G11/FR5 High TempG11FR5 High Temp. Glass Reinforced Epoxy Tube - .031" Wall Thickness

G11 FR5 Tubes .031 inch Wall

G11/FR5 Glass Reinforced Epoxy - natural (yellow green to amber) Technical Data Sheet
This grade is similar to G10/FR4, with the addition of a higher operating temperature and some improved mechanical strength at elevated temperatures.

The main difference between NEMA Grades G11 and FR5 is that FR5 is a fire retardant grade of G11. Therefore, FR5 can be safely substituted when G11 is called for, while G11 can never be substituted where FR5 is called for. (NEMA G-11 certs to MIL-I-24768/3 GEB, IEC 60893-3 Type 2 EP GC 203; FR5 certifies to Mil-I-24768/28 GEB-F.)

  Chemical Resistance Chart

.031" (1/32") Wall Thickness .062" (1/16")Wall Thickness .093" (3/32")Wall Thickness .125" (1/8")Wall Thickness .187" (3/16")Wall Thickness
.250" (1/4")Wall Thickness .375" (3/8")Wall Thickness .500" (1/2")Wall Thickness .750" (3/4")WallThickness 1.00" Wall Thickness (Max. Possible)



G11FR5 Tubes with a .031" Wall Thickness
Stock # OD inch ID Inch Price/Foot Min Feet Purchase
KM-1495 0.500 0.437 $19.99 27 Buy Now
KM-1499 0.562 0.500 $23.56 21 Buy Now
KM-1505 0.625 0.562 $25.20 36 Buy Now
KM-1510 0.687 0.625 $15.09 36 Buy Now
KM-1516K 0.750 0.687 $15.51 30 Buy Now
KM-1519K 0.812 0.750 $15.72 30 Buy Now
KM-8716 0.875 0.812 $16.07 30 Buy Now
KM-1515K 0.937 0.875 $16.94 15 Buy Now
KM-8735 1.000 0.937 $17.75 30 Buy Now
KM-1521 1.062 1.000 $18.17 30 Buy Now
KM-8722 1.125 1.062 $18.48 30 Buy Now
KM-8731 1.187 1.125 $19.11 30 Buy Now
KM-8720 1.250 1.187 $19.71 30 Buy Now
KM-8515 1.312 1.250 $20.27 30 Buy Now
KM-8718 1.375 1.312 $20.76 30 Buy Now
KM-8717 1.437 1.375 $21.25 30 Buy Now
KM-8606 1.500 1.437 $21.11 30 Buy Now
KM-8477 1.562 1.500 $21.46 30 Buy Now
KM-8510 1.625 1.562 $22.33 30 Buy Now
KM-8509 1.687 1.625 $22.61 30 Buy Now
KM-8508 1.750 1.687 $22.86 30 Buy Now
KM-8507 1.812 1.750 $23.70 30 Buy Now
KM-8496 1.875 1.812 $24.54 30 Buy Now
KM-8505 1.937 1.875 $24.68 30 Buy Now
KM-8721 2.000 1.937 $24.78 30 Buy Now







nominal inches,
diameter

plus or minus (±) tolerance, inches

ID inside diameter

OD outside diameter

steel
mandrel

built-up
mandrel

.125" -.749"

.003"

-

.005"

.750" - 1.999"

.004"

-

.005"

2.000" - 4.000"

.006"

-

.008"



*turned

*as wound

4.001" - 12.000"

.010"

-

.025"

plus only

12.001" - 18.000"

.030"

.060"

.030"

plus only

18.001" - 24.000"

.040"

.075"

.035"

plus only

24.001" - 48.000"

.060"

.090"

.040"

plus only

*Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request)
