G11-FR5 Tube High Temp. Glass Reinforced Epoxy - .750" Wall Thickness

G11 Fr5 Tube .750 inch wall

G11/FR5 Glass Reinforced Epoxy - natural (yellow green to amber) Technical Data Sheet
This grade is similar to G10/FR4, with the addition of a higher operating temperature and some improved mechanical strength at elevated temperatures.

The main difference between NEMA Grades G11 and FR5 is that FR5 is a fire retardant grade of G11. Therefore, FR5 can be safely substituted when G11 is called for, while G11 can never be substituted where FR5 is called for. (NEMA G-11 certs to MIL-I-24768/3 GEB, IEC 60893-3 Type 2 EP GC 203; FR5 certifies to Mil-I-24768/28 GEB-F.)

  Chemical Resistance Chart

.031" (1/32") Wall Thickness .062" (1/16")Wall Thickness .093" (3/32")Wall Thickness .125" (1/8")Wall Thickness .187" (3/16")Wall Thickness
.250" (1/4")Wall Thickness .375" (3/8")Wall Thickness .500" (1/2")Wall Thickness .750" (3/4")WallThickness 1.00" Wall Thickness (Max. Possible)



.750" Wall Thickness G11-Fr5 Tube
Stock # OD Inches ID Inches Price/Ft Min Feet to Order Purchase Online
KM-10499 2.000 0.500 $179.34 6 Buy Now
KM-10521 2.062 0.562 $188.30 6 Buy Now
KM-10520 2.125 0.625 $197.26 6 Buy Now
KM-10519 2.187 0.687 $206.22 6 Buy Now
KM-10518 2.250 0.750 $215.22 3 Buy Now
KM-10517 2.312 0.812 $224.18 6 Buy Now
KM-10507 2.375 0.875 $233.14 3 Buy Now
KM-10515 2.437 0.937 $242.10 3 Buy Now
KM-10523 2.500 1.000 $251.06 3 Buy Now
KM-10513 2.562 1.062 $260.05 3 Buy Now
KM-10512 2.625 1.125 $269.01 3 Buy Now
KM-10511 2.687 1.187 $277.97 3 Buy Now
KM-10510 2.750 1.250 $286.93 3 Buy Now
KM-10509 2.812 1.312 $295.89 3 Buy Now
KM-10406 2.875 1.375 $304.89 3 Buy Now
KM-10716 2.937 1.437 $313.85 3 Buy Now
KM-10442 3.000 1.500 $313.01 3 Buy Now
KM-10310 3.062 1.562 $321.72 3 Buy Now
KM-10309 3.125 1.625 $330.40 3 Buy Now
KM-10308 3.187 1.687 $339.12 3 Buy Now
KM-10307 3.250 1.750 $347.80 3 Buy Now
KM-10306 3.312 1.812 $356.51 3 Buy Now
KM-10305 3.375 1.875 $365.19 3 Buy Now
KM-10296 3.437 1.937 $373.87 3 Buy Now
KM-10303 3.500 2.000 $382.59 3 Buy Now
KM-10311 3.562 2.062 $391.27 3 Buy Now
KM-10301 3.625 2.125 $399.98 3 Buy Now
KM-10300 3.687 2.187 $408.66 3 Buy Now
KM-10299 3.750 2.250 $417.38 3 Buy Now
KM-10298 3.812 2.312 $426.06 3 Buy Now
KM-10297 3.875 2.375 $434.77 3 Buy Now
KM-10319 3.937 2.437 $443.45 3 Buy Now
KM-10351 4.000 2.500 $452.13 3 Buy Now
KM-10304 4.062 2.562 $475.23 3 Buy Now
KM-10356 4.125 2.625 $484.19 3 Buy Now
KM-10355 4.187 2.687 $493.19 3 Buy Now
KM-10354 4.250 2.750 $502.15 3 Buy Now
KM-10352 4.375 2.875 $520.07 3 Buy Now
KM-10353 4.312 2.812 $511.11 3 Buy Now
KM-10312 4.437 2.937 $529.03 3 Buy Now
KM-10350 4.500 3.000 $538.02 3 Buy Now
KM-10358 4.562 3.062 $546.98 3 Buy Now
KM-10318 4.625 3.125 $547.51 3 Buy Now
KM-10317 4.687 3.187 $556.36 3 Buy Now
KM-10316 4.750 3.250 $565.18 3 Buy Now
KM-10315 4.812 3.312 $574.00 3 Buy Now
KM-10314 4.875 3.375 $582.86 3 Buy Now
KM-10288 4.937 3.437 $591.68 3 Buy Now
KM-10357 5.000 3.500 $591.26 3 Buy Now
KM-10302 5.062 3.562 $599.97 3 Buy Now
KM-10278 5.125 3.625 $608.65 3 Buy Now
KM-10277 5.187 3.687 $607.71 3 Buy Now
KM-10276 5.250 3.750 $616.25 3 Buy Now
KM-10275 5.312 3.812 $624.82 3 Buy Now
KM-10274 5.375 3.875 $633.40 3 Buy Now
KM-10273 5.437 3.937 $641.94 3 Buy Now
KM-10264 5.500 4.000 $650.51 3 Buy Now
KM-10271 5.562 4.062 $659.05 3 Buy Now
KM-10279 5.625 4.125 $667.63 3 Buy Now
KM-10269 5.687 4.187 $676.17 3 Buy Now
KM-10268 5.750 4.250 $684.74 3 Buy Now
KM-10267 5.812 4.312 $693.28 3 Buy Now
KM-10266 5.875 4.375 $701.86 3 Buy Now
KM-10286 5.937 4.437 $710.43 3 Buy Now
KM-10270 6.000 4.500 $718.97 3 Buy Now
KM-10272 6.062 4.562 $727.55 3 Buy Now
KM-10294 6.125 4.625 $736.09 3 Buy Now
KM-10293 6.187 4.687 $744.66 3 Buy Now
KM-10292 6.250 4.750 $753.20 3 Buy Now
KM-10291 6.312 4.812 $773.85 3 Buy Now
KM-10290 6.375 4.875 $782.57 3 Buy Now
KM-10289 6.437 4.937 $791.25 3 Buy Now
KM-10280 6.500 5.000 $799.96 3 Buy Now
KM-10287 6.562 5.062 $808.64 3 Buy Now
KM-10295 6.625 5.125 $817.32 3 Buy Now
KM-10285 6.687 5.187 $826.04 3 Buy Now
KM-10284 6.750 5.250 $834.72 3 Buy Now
KM-10283 6.812 5.312 $843.43 3 Buy Now
KM-10282 6.875 5.375 $852.11 3 Buy Now
KM-10281 6.937 5.437 $860.83 3 Buy Now
KM-10373 7.000 5.500 $869.51 3 Buy Now
KM-10423 7.062 5.562 $878.19 3 Buy Now
KM-10313 7.125 5.625 $886.90 3 Buy Now
KM-10405 7.187 5.687 $895.58 3 Buy Now
KM-10404 7.250 5.750 $904.30 3 Buy Now
KM-10403 7.312 5.812 $912.98 3 Buy Now
KM-10402 7.375 5.875 $921.69 3 Buy Now
KM-10401 7.437 5.937 $930.37 3 Buy Now
KM-10392 7.500 6.000 $939.05 3 Buy Now
KM-10399 7.562 6.062 $947.77 3 Buy Now
KM-10407 7.625 6.125 $956.45 3 Buy Now
KM-10397 7.687 6.187 $965.16 3 Buy Now
KM-10396 7.750 6.250 $973.84 3 Buy Now
KM-10395 7.812 6.312 $982.56 3 Buy Now
KM-10394 7.875 6.375 $991.24 3 Buy Now
KM-10393 7.937 6.437 $999.92 3 Buy Now
KM-10415 8.000 6.500 $1,008.63 3 Buy Now
KM-10417 8.062 6.562 $1,017.31 3 Buy Now
KM-10400 8.125 6.625 $1,026.03 3 Buy Now
KM-10422 8.187 6.687 $1,034.71 3 Buy Now
KM-10421 8.250 6.750 $1,043.42 3 Buy Now
KM-10420 8.312 6.812 $1,052.10 3 Buy Now
KM-10419 8.375 6.875 $1,060.78 3 Buy Now
KM-10418 8.437 6.937 $1,069.50 3 Buy Now
KM-10408 8.500 7.000 $1,078.18 3 Buy Now
KM-10416 8.562 7.062 $1,086.89 3 Buy Now
KM-10424 8.625 7.125 $1,095.57 3 Buy Now
KM-10414 8.687 7.187 $1,104.29 3 Buy Now
KM-10413 8.750 7.250 $1,112.97 3 Buy Now
KM-10412 8.812 7.312 $1,121.65 3 Buy Now
KM-10411 8.875 7.375 $1,130.36 3 Buy Now
KM-10410 8.937 7.437 $1,139.04 3 Buy Now
KM-10409 9.000 7.500 $1,147.76 3 Buy Now
KM-10390 9.062 7.562 $1,156.44 3 Buy Now
KM-10365 9.125 7.625 $1,165.15 3 Buy Now
KM-10398 9.187 7.687 $1,173.83 3 Buy Now
KM-10372 9.250 7.750 $1,182.51 3 Buy Now
KM-10371 9.312 7.812 $1,191.23 3 Buy Now
KM-10370 9.375 7.875 $1,199.91 3 Buy Now
KM-10369 9.437 7.937 $1,280.62 3 Buy Now
KM-10368 9.500 8.000 $1,217.30 3 Buy Now
KM-10359 9.562 8.062 $1,226.02 3 Buy Now
KM-10366 9.625 8.125 $1,234.70 3 Buy Now
KM-10374 9.687 8.187 $1,243.38 3 Buy Now
KM-10364 9.750 8.250 $1,252.09 3 Buy Now
KM-10363 9.812 8.312 $1,260.77 3 Buy Now
KM-10362 9.875 8.375 $1,269.49 3 Buy Now
KM-10361 9.937 8.437 $1,278.17 3 Buy Now
KM-10360 10.000 8.500 $1,286.88 3 Buy Now
KM-10382 10.062 8.562 $1,336.06 3 Buy Now
KM-9782 10.125 8.625 $1,345.02 3 Buy Now
KM-10384 10.187 8.687 $1,353.98 3 Buy Now
KM-10367 10.250 8.750 $1,362.94 3 Buy Now
KM-10389 10.312 8.812 $1,371.93 3 Buy Now
KM-10388 10.375 8.875 $1,183.62 3 Buy Now
KM-10387 10.437 8.937 $1,389.85 3 Buy Now
KM-10386 10.500 9.000 $1,398.81 3 Buy Now
KM-10385 10.562 9.062 $1,407.77 3 Buy Now
KM-10375 10.625 9.125 $1,416.77 3 Buy Now
KM-10383 10.687 9.187 $1,425.73 3 Buy Now
KM-10391 10.750 9.250 $1,434.69 3 Buy Now
KM-10381 10.812 9.312 $1,443.65 3 Buy Now
KM-10380 10.875 9.375 $1,452.61 3 Buy Now
KM-10379 10.937 9.437 $1,461.60 3 Buy Now
KM-10378 11.000 9.500 $1,470.56 3 Buy Now
KM-10377 11.062 9.562 $1,479.52 3 Buy Now
KM-10376 11.125 9.625 $1,488.48 3 Buy Now
KM-8674 11.187 9.687 $1,497.44 3 Buy Now
KM-8673 11.250 9.750 $1,506.40 3 Buy Now
KM-8672 11.312 9.812 $1,515.40 3 Buy Now
KM-8671 11.375 9.875 $1,524.36 3 Buy Now
KM-8670 11.437 9.937 $1,533.32 3 Buy Now
KM-8669 11.500 10.000 $1,542.28 3 Buy Now
KM-8668 11.562 10.062 $1,551.24 3 Buy Now
KM-8667 11.625 10.125 $1,560.23 3 Buy Now
KM-8656 11.687 10.187 $1,569.19 3 Buy Now
KM-8665 11.750 10.250 $1,578.15 3 Buy Now
KM-8675 11.812 10.312 $1,587.11 3 Buy Now
KM-8663 11.875 10.375 $1,596.07 3 Buy Now
KM-8662 11.937 10.437 $1,605.07 3 Buy Now
KM-8661 12.000 10.500 $1,614.03 3 Buy Now
KM-8660 12.062 10.562 $1,622.99 3 Buy Now
KM-8659 12.125 10.625 $1,631.95 3 Buy Now
KM-8658 12.187 10.687 $1,640.91 3 Buy Now
KM-8684 12.250 10.750 $1,694.90 3 Buy Now
KM-8664 12.312 10.812 $1,658.86 3 Buy Now
KM-8666 12.375 10.875 $1,667.82 3 Buy Now
KM-8694 12.437 10.937 $1,676.78 3 Buy Now
KM-8693 12.500 11.000 $1,685.85 3 Buy Now
KM-8692 12.562 11.062 $1,694.74 3 Buy Now
KM-8691 12.625 11.125 $1,703.70 3 Buy Now
KM-8690 12.687 11.187 $1,772.66 3 Buy Now
KM-8689 12.750 11.250 $1,721.62 3 Buy Now
KM-8688 12.812 11.312 $1,730.58 3 Buy Now
KM-8687 12.875 11.375 $1,739.57 3 Buy Now
KM-8676 12.937 11.437 $1,748.53 3 Buy Now
KM-8685 13.000 11.500 $1,757.49 3 Buy Now
KM-8695 13.062 11.562 $1,766.45 3 Buy Now
KM-8683 13.125 11.625 $1,775.41 3 Buy Now
KM-8682 13.187 11.687 $1,784.37 3 Buy Now
KM-8681 13.250 11.750 $1,793.37 3 Buy Now
KM-8680 13.312 11.812 $1,802.33 3 Buy Now
KM-8679 13.375 11.875 $1,811.29 3 Buy Now
KM-8678 13.437 11.937 $1,820.25 3 Buy Now
KM-8677 13.500 12.000 $1,829.21 3 Buy Now
KM-8646 13.562 12.062 $1,838.20 3 Buy Now
KM-8617 13.625 12.125 $1,847.16 3 Buy Now
KM-8657 13.687 12.187 $1,856.12 3 Buy Now
KM-8633 13.750 12.250 $1,865.08 3 Buy Now
KM-8632 13.812 12.312 $1,874.04 3 Buy Now
KM-8631 13.875 12.375 $1,883.04 3 Buy Now
KM-8630 13.937 12.437 $1,892.00 3 Buy Now
KM-8629 14.000 12.500 $1,900.96 3 Buy Now
KM-8628 14.062 12.562 $1,909.92 3 Buy Now
KM-8627 14.125 12.625 $1,918.88 3 Buy Now
KM-8616 14.187 12.687 $1,927.87 3 Buy Now
KM-8625 14.250 12.750 $1,936.83 3 Buy Now
KM-8635 14.312 12.812 $1,945.79 3 Buy Now
KM-8623 14.375 12.875 $1,954.75 3 Buy Now
KM-8622 14.437 12.937 $1,963.71 3 Buy Now
KM-8621 14.500 13.000 $1,972.71 3 Buy Now
KM-8620 14.562 13.062 $1,981.67 3 Buy Now
KM-8619 14.625 13.125 $1,990.63 3 Buy Now
KM-8618 14.687 13.187 $1,999.59 3 Buy Now
KM-8644 14.750 13.250 $2,008.55 3 Buy Now
KM-8624 14.812 13.312 $2,017.54 3 Buy Now
KM-8626 14.875 13.375 $2,026.50 3 Buy Now
KM-8654 14.937 13.437 $2,035.46 3 Buy Now
KM-8653 15.000 13.500 $2,044.42 3 Buy Now
KM-8652 15.062 13.562 $2,053.38 3 Buy Now
KM-8651 15.125 13.625 $2,062.34 3 Buy Now
KM-8650 15.187 13.687 $2,071.34 3 Buy Now
KM-8649 15.250 13.750 $2,080.30 3 Buy Now
KM-8648 15.312 13.812 $2,089.26 3 Buy Now
KM-8647 15.375 13.875 $2,098.22 3 Buy Now
KM-8636 15.437 13.937 $2,107.18 3 Buy Now
KM-8645 15.500 14.000 $2,116.17 3 Buy Now
KM-8655 15.562 14.062 $2,125.13 3 Buy Now
KM-8643 15.625 14.125 $2,134.09 3 Buy Now
KM-8642 15.687 14.187 $2,143.05 3 Buy Now
KM-8641 15.750 14.250 $2,152.01 3 Buy Now
KM-8640 15.812 14.312 $2,161.01 3 Buy Now
KM-8639 15.875 14.375 $2,169.97 3 Buy Now
KM-8638 15.937 14.437 $2,178.93 3 Buy Now
KM-8714 16.000 14.500 $2,187.89 3 Buy Now
KM-8634 16.062 14.562 $2,196.85 3 Buy Now
KM-8686 16.125 14.625 $2,205.84 3 Buy Now
KM-8754 16.187 14.687 $2,214.80 3 Buy Now
KM-8753 16.250 14.750 $2,223.76 3 Buy Now
KM-8752 16.312 14.812 $2,232.72 3 Buy Now
KM-8751 16.375 14.875 $2,241.68 3 Buy Now
KM-8750 16.437 14.937 $2,250.68 3 Buy Now
KM-8749 16.500 15.000 $2,259.64 3 Buy Now
KM-8747 16.625 15.125 $2,268.60 3 Buy Now
KM-8748 16.562 15.062 $2,277.56 3 Buy Now
KM-8736 16.687 15.187 $2,286.52 3 Buy Now
KM-8745 16.750 15.250 $2,295.51 3 Buy Now
KM-8755 16.812 15.312 $2,304.47 3 Buy Now
KM-8743 16.875 15.375 $2,313.43 3 Buy Now
KM-8742 16.937 15.437 $2,322.39 3 Buy Now
KM-8741 17.000 15.500 $2,331.35 3 Buy Now
KM-8740 17.062 15.562 $2,340.31 3 Buy Now
KM-8739 17.125 15.625 $2,349.31 3 Buy Now
KM-8738 17.187 15.687 $2,358.27 3 Buy Now
KM-8764 17.250 15.750 $2,367.23 3 Buy Now
KM-8744 17.312 15.812 $2,376.19 3 Buy Now
KM-8746 17.375 15.875 $2,385.15 3 Buy Now
KM-8774 17.437 15.937 $2,394.14 3 Buy Now
KM-8773 17.500 16.000 $2,403.10 3 Buy Now
KM-8772 17.562 16.062 $2,412.06 3 Buy Now
KM-8771 17.625 16.125 $2,421.02 3 Buy Now
KM-8770 17.687 16.187 $2,429.98 3 Buy Now
KM-8769 17.750 16.250 $2,438.98 3 Buy Now
KM-8768 17.812 16.312 $2,447.94 3 Buy Now
KM-8767 17.875 16.375 $2,456.90 3 Buy Now
KM-8756 17.937 16.437 $2,465.86 3 Buy Now
KM-8765 18.000 16.500 $2,474.82 3 Buy Now
KM-8775 18.062 16.562 $2,483.81 3 Buy Now
KM-8763 18.125 16.625 $2,492.77 3 Buy Now
KM-8762 18.187 16.687 $2,501.73 3 Buy Now
KM-8761 18.250 16.750 $2,510.69 3 Buy Now
KM-8760 18.312 16.812 $2,519.65 3 Buy Now
KM-8759 18.375 16.875 $2,528.65 3 Buy Now
KM-8758 18.437 16.937 $2,537.61 3 Buy Now
KM-8757 18.500 17.000 $2,546.57 3 Buy Now
KM-8726 18.562 17.062 $2,551.53 3 Buy Now
KM-8697 18.625 17.125 $2,564.49 3 Buy Now
KM-8737 18.687 17.187 $2,573.48 3 Buy Now
KM-8713 18.750 17.250 $2,582.44 3 Buy Now
KM-8712 18.812 17.312 $2,591.40 3 Buy Now
KM-8711 18.875 17.375 $2,600.36 3 Buy Now
KM-8710 18.937 17.437 $2,609.32 3 Buy Now
KM-8709 19.000 17.500 $2,618.28 3 Buy Now
KM-8708 19.062 17.562 $2,627.28 3 Buy Now
KM-8707 19.125 17.625 $2,636.24 3 Buy Now
KM-8696 19.187 17.687 $2,645.20 3 Buy Now
KM-8705 19.250 17.750 $2,654.16 3 Buy Now
KM-8715 19.312 17.812 $2,663.12 3 Buy Now
KM-8703 19.375 17.875 $2,672.11 3 Buy Now
KM-8702 19.437 17.937 $2,681.07 3 Buy Now
KM-8701 19.500 18.000 $2,690.03 3 Buy Now
KM-8700 19.562 18.062 $2,698.99 3 Buy Now
KM-8699 19.625 18.125 $2,707.95 3 Buy Now
KM-8698 19.687 18.187 $2,716.95 3 Buy Now
KM-8724 19.750 18.250 $2,725.91 3 Buy Now
KM-8704 19.812 18.312 $2,734.87 3 Buy Now
KM-8706 19.875 18.375 $2,743.83 3 Buy Now
KM-8734 19.937 18.437 $2,752.79 3 Buy Now
KM-8733 20.000 18.500 $2,761.78 3 Buy Now









nominal inches,
diameter

plus or minus (±) tolerance, inches

ID inside diameter

OD outside diameter

steel
mandrel

built-up
mandrel

.125" -.749"

.003"

-

.005"

.750" - 1.999"

.004"

-

.005"

2.000" - 4.000"

.006"

-

.008"



*turned

*as wound

4.001" - 12.000"

.010"

-

.025"

plus only

12.001" - 18.000"

.030"

.060"

.030"

plus only

18.001" - 24.000"

.040"

.075"

.035"

plus only

24.001" - 48.000"

.060"

.090"

.040"

plus only

*Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request)
