 3 $1,219.38 Buy Now
KM-12513 12.500 11.500 3 $1,225.80 Buy Now
KM-12526 12.563 11.563 3 $1,232.22 Buy Now
KM-12516 12.625 11.625 3 $1,238.64 Buy Now
KM-12525 12.688 11.688 3 $1,245.04 Buy Now
KM-12518 12.750 11.750 3 $1,251.46 Buy Now
KM-12519 12.813 11.813 3 $1,257.88 Buy Now
KM-12520 12.875 11.875 3 $1,264.30 Buy Now
KM-12521 12.937 11.938 3 $1,270.72 Buy Now
KM-12522 13.000 12.000 3 $1,277.14 Buy Now
KM-12523 13.062 12.063 3 $1,283.56 Buy Now
KM-12497 13.125 12.125 3 $1,289.98 Buy Now
KM-12528 13.187 12.188 3 $1,296.40 Buy Now
KM-12601 13.250 12.250 3 $1,302.80 Buy Now
KM-12495 13.312 12.313 3 $1,309.22 Buy Now
KM-12975 13.375 12.375 3 $1,315.64 Buy Now
KM-12976 13.437 12.438 3 $1,322.06 Buy Now
KM-12977 13.500 12.500 3 $1,328.48 Buy Now
KM-12978 13.562 12.563 3 $1,334.90 Buy Now
KM-12979 13.625 12.625 3 $1,341.32 Buy Now
KM-12602 13.687 12.688 3 $1,347.74 Buy Now
KM-12973 13.750 12.750 3 $1,354.16 Buy Now
KM-12982 13.812 12.813 3 $1,360.56 Buy Now
KM-12987 13.875 12.875 3 $1,366.98 Buy Now
KM-12984 13.938 12.938 3 $1,373.40 Buy Now
KM-12985 14.000 13.000 3 $1,379.82 Buy Now
KM-13248 14.062 13.063 3 $1,386.24 Buy Now
KM-12960 14.125 13.125 3 $1,392.66 Buy Now
KM-13249 14.187 13.188 3 $1,399.08 Buy Now
KM-13250 14.250 13.250 3 $1,405.50 Buy Now
KM-13186 14.312 13.312 3 $1,411.92 Buy Now
KM-12981 14.375 13.375 3 $1,418.32 Buy Now
KM-12557 14.437 13.438 3 $1,424.74 Buy Now
KM-12558 14.500 13.500 3 $1,437.58 Buy Now
KM-12498 14.562 13.563 3 $1,444.00 Buy Now
KM-12499 14.625 13.625 3 $1,450.42 Buy Now
KM-12500 14.687 13.688 3 $1,456.84 Buy Now
KM-12482 14.750 13.750 3 $1,463.26 Buy Now
KM-12517 14.812 13.813 3 $1,469.68 Buy Now
KM-12554 14.875 13.875 3 $1,476.08 Buy Now
KM-12959 14.937 13.938 3 $1,482.50 Buy Now
KM-12556 15.000 14.000 3 $1,488.92 Buy Now
KM-12496 15.062 14.063 3 $1,495.34 Buy Now
KM-12419 15.125 14.125 3 $1,501.76 Buy Now
KM-12477 15.187 14.188 3 $1,508.18 Buy Now
KM-12478 15.250 14.250 3 $1,514.60 Buy Now
KM-12479 15.312 14.313 3 $1,521.02 Buy Now
KM-12969 15.375 14.375 3 $1,527.44 Buy Now
KM-12970 15.437 14.438 3 $1,533.84 Buy Now
KM-12971 15.500 14.500 3 $1,540.26 Buy Now
KM-12555 15.563 14.562 3 $1,546.68 Buy Now
KM-12416 15.625 14.625 3 $1,553.10 Buy Now
KM-12424 15.687 14.688 3 $1,559.52 Buy Now
KM-12423 15.750 14.750 3 $1,562.35 Buy Now
KM-12422 15.812 14.813 3 $1,565.94 Buy Now
KM-12409 15.875 14.875 3 $1,572.36 Buy Now
KM-12420 15.937 14.938 3 $1,578.78 Buy Now
KM-12432 16.000 15.000 3 $1,585.20 Buy Now
KM-12507 16.062 15.063 3 $1,591.60 Buy Now
KM-12417 16.125 15.125 3 $1,598.02 Buy Now
KM-12427 16.187 15.188 3 $1,604.44 Buy Now
KM-12415 16.250 15.250 3 $1,610.86 Buy Now
KM-12414 16.312 15.313 3 $1,617.28 Buy Now
KM-12413 16.375 15.375 3 $1,623.70 Buy Now
KM-12412 16.437 15.438 3 $1,630.12 Buy Now
KM-12411 16.500 15.500 3 $1,636.54 Buy Now
KM-12503 16.562 15.563 3 $1,642.96 Buy Now
KM-12407 16.625 15.625 3 $1,649.36 Buy Now
KM-12418 16.687 15.688 3 $1,655.78 Buy Now
KM-12387 16.750 15.750 3 $1,662.20 Buy Now
KM-12396 16.812 15.813 3 $1,668.62 Buy Now
KM-12408 16.875 15.875 3 $1,681.46 Buy Now
KM-12394 16.937 15.938 3 $1,687.88 Buy Now
KM-12393 17.000 16.000 3 $1,694.30 Buy Now
KM-12392 17.062 16.063 3 $1,700.72 Buy Now
KM-12391 17.125 16.125 3 $1,707.12 Buy Now
KM-12390 17.187 16.188 3 $1,713.54 Buy Now
KM-12425 17.250 16.250 3 $1,719.96 Buy Now
KM-12388 17.312 16.313 3 $1,726.38 Buy Now
KM-12426 17.375 16.375 3 $1,732.80 Buy Now
KM-12395 17.437 16.438 3 $1,739.22 Buy Now
KM-12397 17.500 16.500 3 $1,745.64 Buy Now
KM-12431 17.562 16.563 3 $1,752.06 Buy Now
KM-12430 17.625 16.625 3 $1,758.48 Buy Now
KM-12429 17.687 16.688 3 $1,764.88 Buy Now
KM-12428 17.750 16.750 3 $1,771.30 Buy Now
KM-12550 17.812 16.813 3 $1,777.72 Buy Now
KM-12389 17.875 16.875 3 $1,784.14 Buy Now
KM-12566 17.937 16.938 3 $1,790.56 Buy Now
KM-12469 18.000 17.000 3 $1,796.98 Buy Now
KM-12574 18.062 17.063 3 $1,803.40 Buy Now
KM-12573 18.125 17.125 3 $1,809.82 Buy Now
KM-12572 18.187 17.188 3 $1,816.24 Buy Now
KM-12571 18.250 17.250 3 $1,822.64 Buy Now
KM-12570 18.312 17.313 3 $1,829.06 Buy Now
KM-12569 18.375 17.375 3 $1,835.48 Buy Now
KM-12541 18.437 17.438 3 $1,841.90 Buy Now
KM-12567 18.500 17.500 3 $1,848.32 Buy Now
KM-12539 18.562 17.563 3 $1,854.74 Buy Now
KM-12553 18.625 17.625 3 $1,861.16 Buy Now
KM-12564 18.687 17.688 3 $1,867.58 Buy Now
KM-12576 18.750 17.750 3 $1,874.00 Buy Now
KM-12562 18.937 17.938 3 $1,880.40 Buy Now
KM-12561 19.000 18.000 3 $1,886.82 Buy Now
KM-12560 19.062 18.063 3 $1,893.24 Buy Now
KM-12559 19.125 18.125 3 $1,899.66 Buy Now
KM-12568 19.187 18.188 3 $1,906.08 Buy Now
KM-12529 19.250 18.250 3 $1,912.50 Buy Now
KM-13217 19.312 18.313 3 $1,918.92 Buy Now
KM-12549 19.375 18.375 3 $1,925.34 Buy Now
KM-12548 19.437 18.438 3 $1,931.76 Buy Now
KM-12547 19.500 18.500 3 $1,938.16 Buy Now
KM-12546 19.562 18.563 3 $1,944.58 Buy Now
KM-12545 19.625 18.625 3 $1,963.84 Buy Now
KM-12544 19.687 18.688 3 $1,970.26 Buy Now
KM-12575 19.750 18.750 3 $1,976.68 Buy Now
KM-12542 19.812 18.812 3 $1,983.10 Buy Now
KM-12551 19.875 18.875 3 $1,989.52 Buy Now
KM-12540 19.937 18.938 3 $1,995.92 Buy Now
KM-12552 20.000 19.000 3 $2,002.34 Buy Now







nominal inches,
diameter

plus or minus (±) tolerance, inches

ID inside diameter

OD outside diameter

steel
mandrel

built-up
mandrel

.125" -.749"

.003"

-

.005"

.750" - 1.999"

.004"

-

.005"

2.000" - 4.000"

.006"

-

.008"



*turned

*as wound

4.001" - 12.000"

.010"

-

.025"

plus only

12.001" - 18.000"

.030"

.060"

.030"

plus only

18.001" - 24.000"

.040"

.075"

.035"

plus only

24.001" - 48.000"

.060"

.090"

.040"

plus only

*Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request)
