Fiberglass GP03 Channels

High Strength, Non Conductive, Paintable, Operating Temperature: 0° to +285° F., UL 94VO Flame Retardant. Opaque Red.

Base tolerance is ±.040". Leg tolerance is ±.020".

Length tolerance is ±1.00". Straightness tolerance is .050" per ft.

U Channels GPO3

Fiberglass GP03 U Channels
Stock # Thickness Inch T1 Outside Width Inch Height Inch Length Inch Price Each Purchase Online
Channel-357 0.156 2.562 1.250 36 $26.08 Buy Now
Channel-358 0.187 3.660 2.562 36 $58.60 Buy Now
Channel-359 0.187 4.250 2.000 36 $66.28 Buy Now
Channel-360 0.187 4.750 1.630 36 $58.18 Buy Now
Channel-361 0.187 6.750 1.630 36 $93.06 Buy Now
Channel-362 0.187 6.500 2.750 36 $96.14 Buy Now
Channel-363 0.156 2.562 1.250 72 $43.44 Buy Now
Channel-364 0.187 3.660 2.562 72 $97.68 Buy Now
Channel-365 0.187 4.250 2.000 72 $110.50 Buy Now
Channel-366 0.187 4.750 1.630 72 $97.10 Buy Now
Channel-367 0.187 6.750 1.630 72 $152.28 Buy Now



High Temperature Fiberglass GPO-3 Channels

This polyply channel is UL94V-O flame rated with 28%-32% glass content. Maximum temperature +400° F, 50 Barcol Hardness.

Polyply High Temperature Fiberglass GPO-3

Special Order

Stock # Thickness T1 Outside Width Inside Radius Outside Radius Height Length Price Each
Channel-233 .093" 2.687" .044" .138" 1.375" 76" $52.92
Channel-234 .093" 10.00" .137" .234" 2.00" 65" $84.48
Channel-313 .125" 3.562" .080" .230" 1.625" 82" $63.80
Channel-310 .125" 3.75" .110" .170" 2.687" 82" $63.99
Channel-311 .125" 7.375" .083" .170" 1.625" 64" $111.93
Channel-308 .125" 8.187" .104" .215" 4.00" 54" $82.71
Channel-312 .125" 8.625" .085" .210" 2.00" 80" $112.06
Channel-309 .125" 9.625" .110" .170" 1.625" 54" $75.60
Channel-326 .156" 2.562" .075" .245" 1.25" 71" $50.09
Channel-325 .156" 3.062" .060" .220" 1.625" 75" $72.75
Channel-335 .187" 3.656" .040" .340" 2.562" 76" $101.03
Channel-337 .187" 4.25" .100" .325" 2.00" 76" $98.12
Channel-336 .187" 4.75" .070" .360" 1.625" 76" $96.22
Channel-338 .187" 6.75" .075" .300" 1.625" 82" $143.84
Channel-339 .250" 6.562" .120" .328" 2.75" 80" $188.63
