Canvas C Fabric Reinforced Phenolic Tubes .750" Wall Thickness

CE Canvas Tube .750 Inch Wall

Canvas C Fabric Reinforced Phenolic Tubes - natural (light tan to brown) Technical Data Sheet
This grade is composed of a continuous cotton woven cloth impregnated with a phenolic resin binder. This grade contains a medium weave canvas and is known primarily for it's mechanical properties. This grade is not recommended for primary insulation.

NEMA grades C  Canvas Cotton-Cloth Reinforced Phenolic -- natural color is typically light tan to brown. C grades are composed of a continuous cotton woven cloth impregnated with a phenolic resin binder. These grades contain a medium weave canvas and are known primarily for their mechanical properties. These grades are not recommended for primary electrical insulation.

NEMA C certs to Mil-I-13768/16 FBM, IEC 60893-3 Type 4, PF CC 201
  Chemical Resistance Chart

C  Tubes    C/CE Sheets  C/CE Bar Stock


Wall Thickness Options
.031" .062" .093" .125"
.187" .250" .375" .500"
.750" 1.00"




.750" Wall Thickness - Canvas Tubing
Stock # OD Inches ID Inches Min. Feet to Purchase  Price Per Foot Purchase Online
KM-17424 2.000 .500 6 $56.68 Buy Now
KM-17401 2.062 .562 6 $59.50 Buy Now
KM-17432 2.125 .625 6 $62.35 Buy Now
KM-17431 2.188 .687 6 $64.28 Buy Now
KM-17430 2.250 .750 6 $67.08 Buy Now
KM-17429 2.312 .812 6 $69.78 Buy Now
KM-17428 2.375 .875 6 $72.48 Buy Now
KM-17427 2.437 .937 6 $75.15 Buy Now
KM-17426 2.500 1.000 6 $77.85 Buy Now
KM-17425 2.562 1.062 6 $80.50 Buy Now
KM-17412 2.625 1.125 6 $83.18 Buy Now
KM-17423 2.688 1.187 6 $85.83 Buy Now
KM-17434 2.750 1.250 6 $88.48 Buy Now
KM-17421 2.812 1.312 6 $91.13 Buy Now
KM-17420 2.875 1.375 6 $93.75 Buy Now
KM-17419 2.937 1.437 6 $96.38 Buy Now
KM-17418 3.000 1.500 6 $99.00 Buy Now
KM-17417 3.062 1.562 6 $101.63 Buy Now
KM-17416 3.125 1.625 6 $104.23 Buy Now
KM-17415 3.188 1.687 3 $106.83 Buy Now
KM-17414 3.250 1.750 3 $109.40 Buy Now
KM-17413 3.312 1.812 3 $112.00 Buy Now
KM-17388 3.375 1.875 3 $114.58 Buy Now
KM-17354 3.437 1.937 3 $117.13 Buy Now
KM-17399 3.500 2.000 3 $119.70 Buy Now
KM-17364 3.562 2.062 3 $122.25 Buy Now
KM-17363 3.625 2.125 3 $124.80 Buy Now
KM-17362 3.687 2.187 3 $127.33 Buy Now
KM-17361 3.750 2.250 3 $129.88 Buy Now
KM-17360 3.812 2.312 3 $132.38 Buy Now
KM-16241 3.875 2.375 3 $134.90 Buy Now
KM-17359 3.937 2.437 3 $136.60 Buy Now
KM-17358 4.000 2.500 3 $139.28 Buy Now
KM-17357 4.062 2.562 3 $141.95 Buy Now
KM-17345 4.125 2.625 3 $144.63 Buy Now
KM-17355 4.187 2.687 3 $147.30 Buy Now
KM-17366 4.250 2.750 3 $150.00 Buy Now
KM-17353 4.312 2.812 3 $152.68 Buy Now
KM-17352 4.375 2.875 3 $155.35 Buy Now
KM-17351 4.437 2.937 3 $158.03 Buy Now
KM-17350 4.500 3.000 3 $160.70 Buy Now
KM-17349 4.562 3.062 3 $163.38 Buy Now
KM-17348 4.625 3.125 3 $166.05 Buy Now
KM-17347 4.687 3.187 3 $168.75 Buy Now
KM-17346 4.75 3.250 3 $171.43 Buy Now
KM-17377 4.812 3.312 3 $174.10 Buy Now
KM-17379 4.875 3.375 3 $176.78 Buy Now
KM-17356 4.937 3.437 3 $179.45 Buy Now
KM-17387 5.000 3.500 3 $182.13 Buy Now
KM-17386 5.062 3.562 3 $184.80 Buy Now
KM-17385 5.125 3.625 3 $187.48 Buy Now
KM-17384 5.187 3.687 3 $190.18 Buy Now
KM-17383 5.250 3.750 3 $192.85 Buy Now
KM-17382 5.312 3.812 3 $195.53 Buy Now
KM-17381 5.375 3.875 3 $198.20 Buy Now
KM-17380 5.437 3.937 3 $200.88 Buy Now
KM-2116 5.500 4.000 3 $203.55 Buy Now
KM-17378 5.562 4.062 3 $206.23 Buy Now
KM-17389 5.625 4.125 3 $208.93 Buy Now
KM-17376 5.688 4.187 3 $211.60 Buy Now
KM-17375 5.750 4.250 3 $214.28 Buy Now
KM-17374 5.812 4.312 3 $216.95 Buy Now
KM-17373 5.875 4.375 3 $219.93 Buy Now
KM-17372 5.938 4.438 3 $222.90 Buy Now
KM-2121 6.000 4.500 3 $225.90 Buy Now
KM-17370 6.063 4.562 3 $228.90 Buy Now
KM-17369 6.125 4.625 3 $231.90 Buy Now
KM-17234 6.187 4.687 3 $234.93 Buy Now
KM-17410 6.250 4.750 3 $237.95 Buy Now
KM-17257 6.312 4.812 3 $240.98 Buy Now
KM-17142 6.375 4.875 3 $244.00 Buy Now
KM-17141 6.437 4.937 3 $247.05 Buy Now
KM-2126 6.500 5.000 3 $276.18 Buy Now
KM-17139 6.562 5.062 3 $253.15 Buy Now
KM-17138 6.625 5.125 3 $256.23 Buy Now
KM-17137 6.688 5.187 3 $259.28 Buy Now
KM-17136 6.750 5.250 3 $262.38 Buy Now
KM-17135 6.812 5.313 3 $265.45 Buy Now
KM-17134 6.875 5.375 3 $268.55 Buy Now
KM-17122 6.938 5.437 3 $271.65 Buy Now
KM-2132 7.000 5.500 3 $274.75 Buy Now
KM-17143 7.062 5.562 3 $277.88 Buy Now
KM-17130 7.125 5.625 3 $281.00 Buy Now
KM-17129 7.187 5.687 3 $284.13 Buy Now
KM-17128 7.250 5.750 3 $287.25 Buy Now
KM-17127 7.312 5.812 3 $290.40 Buy Now
KM-17126 7.375 5.875 3 $293.55 Buy Now
KM-17125 7.437 5.937 3 $296.70 Buy Now
KM-2138 7.500 6.000 3 $299.88 Buy Now
KM-17123 7.562 6.062 3 $303.05 Buy Now
KM-17154 7.625 6.125 3 $306.23 Buy Now
KM-17156 7.688 6.187 3 $309.43 Buy Now
KM-17133 7.750 6.250 3 $313.03 Buy Now
KM-17164 7.812 6.312 3 $315.83 Buy Now
KM-17163 7.875 6.375 3 $318.60 Buy Now
KM-17162 7.938 6.437 3 $321.40 Buy Now
KM-17161 8.000 6.500 3 $324.20 Buy Now
KM-17160 8.062 6.562 3 $327.00 Buy Now
KM-17159 8.125 6.625 3 $329.80 Buy Now
KM-17158 8.188 6.687 3 $332.58 Buy Now
KM-17157 8.250 6.750 3 $335.38 Buy Now
KM-17144 8.312 6.812 3 $338.18 Buy Now
KM-17155 8.375 6.875 3 $340.98 Buy Now
KM-17166 8.437 6.938 3 $343.78 Buy Now
KM-17153 8.500 7.000 3 $346.55 Buy Now
KM-17152 8.562 7.062 3 $349.35 Buy Now
KM-17151 8.625 7.125 3 $352.15 Buy Now
KM-17150 8.688 7.187 3 $354.95 Buy Now
KM-17149 8.750 7.250 3 $357.75 Buy Now
KM-17148 8.812 7.312 3 $360.53 Buy Now
KM-17147 8.875 7.375 3 $363.33 Buy Now
KM-17146 8.938 7.437 3 $366.13 Buy Now
KM-17111 9.000 7.500 3 $368.93 Buy Now
KM-17165 9.062 7.562 3 $433.68 Buy Now
KM-17131 9.125 7.625 3 $436.75 Buy Now
KM-17098 9.188 7.687 3 $439.85 Buy Now
KM-17097 9.250 7.750 3 $442.93 Buy Now
KM-17096 9.312 7.812 3 $446.03 Buy Now
KM-17095 9.375 7.875 3 $449.10 Buy Now
KM-17094 9.437 7.937 3 $452.18 Buy Now
KM-17093 9.500 8.000 3 $455.28 Buy Now
KM-17092 9.563 8.062 3 $458.35 Buy Now
KM-17091 9.625 8.125 3 $461.40 Buy Now
KM-17090 9.688 8.187 3 $464.48 Buy Now
KM-17078 9.750 8.250 3 $467.55 Buy Now
KM-17088 9.812 8.312 3 $470.63 Buy Now
KM-17099 9.875 8.375 3 $473.68 Buy Now
KM-17086 9.937 8.437 3 $476.75 Buy Now
KM-17085 10.00 8.500 3 $479.80 Buy Now
KM-17084 10.062 8.562 3 $482.85 Buy Now
KM-17083 10.125 8.625 3 $485.90 Buy Now
KM-17082 10.187 8.687 3 $488.95 Buy Now
KM-17081 10.250 8.75 3 $492.00 Buy Now
KM-17080 10.313 8.812 3 $495.05 Buy Now
KM-17109 10.375 8.875 3 $498.10 Buy Now
KM-17087 10.437 8.937 3 $501.13 Buy Now
KM-17089 10.500 9.000 3 $504.18 Buy Now
KM-16210 10.563 9.062 3 $507.20 Buy Now
KM-17120 10.625 9.125 3 $510.23 Buy Now
KM-17119 10.688 9.187 3 $513.28 Buy Now
KM-17118 10.750 9.250 3 $515.50 Buy Now
KM-17117 10.813 9.312 3 $518.73 Buy Now
KM-17116 10.875 9.375 3 $521.93 Buy Now
KM-17115 10.937 9.437 3 $525.15 Buy Now
KM-17114 11.000 9.500 3 $528.38 Buy Now
KM-17113 11.062 9.562 3 $531.60 Buy Now
KM-17112 11.125 9.625 3 $534.83 Buy Now
KM-17100 11.188 9.687 3 $538.05 Buy Now
KM-17110 11.250 9.750 3 $541.28 Buy Now
KM-17121 11.313 9.813 3 $544.50 Buy Now
KM-17108 11.375 9.875 3 $547.70 Buy Now
KM-17107 11.437 9.937 3 $550.93 Buy Now
KM-17106 11.500 10.000 3 $554.15 Buy Now
KM-17105 11.562 10.062 3 $557.38 Buy Now
KM-17104 11.625 10.125 3 $560.60 Buy Now
KM-17103 11.687 10.187 3 $563.83 Buy Now
KM-17102 11.750 10.250 3 $567.05 Buy Now
KM-17941 11.812 10.312 3 $570.28 Buy Now
KM-17942 11.875 10.375 3 $573.48 Buy Now
KM-17943 11.937 10.437 3 $576.70 Buy Now
KM-17944 12.000 10.500 3 $579.93 Buy Now
KM-17913 12.062 10.562 3 $583.15 Buy Now
KM-17911 12.125 10.625 3 $586.38 Buy Now
KM-17933 12.187 10.687 3 $589.60 Buy Now
KM-17904 12.250 10.750 3 $592.83 Buy Now
KM-17905 12.313 10.812 3 $596.05 Buy Now
KM-17906 12.375 10.875 3 $599.25 Buy Now
KM-17907 12.437 10.937 3 $602.48 Buy Now
KM-17908 12.500 11.000 3 $605.70 Buy Now
KM-17909 12.562 11.062 3 $608.93 Buy Now
KM-17910 12.625 11.125 3 $612.15 Buy Now
KM-17923 12.687 11.187 3 $615.38 Buy Now
KM-17912 12.750 11.250 3 $618.60 Buy Now
KM-17902 12.812 11.312 3 $621.83 Buy Now
KM-17914 12.875 11.375 3 $625.03 Buy Now
KM-17168 12.937 11.437 3 $628.25 Buy Now
KM-17079 13.000 11.500 3 $631.48 Buy Now
KM-17145 13.062 11.562 3 $634.70 Buy Now
KM-17231 13.125 11.625 3 $637.93 Buy Now
KM-17230 13.187 11.687 3 $641.15 Buy Now
KM-17229 13.250 11.750 3 $644.38 Buy Now
KM-17228 13.312 11.812 3 $647.58 Buy Now
KM-17227 13.375 11.875 3 $650.80 Buy Now
KM-17226 13.437 11.937 3 $654.03 Buy Now
KM-17225 13.500 12.000 3 $657.25 Buy Now
KM-17224 13.562 12.062 3 $660.48 Buy Now
KM-17223 13.625 12.125 3 $663.70 Buy Now
KM-17211 13.687 12.187 3 $666.93 Buy Now
KM-17221 13.750 12.250 3 $670.15 Buy Now
KM-17232 13.812 12.312 3 $673.35 Buy Now
KM-17219 13.875 12.375 3 $676.58 Buy Now
KM-17218 13.937 12.437 3 $679.80 Buy Now
KM-17217 14.000 12.500 3 $683.03 Buy Now
KM-17216 14.062 12.562 3 $686.25 Buy Now
KM-17215 14.125 12.625 3 $689.48 Buy Now
KM-17214 14.187 12.687 3 $692.70 Buy Now
KM-17213 14.250 12.750 3 $695.93 Buy Now
KM-17212 14.312 12.813 3 $699.13 Buy Now
KM-17243 14.375 12.875 3 $702.35 Buy Now
KM-17245 14.437 12.937 3 $705.58 Buy Now
KM-17222 14.500 13.000 3 $708.80 Buy Now
KM-17253 14.562 13.062 3 $712.03 Buy Now
KM-17252 14.625 13.125 3 $715.25 Buy Now
KM-17251 14.687 13.187 3 $718.48 Buy Now
KM-17250 14.750 13.250 3 $721.70 Buy Now
KM-17249 14.812 13.312 3 $724.90 Buy Now
KM-17248 14.875 13.375 3 $728.13 Buy Now
KM-17247 14.937 13.437 3 $731.35 Buy Now
KM-17246 15.000 13.500 3 $734.58 Buy Now
KM-17233 15.062 13.562 3 $737.80 Buy Now
KM-17244 15.125 13.625 3 $741.03 Buy Now
KM-17255 15.187 13.687 3 $744.25 Buy Now
KM-17242 15.250 13.750 3 $747.48 Buy Now
KM-17241 15.312 13.812 3 $750.68 Buy Now
KM-17240 15.375 13.875 3 $753.90 Buy Now
KM-17239 15.437 13.937 3 $757.13 Buy Now
KM-17238 15.500 14.000 3 $760.35 Buy Now
KM-17237 15.562 14.062 3 $763.58 Buy Now
KM-17236 15.625 14.125 3 $766.80 Buy Now
KM-17235 15.687 14.187 3 $770.03 Buy Now
KM-17200 15.750 14.250 3 $773.25 Buy Now
KM-17254 15.812 14.312 3 $776.45 Buy Now
KM-17220 15.875 14.375 3 $779.68 Buy Now
KM-17187 15.937 14.437 3 $782.90 Buy Now
KM-17186 16.000 14.500 3 $786.13 Buy Now
KM-17185 16.062 14.562 3 $789.35 Buy Now
KM-17184 16.125 14.625 3 $792.58 Buy Now
KM-17183 16.187 14.687 3 $795.80 Buy Now
KM-17182 16.250 14.750 3 $799.03 Buy Now
KM-17181 16.312 14.812 3 $802.23 Buy Now
KM-17180 16.375 14.875 3 $805.45 Buy Now
KM-17179 16.437 14.937 3 $808.68 Buy Now
KM-17167 16.500 15.000 3 $811.90 Buy Now
KM-17177 16.562 15.062 3 $815.13 Buy Now
KM-17188 16.625 15.125 3 $818.35 Buy Now
KM-17175 16.687 15.187 3 $821.58 Buy Now
KM-17174 16.750 15.250 3 $824.80 Buy Now
KM-17173 16.812 15.312 3 $828.00 Buy Now
KM-17172 16.875 15.375 3 $831.23 Buy Now
KM-17171 16.937 15.437 3 $834.45 Buy Now
KM-17170 17.000 15.500 3 $837.68 Buy Now
KM-17169 17.062 15.562 3 $840.90 Buy Now
KM-17198 17.125 15.625 3 $844.13 Buy Now
KM-17176 17.187 15.687 3 $847.35 Buy Now
KM-17178 17.250 15.750 3 $850.55 Buy Now
KM-17209 17.312 15.812 3 $853.78 Buy Now
KM-17208 17.375 15.875 3 $857.00 Buy Now
KM-17207 17.437 15.937 3 $860.23 Buy Now
KM-17206 17.500 16.000 3 $863.45 Buy Now
KM-17205 17.562 16.062 3 $866.68 Buy Now
KM-17204 17.625 16.125 3 $869.90 Buy Now
KM-17203 17.687 16.187 3 $873.13 Buy Now
KM-17202 17.750 16.250 3 $876.33 Buy Now
KM-17201 17.812 16.312 3 $879.55 Buy Now
KM-17189 17.875 16.375 3 $882.78 Buy Now
KM-17199 17.937 16.437 3 $886.00 Buy Now
KM-17210 18.000 16.500 3 $889.23 Buy Now
KM-17197 18.062 16.562 3 $892.45 Buy Now
KM-17196 18.125 16.625 3 $895.68 Buy Now
KM-17195 18.187 16.687 3 $898.90 Buy Now
KM-17194 18.250 16.750 3 $902.10 Buy Now
KM-17193 18.312 16.812 3 $905.33 Buy Now
KM-17192 18.375 16.875 3 $908.55 Buy Now
KM-17191 18.437 16.937 3 $911.78 Buy Now
KM-17190 18.500 17.000 3 $915.00 Buy Now
KM-16654 18.562 17.062 3 $918.23 Buy Now
KM-16089 18.625 17.125 3 $921.45 Buy Now
KM-16833 18.687 17.187 3 $924.68 Buy Now
KM-16218 18.750 17.250 3 $927.88 Buy Now
KM-16217 18.812 17.312 3 $931.10 Buy Now
KM-16216 18.875 17.375 3 $934.33 Buy Now
KM-16215 18.937 17.437 3 $937.55 Buy Now
KM-16214 19.000 17.500 3 $940.78 Buy Now
KM-16213 19.062 17.562 3 $944.00 Buy Now
KM-16212 19.125 17.625 3 $947.23 Buy Now
KM-16211 19.187 17.687 3 $950.45 Buy Now
KM-16199 19.250 17.750 3 $953.65 Buy Now
KM-16209 19.312 17.812 3 $956.88 Buy Now
KM-16220 19.375 17.875 3 $960.10 Buy Now
KM-16207 19.437 17.937 3 $963.33 Buy Now
KM-16206 19.500 18.000 3 $966.55 Buy Now
KM-16205 19.562 18.062 3 $969.78 Buy Now
KM-16204 19.625 18.125 3 $973.00 Buy Now
KM-16203 19.687 18.187 3 $976.23 Buy Now
KM-16202 19.750 18.250 3 $979.43 Buy Now
KM-16201 19.812 18.312 3 $982.65 Buy Now
KM-16200 19.875 18.375 3 $985.88 Buy Now
KM-16231 19.937 18.437 3 $989.10 Buy Now
KM-16233 20.000 18.500 3 $992.33 Buy Now



nominal inches,
diameter

plus or minus (±) tolerance, inches

ID inside diameter

OD outside diameter

steel
mandrel

built-up
mandrel

.125" -.749"

.003"

-

.005"

.750" - 1.999"

.004"

-

.005"

2.000" - 4.000"

.006"

-

.008"



*turned

*as wound

4.001" - 12.000"

.010"

-

.025"

plus only

12.001" - 18.000"

.030"

.060"

.030"

plus only

18.001" - 24.000"

.040"

.075"

.035"

plus only

24.001" - 48.000"

.060"

.090"

.040"

plus only

*Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request)
