G7 Glass Reinforced Silicone Tubes - .093" Wall Thickness

G7 Tubes .093 Inch Wall

G7 Tube Glass Reinforced Silicone - natural (cream to white)

Technical Data Sheet    Chemical Resistance Chart
Composed of a continuous glass woven cloth base impregnated with a silicone resin binder, this grade has excellent heat and arc resistance. It has extremely good dielectric loss properties under dry conditions and good electrical properties under humid conditions, although the percentage of change is high.
NEMA G-7 certs to MIL-I-24768/17 GSG, IEC 60893-3 Type 6 SI GC 201

NEMA grade G7 Glass-Cloth Reinforced Silicone -- natural color is typically cream to white. Composed of a continuous glass woven clothe base impregnated with a silicone resin binder, this grade has excellent heat and arc resistance. (Silicone thermosetting resins are among the best of all polymer materials in resistance to temperature. Hence, silicone is broadly used for high temperature electronic applications requiring low electrical losses. Silicone isn't as strong as epoxies and phenolics upon aging at lower temperatures but is stronger upon aging over 400° F.) G7 has extremely good dielectric loss properties under dry conditions and good electrical properties under humid conditions, although the percentage of change is high.

G7 Sheets    G7 Rods



Select G7 Tube Wall Thickness

.031" .187" .750"
.062" .250" 1.00"
.093" .375"
.125" .500"



G7 Tubes - .093" Wall Thickness
Stock # OD Inch ID Inch Min. Feet to Order  Price/Ft Purchase Online
KM-1758 .375 .187 9 $38.75 Buy Now
KM-1761 .438 .250 9 $41.10 Buy Now
KM-1764 .500 .312 9 $44.15 Buy Now
KM-1767 .563 .375 9 $48.13 Buy Now
KM-1770 .625 .437 9 $38.88 Buy Now
KM-1773 .688 .500 15 $23.50 Buy Now
KM-11682 .750 .563 15 $24.45 Buy Now
KM-1782 .813 .625 15 $26.23 Buy Now
KM-13305 .875 .688 15 $27.30 Buy Now
KM-13328 .938 .750 15 $28.83 Buy Now
KM-13346 1.000 .813 12 $29.55 Buy Now
KM-1794 1.063 .875 12 $30.83 Buy Now
KM-13363 1.125 .938 12 $32.83 Buy Now
KM-1799 1.187 1.000 12 $33.98 Buy Now
KM-13341 1.250 1.063 12 $35.00 Buy Now
KM-13342 1.313 1.125 12 $36.90 Buy Now
KM-13343 1.375 1.188 9 $37.80 Buy Now
KM-13344 1.438 1.250 9 $39.65 Buy Now
KM-13345 1.500 1.313 9 $40.40 Buy Now
KM-13355 1.562 1.375 9 $42.20 Buy Now
KM-13347 1.625 1.438 9 $42.80 Buy Now
KM-13339 1.688 1.500 9 $44.55 Buy Now
KM-13349 1.750 1.563 9 $46.30 Buy Now
KM-13350 1.813 1.625 9 $46.70 Buy Now
KM-13351 1.875 1.688 9 $48.40 Buy Now
KM-13352 1.938 1.750 9 $50.10 Buy Now
KM-13353 2.000 1.813 9 $50.33 Buy Now
KM-13354 2.063 1.875 9 $51.98 Buy Now
KM-13380 2.125 1.938 6 $53.63 Buy Now
KM-13406 2.188 2.000 6 $53.65 Buy Now
KM-13365 2.250 2.063 6 $55.25 Buy Now
KM-13392 2.313 2.125 6 $56.85 Buy Now
KM-13393 2.375 2.188 6 $56.68 Buy Now
KM-13394 2.438 2.250 6 $58.23 Buy Now
KM-13395 2.500 2.313 6 $59.78 Buy Now
KM-13396 2.563 2.375 6 $61.33 Buy Now
KM-13407 2.625 2.438 6 $62.88 Buy Now
KM-13398 2.688 2.500 6 $64.43 Buy Now
KM-13390 2.750 2.563 6 $66.00 Buy Now
KM-13400 2.813 2.625 6 $67.55 Buy Now
KM-13401 2.875 2.688 6 $69.10 Buy Now
KM-13402 2.938 2.750 6 $70.65 Buy Now
KM-13403 3.000 2.813 6 $72.20 Buy Now
KM-13404 3.063 2.875 6 $73.75 Buy Now
KM-13405 3.125 2.938 6 $75.30 Buy Now
KM-13382 3.188 3.000 6 $76.85 Buy Now
KM-13399 3.250 3.063 6 $78.40 Buy Now
KM-13397 3.313 3.125 6 $77.48 Buy Now
KM-13374 3.375 3.188 6 $78.98 Buy Now
KM-13375 3.438 3.250 6 $80.48 Buy Now
KM-13376 3.500 3.313 6 $81.98 Buy Now
KM-13377 3.563 3.375 6 $83.48 Buy Now
KM-13378 3.625 3.438 6 $84.98 Buy Now
KM-13379 3.688 3.500 6 $86.50 Buy Now
KM-13389 3.750 3.563 6 $88.00 Buy Now
KM-13381 3.813 3.625 6 $89.50 Buy Now
KM-13373 3.875 3.688 6 $91.00 Buy Now
KM-13383 3.938 3.750 6 $92.50 Buy Now
KM-13384 4.000 3.813 6 $90.98 Buy Now
KM-13385 4.063 3.875 6 $92.43 Buy Now
KM-13386 4.125 3.938 6 $93.90 Buy Now
KM-13387 4.188 4.000 6 $95.35 Buy Now
KM-13388 4.250 4.063 6 $96.80 Buy Now
KM-13322 4.313 4.125 6 $98.25 Buy Now
KM-13271 4.375 4.188 6 $99.70 Buy Now
KM-13340 4.438 4.250 6 $101.18 Buy Now
KM-13289 4.500 4.313 6 $102.63 Buy Now
KM-13290 4.563 4.375 6 $104.08 Buy Now
KM-13291 4.625 4.438 6 $105.53 Buy Now
KM-13292 4.688 4.500 6 $107.00 Buy Now
KM-13293 4.750 4.563 6 $108.45 Buy Now
KM-13303 4.813 4.625 3 $109.90 Buy Now
KM-13295 4.875 4.688 3 $111.35 Buy Now
KM-13287 4.938 4.750 6 $112.80 Buy Now
KM-13297 5.000 4.813 3 $114.28 Buy Now
KM-13476 5.063 4.875 3 $115.73 Buy Now
KM-13298 5.125 4.938 3 $117.18 Buy Now
KM-13391 5.188 5.000 3 $118.63 Buy Now
KM-13300 5.250 5.063 3 $120.10 Buy Now
KM-13301 5.313 5.125 3 $121.55 Buy Now
KM-13302 5.375 5.188 3 $123.00 Buy Now
KM-13279 5.437 5.250 3 $124.45 Buy Now
KM-13277 5.500 5.313 3 $125.93 Buy Now
KM-13294 5.563 5.375 3 $127.38 Buy Now
KM-13272 5.625 5.438 3 $128.83 Buy Now
KM-13273 5.688 5.500 3 $130.28 Buy Now
KM-13274 5.750 5.563 3 $131.73 Buy Now
KM-13275 5.813 5.625 3 $133.20 Buy Now
KM-13276 5.875 5.688 3 $134.65 Buy Now
KM-13286 5.938 5.750 3 $136.10 Buy Now
KM-13278 6.000 5.813 3 $137.55 Buy Now
KM-13270 6.063 5.875 3 $139.03 Buy Now
KM-13280 6.125 5.938 3 $140.48 Buy Now
KM-13281 6.188 6.000 3 $141.93 Buy Now
KM-13282 6.250 6.063 3 $143.38 Buy Now
KM-13283 6.313 6.125 3 $144.83 Buy Now
KM-13284 6.375 6.188 3 $146.30 Buy Now
KM-13285 6.438 6.250 3 $147.75 Buy Now
KM-13311 6.500 6.313 3 $149.20 Buy Now
KM-13337 6.563 6.375 3 $150.65 Buy Now
KM-13296 6.625 6.438 3 $152.13 Buy Now
KM-13323 6.688 6.500 3 $153.58 Buy Now
KM-13324 6.750 6.563 3 $155.03 Buy Now
KM-13325 6.813 6.625 3 $156.48 Buy Now
KM-13326 6.875 6.688 3 $157.93 Buy Now
KM-13327 6.938 6.750 3 $159.40 Buy Now
KM-13338 7.000 6.813 3 $160.85 Buy Now
KM-13329 7.063 6.875 3 $162.30 Buy Now
KM-13321 7.125 6.938 3 $163.75 Buy Now
KM-13331 7.188 7.000 3 $165.23 Buy Now
KM-13332 7.250 7.063 3 $166.68 Buy Now
KM-13333 7.313 7.125 3 $168.13 Buy Now
KM-13334 7.375 7.188 3 $169.58 Buy Now
KM-13335 7.438 7.250 3 $171.05 Buy Now
KM-13336 7.500 7.313 3 $172.50 Buy Now
KM-13313 7.563 7.375 3 $173.95 Buy Now
KM-13330 7.625 7.438 3 $175.40 Buy Now
KM-13483 7.688 7.500 3 $176.85 Buy Now
KM-13484 7.750 7.563 3 $178.33 Buy Now
KM-13494 7.813 7.625 3 $179.78 Buy Now
KM-13486 7.875 7.688 3 $181.23 Buy Now
KM-13478 7.938 7.750 3 $182.68 Buy Now
KM-13488 8.000 7.813 3 $178.00 Buy Now
KM-13489 8.063 7.875 3 $179.40 Buy Now
KM-13490 8.125 7.938 3 $180.83 Buy Now
KM-13491 8.188 8.000 3 $182.23 Buy Now
KM-13492 8.250 8.063 3 $183.63 Buy Now
KM-13493 8.313 8.125 3 $185.03 Buy Now
KM-13470 8.375 8.188 3 $186.45 Buy Now
KM-13468 8.438 8.250 3 $187.85 Buy Now
KM-13477 8.500 8.313 3 $189.25 Buy Now
KM-13469 8.563 8.375 3 $190.68 Buy Now
KM-13461 8.625 8.438 3 $192.08 Buy Now
KM-13471 8.688 8.500 3 $193.48 Buy Now
KM-13472 8.750 8.563 3 $194.88 Buy Now
KM-13473 8.813 8.625 3 $196.30 Buy Now
KM-13527 8.875 8.688 3 $197.70 Buy Now
KM-13504 8.938 8.750 3 $199.10 Buy Now
KM-13502 9.000 8.813 3 $200.53 Buy Now
KM-13519 9.063 8.875 3 $369.03 Buy Now
KM-13510 9.125 8.938 3 $371.60 Buy Now
KM-13509 9.188 9.000 3 $374.18 Buy Now
KM-13508 9.250 9.063 3 $376.75 Buy Now
KM-13507 9.313 9.125 3 $379.33 Buy Now
KM-13506 9.375 9.188 3 $381.90 Buy Now
KM-13505 9.438 9.250 3 $384.45 Buy Now
KM-13495 9.500 9.313 3 $387.03 Buy Now
KM-13503 9.563 9.375 3 $389.60 Buy Now
KM-13511 9.625 9.438 3 $392.18 Buy Now
KM-13501 9.688 9.500 3 $394.75 Buy Now
KM-13500 9.750 9.563 3 $397.33 Buy Now
KM-13499 9.813 9.625 3 $399.90 Buy Now
KM-13498 9.875 9.688 3 $402.45 Buy Now
KM-13497 9.938 9.750 3 $405.03 Buy Now
KM-13426 10.000 9.813 3 $407.60 Buy Now
KM-13438 10.063 9.875 3 $410.18 Buy Now
KM-13439 10.125 9.938 3 $412.75 Buy Now
KM-13440 10.188 10.000 3 $415.33 Buy Now
KM-13441 10.250 10.063 3 $417.90 Buy Now
KM-13442 10.313 10.125 3 $420.48 Buy Now
KM-13417 10.375 10.188 3 $423.03 Buy Now
KM-13415 10.438 10.250 3 $425.60 Buy Now
KM-13433 10.500 10.313 3 $428.18 Buy Now
KM-13445 10.563 10.375 3 $430.75 Buy Now
KM-13409 10.625 10.438 3 $433.33 Buy Now
KM-13435 10.688 10.500 3 $435.90 Buy Now
KM-13446 10.750 10.563 3 $438.48 Buy Now
KM-13447 10.813 10.625 3 $441.03 Buy Now
KM-13448 10.875 10.688 3 $443.60 Buy Now
KM-13449 10.938 10.750 3 $446.18 Buy Now
KM-13450 11.000 10.813 3 $448.75 Buy Now
KM-13479 11.063 10.875 3 $451.33 Buy Now
KM-13452 11.125 10.938 3 $453.90 Buy Now
KM-13444 11.188 11.000 3 $456.00 Buy Now
KM-13454 11.250 11.063 3 $459.05 Buy Now
KM-13455 11.313 11.125 3 $461.60 Buy Now
KM-13456 11.375 11.188 3 $464.18 Buy Now
KM-13457 11.437 11.250 3 $466.75 Buy Now
KM-13458 11.500 11.313 3 $469.33 Buy Now
KM-13459 11.563 11.375 3 $471.90 Buy Now
KM-13460 11.625 11.438 3 $474.48 Buy Now
KM-13453 11.688 11.500 3 $477.05 Buy Now
KM-13480 11.750 11.563 3 $479.60 Buy Now
KM-13481 11.813 11.625 3 $482.18 Buy Now
KM-13482 11.875 11.688 3 $484.75 Buy Now
KM-13485 11.938 11.750 3 $487.33 Buy Now
KM-13463 12.000 11.813 3 $489.90 Buy Now
KM-13521 12.063 11.875 3 $492.48 Buy Now
KM-13464 12.125 11.938 3 $495.05 Buy Now
KM-13529 12.188 12.000 3 $497.60 Buy Now
KM-13465 12.250 12.063 3 $500.18 Buy Now
KM-13466 12.313 12.125 3 $502.75 Buy Now
KM-13467 12.375 12.188 3 $505.33 Buy Now
KM-13474 12.438 12.250 3 $507.90 Buy Now
KM-13475 12.500 12.312 3 $510.48 Buy Now
KM-13496 12.563 12.375 3 $513.05 Buy Now
KM-13462 12.625 12.438 3 $515.63 Buy Now
KM-13487 12.688 12.500 3 $518.18 Buy Now
KM-13423 12.750 12.563 3 $520.75 Buy Now
KM-13422 12.813 12.625 3 $523.33 Buy Now
KM-13421 12.875 12.688 3 $525.90 Buy Now
KM-13420 12.937 12.750 3 $528.48 Buy Now
KM-13419 13.000 12.813 3 $531.05 Buy Now
KM-13418 13.062 12.875 3 $533.63 Buy Now
KM-13408 13.125 12.938 3 $536.18 Buy Now
KM-13416 13.187 13.000 3 $538.75 Buy Now
KM-13425 13.250 13.063 3 $541.33 Buy Now
KM-13513 13.312 13.125 3 $543.90 Buy Now
KM-13414 13.375 13.188 3 $546.48 Buy Now
KM-13514 13.437 13.250 3 $549.05 Buy Now
KM-13413 13.500 13.312 3 $551.63 Buy Now
KM-13412 13.562 13.375 3 $554.20 Buy Now
KM-13411 13.625 13.438 3 $556.75 Buy Now
KM-13410 13.687 13.500 3 $559.33 Buy Now
KM-13437 13.750 13.563 3 $561.90 Buy Now
KM-13436 13.812 13.625 3 $564.48 Buy Now
KM-13434 13.875 13.688 3 $567.05 Buy Now
KM-13443 13.938 13.750 3 $569.63 Buy Now
KM-13432 14.000 13.813 3 $572.20 Buy Now
KM-13431 14.062 13.875 3 $574.75 Buy Now
KM-13430 14.125 13.938 3 $577.33 Buy Now
KM-13429 14.187 14.000 3 $579.90 Buy Now
KM-13428 14.250 14.063 3 $582.48 Buy Now
KM-13427 14.312 14.125 3 $585.05 Buy Now
KM-13424 14.375 14.188 3 $587.63 Buy Now
KM-13515 14.437 14.250 3 $590.20 Buy Now
KM-13516 14.500 14.313 3 $592.78 Buy Now
KM-13517 14.562 14.375 3 $595.33 Buy Now
KM-13518 14.625 14.438 3 $597.90 Buy Now
KM-13528 14.687 14.500 3 $600.48 Buy Now
KM-13520 14.750 14.563 3 $603.05 Buy Now
KM-13512 14.812 14.625 3 $605.63 Buy Now
KM-13522 14.875 14.688 3 $608.20 Buy Now
KM-13523 14.937 14.750 3 $610.78 Buy Now
KM-13524 15.000 14.813 3 $613.33 Buy Now
KM-13525 15.062 14.875 3 $615.90 Buy Now
KM-13526 15.125 14.938 3 $618.48 Buy Now
KM-13299 15.187 15.000 3 $621.05 Buy Now
KM-13018 15.250 15.063 3 $623.63 Buy Now
KM-13085 15.312 15.125 3 $626.20 Buy Now
KM-13086 15.375 15.188 3 $628.78 Buy Now
KM-13087 15.437 15.250 3 $631.33 Buy Now
KM-13088 15.500 15.313 3 $633.90 Buy Now
KM-13089 15.563 15.375 3 $636.48 Buy Now
KM-13090 15.625 15.438 3 $639.05 Buy Now
KM-13100 15.687 15.500 3 $641.63 Buy Now
KM-13092 15.750 15.563 3 $644.20 Buy Now
KM-13084 15.812 15.625 3 $646.78 Buy Now
KM-13094 15.875 15.688 3 $649.35 Buy Now
KM-13095 15.937 15.750 3 $651.90 Buy Now
KM-13096 16.000 15.813 3 $654.48 Buy Now
KM-13097 16.062 15.875 3 $657.05 Buy Now
KM-13098 16.125 15.938 3 $659.63 Buy Now
KM-13076 16.187 16.000 3 $662.20 Buy Now
KM-13093 16.250 16.063 3 $664.78 Buy Now
KM-13091 16.312 16.125 3 $667.35 Buy Now
KM-13069 16.375 16.188 3 $669.90 Buy Now
KM-13070 16.437 16.250 3 $672.48 Buy Now
KM-13071 16.500 16.313 3 $675.05 Buy Now
KM-13072 16.562 16.375 3 $677.63 Buy Now
KM-13073 16.625 16.438 3 $680.20 Buy Now
KM-13083 16.687 16.500 3 $682.78 Buy Now
KM-13075 16.750 16.563 3 $685.35 Buy Now
KM-13068 16.812 16.625 3 $687.93 Buy Now
KM-13077 16.875 16.688 3 $690.48 Buy Now
KM-13078 16.937 16.750 3 $693.05 Buy Now
KM-13079 17.000 16.813 3 $695.63 Buy Now
KM-13080 17.062 16.875 3 $698.20 Buy Now
KM-13081 17.125 16.938 3 $700.78 Buy Now
KM-13082 17.187 17.000 3 $703.35 Buy Now
KM-13102 17.250 17.063 3 $705.93 Buy Now
KM-13127 17.312 17.125 3 $708.48 Buy Now
KM-13099 17.375 17.188 3 $711.05 Buy Now
KM-13120 17.437 17.250 3 $713.63 Buy Now
KM-13121 17.500 17.313 3 $716.20 Buy Now
KM-13122 17.562 17.375 3 $718.78 Buy Now
KM-13123 17.625 17.438 3 $721.35 Buy Now
KM-13124 17.687 17.500 3 $723.93 Buy Now
KM-13134 17.750 17.563 3 $726.50 Buy Now
KM-13126 17.812 17.625 3 $729.05 Buy Now
KM-13118 17.875 17.688 3 $731.63 Buy Now
KM-13128 17.937 17.750 3 $734.20 Buy Now
KM-13129 18.000 17.813 3 $736.78 Buy Now
KM-13130 18.062 17.875 3 $739.35 Buy Now
KM-13131 18.125 17.938 3 $741.93 Buy Now
KM-13132 18.187 18.000 3 $744.50 Buy Now
KM-13133 18.250 18.063 3 $747.05 Buy Now
KM-13110 18.312 18.125 3 $749.63 Buy Now
KM-13108 18.375 18.188 3 $752.20 Buy Now
KM-13125 18.437 18.250 3 $754.78 Buy Now
KM-13103 18.500 18.313 3 $757.35 Buy Now
KM-13104 18.562 18.375 3 $759.93 Buy Now
KM-13105 18.625 18.438 3 $762.50 Buy Now
KM-13030 18.687 18.500 3 $765.08 Buy Now
KM-13101 18.750 18.562 3 $767.63 Buy Now
KM-13106 18.812 18.625 3 $770.20 Buy Now
KM-13107 18.875 18.687 3 $772.78 Buy Now
KM-13117 18.937 18.750 3 $775.35 Buy Now
KM-13109 19.000 18.812 3 $777.93 Buy Now
KM-13024 19.062 18.875 3 $780.50 Buy Now
KM-13026 19.125 18.938 3 $783.08 Buy Now
KM-13029 19.250 19.062 3 $788.20 Buy Now
KM-13028 19.312 19.125 3 $790.78 Buy Now
KM-13027 19.375 19.187 3 $793.35 Buy Now
KM-13025 19.437 19.250 3 $795.93 Buy Now
KM-13033 19.500 19.312 3 $798.50 Buy Now
KM-13113 19.562 19.375 3 $801.08 Buy Now
KM-13111 19.625 19.437 3 $803.63 Buy Now
KM-13009 19.687 19.500 3 $806.20 Buy Now
KM-13112 19.750 19.562 3 $808.78 Buy Now
KM-13023 19.812 19.625 3 $811.35 Buy Now
KM-13114 19.875 19.687 3 $813.93 Buy Now
KM-13115 19.937 19.750 3 $816.50 Buy Now
KM-13116 20.000 19.812 3 $819.08 Buy Now





nominal inches,
diameter

plus or minus (±) tolerance, inches

ID inside diameter

OD outside diameter

steel
mandrel

built-up
mandrel

.125" -.749"

.003"

-

.005"

.750" - 1.999"

.004"

-

.005"

2.000" - 4.000"

.006"

-

.008"



*turned

*as wound

4.001" - 12.000"

.010"

-

.025"

plus only

12.001" - 18.000"

.030"

.060"

.030"

plus only

18.001" - 24.000"

.040"

.075"

.035"

plus only

24.001" - 48.000"

.060"

.090"

.040"

plus only

*Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request)
