PVC Type I Channels

Chemical Resistant, Machinable, Insulating, UL 94VO Rated Flame Retardant, Operating Temperature 32° to +140° F,  5' lengths. Grey

pvc u channels

PVC Type I, Rigid Grey U Channels
Stock # Thickness Inch T1 Outside Width Inch Height Inch Price Each Length Inch Purchase Online
Channel-501 0.040 0.268 0.250 $7.72 96 80 Pc Min.
Channel-509 0.040 0.392 0.500 $8.90 96 75 Pc Min.
Channel-513 0.062 0.500 0.625 $10.03 96 75 Pc Min.
Channel-517 0.062 0.620 0.750 $13.66 96 50 Pc Min.
Channel-343 0.060 0.510 0.590 $11.00 60 Buy Now
Channel-344 0.066 0.940 0.790 $16.20 60 Buy Now
Channel-505 0.080 0.330 0.375 $8.28 96 75 Pc Min.
Channel-504 0.080 0.410 0.375 $12.88 96 50 Pc Min.
Channel-508 0.080 0.472 0.500 $13.25 96 50 Pc Min.
Channel-345 0.080 0.944 0.290 $26.82 60 Buy Now
Channel-346 0.080 1.140 1.650 $31.82 60 Buy Now
Channel-348 0.080 2.510 1.460 $34.70 60 Buy Now
Channel-512 0.094 0.562 0.625 $14.75 96 50 Pc Min.
Channel-516 0.094 0.688 0.725 $15.57 96 50 Pc Min.
Channel-350 0.098 4.330 0.790 $46.66 60 Buy Now
Channel-347 0.137 1.870 0.790 $37.10 60 Buy Now
Channel-349 1.000 3.540 0.790 $40.14 60 Buy Now

Base and leg tolerances are + / - 10%. Length tolerance is + / - 1.00".



PVC Flexible U Channels, Clear Or Black
Stock # Wall Thickness Inch Inside Width Inch Height Inch Price Each Length Inch Minimum Order Pcs
Channel-500 0.040 0.188 0.250 $6.72 96 100
Channel-502 0.040 0.250 0.375 $7.10 96 100
Channel-506 0.040 0.312 0.500 $7.30 96 100
Channel-511 0.060 0.375 0.625 $8.55 96 75
Channel-515 0.060 0.500 0.750 $9.11 96 75
Channel-503 0.080 0.250 0.375 $8.05 96 80
Channel-507 0.080 0.312 0.500 $8.63 96 80
Channel-514 0.094 0.500 0.750 $10.63 96 75

Base and leg tolerances are ±10%. Length tolerance is ±1.00".
