Canvas C  Fabric Reinforced Phenolic  Tubes .375" Wall Thickness

 CE Canvas Tube .375 Inch Wall

Canvas C  Fabric Reinforced Phenolic Tubes - natural (light tan to brown) Technical Data Sheet
This grade is composed of a continuous cotton woven cloth impregnated with a phenolic resin binder. This grade contains a medium weave canvas and is known primarily for it's mechanical properties. This grade is not recommended for primary insulation.

NEMA grades C Canvas Cotton-Cloth Reinforced Phenolic -- natural color is typically light tan to brown. C grades are composed of a continuous cotton woven cloth impregnated with a phenolic resin binder. These grades contain a medium weave canvas and are known primarily for their mechanical properties. These grades are not recommended for primary electrical insulation.

NEMA C certs to Mil-I-13768/16 FBM, IEC 60893-3 Type 4, PF CC 201
 Chemical Resistance Chart

C  Tubes    C/CE Sheets  C/CE Bar Stock


Wall Thickness Options
.031" .062" .093" .125"
.187" .250" .375" .500"
.750" 1.00"




.375" Wall Thickness - Canvas Tubes
Stock # OD Inches ID Inches Min. Feet to Purchase  Price Per Foot Purchase Online
KM-16154 1.250 .500 15 $22.28 Buy Now
KM-16141 1.312 .562 15 $23.80 Buy Now
KM-16140 1.375 .625 15 $25.30 Buy Now
KM-16139 1.437 .687 15 $26.78 Buy Now
KM-16138 1.500 .750 12 $28.25 Buy Now
KM-16137 1.562 .812 12 $29.73 Buy Now
KM-16136 1.625 .875 12 $31.18 Buy Now
KM-16135 1.688 .937 12 $32.63 Buy Now
KM-16134 1.750 1.000 12 $34.05 Buy Now
KM-16099 1.812 1.062 12 $35.48 Buy Now
KM-16153 1.875 1.125 12 $36.88 Buy Now
KM-16119 1.937 1.187 9 $38.28 Buy Now
KM-2061 2.000 1.250 9 $39.68 Buy Now
KM-16085 2.062 1.312 9 $41.05 Buy Now
KM-16084 2.125 1.375 9 $42.43 Buy Now
KM-16083 2.188 1.437 9 $43.78 Buy Now
KM-2065 2.250 1.500 9 $45.13 Buy Now
KM-16081 2.312 1.562 9 $46.45 Buy Now
KM-16080 2.375 1.625 9 $47.78 Buy Now
KM-16079 2.437 1.687 9 $49.10 Buy Now
KM-2070 2.500 1.750 9 $50.40 Buy Now
KM-16066 2.562 1.812 9 $51.70 Buy Now
KM-16076 2.625 1.875 9 $52.98 Buy Now
KM-16087 2.688 1.937 9 $54.25 Buy Now
KM-2075 2.750 2.000 6 $55.50 Buy Now
KM-16073 2.812 2.062 6 $56.75 Buy Now
KM-16072 2.875 2.125 6 $57.98 Buy Now
KM-16071 2.937 2.187 6 $59.20 Buy Now
KM-2080 3.000 2.250 6 $60.43 Buy Now
KM-16069 3.062 2.312 6 $61.63 Buy Now
KM-16068 3.125 2.375 6 $62.83 Buy Now
KM-16097 3.188 2.437 6 $64.00 Buy Now
KM-2085 3.250 2.500 6 $65.18 Buy Now
KM-16077 3.312 2.562 6 $66.50 Buy Now
KM-16108 3.375 2.625 6 $67.83 Buy Now
KM-16107 3.437 2.687 6 $69.15 Buy Now
KM-2090 3.500 2.750 6 $70.48 Buy Now
KM-16105 3.562 2.812 6 $71.80 Buy Now
KM-16104 3.625 2.875 6 $73.10 Buy Now
KM-16103 3.687 2.937 6 $74.43 Buy Now
KM-2095 3.750 3.000 6 $75.73 Buy Now
KM-16101 3.812 3.062 6 $77.03 Buy Now
KM-16100 3.875 3.125 6 $78.33 Buy Now
KM-16088 3.937 3.187 6 $79.63 Buy Now
KM-2100 4.000 3.250 6 $94.90 Buy Now
KM-16109 4.062 3.312 6 $82.20 Buy Now
KM-16096 4.125 3.375 6 $83.48 Buy Now
KM-16095 4.187 3.437 6 $84.75 Buy Now
KM-2105 4.250 3.500 6 $86.05 Buy Now
KM-16093 4.312 3.562 6 $87.30 Buy Now
KM-16092 4.375 3.625 6 $88.58 Buy Now
KM-16091 4.437 3.687 6 $89.85 Buy Now
KM-2110 4.500 3.750 6 $91.10 Buy Now
KM-16357 4.562 3.812 6 $92.38 Buy Now
KM-16000 4.625 3.875 6 $93.63 Buy Now
KM-16267 4.687 3.937 6 $94.88 Buy Now
KM-16606 4.750 4.000 6 $96.13 Buy Now
KM-16605 4.812 4.062 6 $97.38 Buy Now
KM-16604 4.875 4.125 6 $98.60 Buy Now
KM-16603 4.937 4.187 6 $99.85 Buy Now
KM-16602 5.000 4.250 6 $101.08 Buy Now
KM-16601 5.062 4.312 6 $102.30 Buy Now
KM-16600 5.125 4.375 6 $103.53 Buy Now
KM-16599 5.187 4.438 3 $104.75 Buy Now
KM-16598 5.250 4.500 3 $105.98 Buy Now
KM-16586 5.312 4.562 3 $107.45 Buy Now
KM-16596 5.375 4.625 3 $108.93 Buy Now
KM-16607 5.437 4.687 3 $110.43 Buy Now
KM-16594 5.500 4.750 3 $111.90 Buy Now
KM-16593 5.562 4.812 3 $113.40 Buy Now
KM-16592 5.625 4.875 3 $114.88 Buy Now
KM-16405 5.688 4.937 3 $116.38 Buy Now
KM-16591 5.750 5.000 3 $117.88 Buy Now
KM-16590 5.812 5.062 3 $119.38 Buy Now
KM-16589 5.875 5.125 3 $120.90 Buy Now
KM-16588 5.938 5.187 3 $122.40 Buy Now
KM-16587 6.000 5.250 3 $123.90 Buy Now
KM-16618 6.063 5.313 3 $125.43 Buy Now
KM-16620 6.125 5.375 3 $126.95 Buy Now
KM-16597 6.187 5.437 3 $128.48 Buy Now
KM-16628 6.250 5.500 3 $130.00 Buy Now
KM-16627 6.312 5.562 3 $131.53 Buy Now
KM-16626 6.375 5.625 3 $133.05 Buy Now
KM-16625 6.437 5.687 3 $134.58 Buy Now
KM-16624 6.500 5.750 3 $136.13 Buy Now
KM-16623 6.562 5.812 3 $137.65 Buy Now
KM-16622 6.625 5.875 3 $139.20 Buy Now
KM-16621 6.688 5.937 3 $140.75 Buy Now
KM-16608 6.750 6.000 3 $142.30 Buy Now
KM-16619 6.812 6.062 3 $143.85 Buy Now
KM-16630 6.875 6.125 3 $145.40 Buy Now
KM-16617 6.938 6.187 3 $146.95 Buy Now
KM-16616 7.000 6.250 3 $148.50 Buy Now
KM-16615 7.062 6.312 3 $150.08 Buy Now
KM-16614 7.125 6.375 3 $151.65 Buy Now
KM-16613 7.187 6.437 3 $153.20 Buy Now
KM-16612 7.250 6.500 3 $154.78 Buy Now
KM-16611 7.312 6.562 3 $157.70 Buy Now
KM-16610 7.375 6.625 3 $160.65 Buy Now
KM-16575 7.437 6.687 3 $163.63 Buy Now
KM-16629 7.500 6.750 3 $166.63 Buy Now
KM-16595 7.562 6.812 3 $169.68 Buy Now
KM-16562 7.625 6.875 3 $172.73 Buy Now
KM-16561 7.688 6.938 3 $175.80 Buy Now
KM-16560 7.750 7.000 3 $178.93 Buy Now
KM-16559 7.812 7.062 3 $182.08 Buy Now
KM-16558 7.875 7.125 3 $185.23 Buy Now
KM-16557 7.938 7.187 3 $188.43 Buy Now
KM-16556 8.000 7.250 3 $191.65 Buy Now
KM-16555 8.062 7.312 3 $194.90 Buy Now
KM-16554 8.125 7.375 3 $198.18 Buy Now
KM-16542 8.188 7.437 3 $201.48 Buy Now
KM-16552 8.250 7.500 3 $204.80 Buy Now
KM-16563 8.312 7.562 3 $208.18 Buy Now
KM-16550 8.375 7.625 3 $211.55 Buy Now
KM-16549 8.437 7.687 3 $214.98 Buy Now
KM-16548 8.500 7.750 3 $218.40 Buy Now
KM-16547 8.562 7.812 3 $221.88 Buy Now
KM-16546 8.625 7.875 3 $225.38 Buy Now
KM-16545 8.688 7.937 3 $228.90 Buy Now
KM-16544 8.750 8.000 3 $232.45 Buy Now
KM-16573 8.812 8.062 3 $236.03 Buy Now
KM-16551 8.875 8.125 3 $239.63 Buy Now
KM-16553 8.938 8.187 3 $243.25 Buy Now
KM-16584 9.000 8.250 3 $246.93 Buy Now
KM-16583 9.062 8.312 3 $250.60 Buy Now
KM-16582 9.125 8.375 3 $254.33 Buy Now
KM-16581 9.188 8.437 3 $258.05 Buy Now
KM-16580 9.250 8.500 3 $261.83 Buy Now
KM-16579 9.312 8.562 3 $263.68 Buy Now
KM-16578 9.375 8.625 3 $265.50 Buy Now
KM-16577 9.437 8.687 3 $267.35 Buy Now
KM-16576 9.500 8.750 3 $269.20 Buy Now
KM-16564 9.563 8.812 3 $271.05 Buy Now
KM-16574 9.625 8.875 3 $272.88 Buy Now
KM-16585 9.688 8.937 3 $274.73 Buy Now
KM-16572 9.750 9.000 3 $276.58 Buy Now
KM-16571 9.812 9.062 3 $278.43 Buy Now
KM-16570 9.875 9.125 3 $280.25 Buy Now
KM-16569 9.937 9.187 3 $282.10 Buy Now
KM-16568 10.000 9.250 3 $283.95 Buy Now
KM-16567 10.062 9.312 3 $285.80 Buy Now
KM-16566 10.125 9.375 3 $287.63 Buy Now
KM-16565 10.187 9.437 3 $289.48 Buy Now
KM-16651 10.250 9.500 3 $291.33 Buy Now
KM-16719 10.313 9.562 3 $293.18 Buy Now
KM-16609 10.375 9.625 3 $295.00 Buy Now
KM-16695 10.437 9.687 3 $296.85 Buy Now
KM-16694 10.500 9.750 3 $298.70 Buy Now
KM-16693 10.563 9.813 3 $300.55 Buy Now
KM-16692 10.625 9.875 3 $302.38 Buy Now
KM-16691 10.688 9.937 3 $304.23 Buy Now
KM-16690 10.750 10.000 3 $306.08 Buy Now
KM-16689 10.813 10.062 3 $307.93 Buy Now
KM-16688 10.875 10.125 3 $309.75 Buy Now
KM-16676 10.937 10.187 3 $311.60 Buy Now
KM-16686 11.000 10.250 3 $313.45 Buy Now
KM-16697 11.062 10.312 3 $315.30 Buy Now
KM-16684 11.125 10.375 3 $317.13 Buy Now
KM-16683 11.188 10.437 3 $318.98 Buy Now
KM-16682 11.250 10.500 3 $320.83 Buy Now
KM-16681 11.313 10.562 3 $321.93 Buy Now
KM-16680 11.375 10.625 3 $323.03 Buy Now
KM-16679 11.437 10.687 3 $324.10 Buy Now
KM-18162 11.500 10.750 3 $325.18 Buy Now
KM-18151 11.562 10.812 3 $326.25 Buy Now
KM-18141 11.625 10.875 3 $327.30 Buy Now
KM-18153 11.687 10.937 3 $328.35 Buy Now
KM-18154 11.750 11.000 3 $329.40 Buy Now
KM-18155 11.812 11.062 3 $330.43 Buy Now
KM-18156 11.875 11.125 3 $331.45 Buy Now
KM-18157 11.937 11.187 3 $332.48 Buy Now
KM-18158 12.000 11.250 3 $333.48 Buy Now
KM-18159 12.062 11.312 3 $334.48 Buy Now
KM-18160 12.125 11.375 3 $335.48 Buy Now
KM-18131 12.187 11.437 3 $336.45 Buy Now
KM-18152 12.250 11.500 3 $337.43 Buy Now
KM-18150 12.313 11.562 3 $338.38 Buy Now
KM-18121 12.375 11.625 3 $339.35 Buy Now
KM-18122 12.437 11.687 3 $340.30 Buy Now
KM-18123 12.500 11.750 3 $341.23 Buy Now
KM-18124 12.562 11.812 3 $342.15 Buy Now
KM-18125 12.625 11.875 3 $343.08 Buy Now
KM-18126 12.687 11.937 3 $344.00 Buy Now
KM-18127 12.750 12.000 3 $344.90 Buy Now
KM-18128 12.812 12.062 3 $345.80 Buy Now
KM-18140 12.875 12.125 3 $346.68 Buy Now
KM-18130 12.937 12.187 3 $347.58 Buy Now
KM-18120 13.000 12.250 3 $348.45 Buy Now
KM-18132 13.062 12.312 3 $349.30 Buy Now
KM-18133 13.125 12.375 3 $350.15 Buy Now
KM-16678 13.187 12.437 3 $351.00 Buy Now
KM-16677 13.250 12.500 3 $351.85 Buy Now
KM-16708 13.312 12.562 3 $353.43 Buy Now
KM-16710 13.375 12.625 3 $355.00 Buy Now
KM-16687 13.437 12.687 3 $356.58 Buy Now
KM-16718 13.500 12.750 3 $358.15 Buy Now
KM-16717 13.562 12.813 3 $359.75 Buy Now
KM-16716 13.625 12.875 3 $361.33 Buy Now
KM-16715 13.687 12.937 3 $362.90 Buy Now
KM-16714 13.750 13.000 3 $364.48 Buy Now
KM-16713 13.812 13.062 3 $366.03 Buy Now
KM-16712 13.875 13.125 3 $367.60 Buy Now
KM-16711 13.937 13.187 3 $369.18 Buy Now
KM-16698 14.000 13.250 3 $370.75 Buy Now
KM-16709 14.062 13.312 3 $372.33 Buy Now
KM-16720 14.125 13.375 3 $373.88 Buy Now
KM-16707 14.187 13.437 3 $375.45 Buy Now
KM-16706 14.250 13.500 3 $377.00 Buy Now
KM-16705 14.312 13.562 3 $378.58 Buy Now
KM-16704 14.375 13.625 3 $380.13 Buy Now
KM-16703 14.437 13.687 3 $381.70 Buy Now
KM-16702 14.500 13.750 3 $383.25 Buy Now
KM-16701 14.562 13.812 3 $384.83 Buy Now
KM-16700 14.625 13.875 3 $386.38 Buy Now
KM-16699 14.687 13.937 3 $387.93 Buy Now
KM-16674 14.750 14.000 3 $389.48 Buy Now
KM-16640 14.812 14.062 3 $391.03 Buy Now
KM-16685 14.875 14.125 3 $392.58 Buy Now
KM-16650 14.937 14.187 3 $394.15 Buy Now
KM-16649 15.000 14.250 3 $395.70 Buy Now
KM-16648 15.062 14.312 3 $397.23 Buy Now
KM-16647 15.125 14.375 3 $398.78 Buy Now
KM-16646 15.187 14.437 3 $400.33 Buy Now
KM-16645 15.250 14.500 3 $401.88 Buy Now
KM-16644 15.312 14.562 3 $403.43 Buy Now
KM-16643 15.375 14.625 3 $404.95 Buy Now
KM-16631 15.437 14.687 3 $406.50 Buy Now
KM-16641 15.500 14.750 3 $408.05 Buy Now
KM-16652 15.562 14.812 3 $409.58 Buy Now
KM-16639 15.625 14.875 3 $411.13 Buy Now
KM-16638 15.687 14.937 3 $412.65 Buy Now
KM-16637 15.750 15.000 3 $414.20 Buy Now
KM-16636 15.812 15.062 3 $415.73 Buy Now
KM-16635 15.875 15.125 3 $417.25 Buy Now
KM-16634 15.937 15.187 3 $418.78 Buy Now
KM-16633 16.000 15.250 3 $420.33 Buy Now
KM-16632 16.062 15.312 3 $421.85 Buy Now
KM-16663 16.125 15.375 3 $423.38 Buy Now
KM-16665 16.187 15.437 3 $424.90 Buy Now
KM-16642 16.250 15.500 3 $426.43 Buy Now
KM-16673 16.312 15.562 3 $427.95 Buy Now
KM-16672 16.375 15.625 3 $429.48 Buy Now
KM-16671 16.437 15.687 3 $431.00 Buy Now
KM-16670 16.500 15.750 3 $432.53 Buy Now
KM-16669 16.562 15.812 3 $434.03 Buy Now
KM-16668 16.625 15.875 3 $435.55 Buy Now
KM-16667 16.687 15.937 3 $437.08 Buy Now
KM-16666 16.750 16.000 3 $438.58 Buy Now
KM-16653 16.812 16.062 3 $440.10 Buy Now
KM-16664 16.875 16.125 3 $441.63 Buy Now
KM-16675 16.937 16.187 3 $443.13 Buy Now
KM-16662 17.000 16.250 3 $444.63 Buy Now
KM-16661 17.062 16.312 3 $446.15 Buy Now
KM-16660 17.125 16.375 3 $447.65 Buy Now
KM-16659 17.187 16.437 3 $449.15 Buy Now
KM-16658 17.250 16.500 3 $450.68 Buy Now
KM-16657 17.312 16.562 3 $452.68 Buy Now
KM-16656 17.375 16.625 3 $454.68 Buy Now
KM-16655 17.437 16.687 3 $456.68 Buy Now
KM-16520 17.500 16.750 3 $458.68 Buy Now
KM-16696 17.562 16.812 3 $460.68 Buy Now
KM-16543 17.625 16.875 3 $462.70 Buy Now
KM-16398 17.687 16.937 3 $464.70 Buy Now
KM-16397 17.750 17.000 3 $466.73 Buy Now
KM-16396 17.812 17.062 3 $468.73 Buy Now
KM-16395 17.875 17.125 3 $470.75 Buy Now
KM-16394 17.937 17.187 3 $472.78 Buy Now
KM-16393 18.000 17.250 3 $474.80 Buy Now
KM-16392 18.062 17.312 3 $476.83 Buy Now
KM-16391 18.125 17.375 3 $478.85 Buy Now
KM-16390 18.187 17.437 3 $480.90 Buy Now
KM-16378 18.250 17.500 3 $482.93 Buy Now
KM-16388 18.312 17.562 3 $484.95 Buy Now
KM-16399 18.375 17.625 3 $487.00 Buy Now
KM-16386 18.437 17.687 3 $489.05 Buy Now
KM-16385 18.500 17.750 3 $491.08 Buy Now
KM-16384 18.562 17.812 3 $493.13 Buy Now
KM-16383 18.625 17.875 3 $495.18 Buy Now
KM-16382 18.687 17.937 3 $497.23 Buy Now
KM-16381 18.750 18.000 3 $499.28 Buy Now
KM-16380 18.812 18.062 3 $501.35 Buy Now
KM-16379 18.875 18.125 3 $503.40 Buy Now
KM-16410 18.937 18.187 3 $505.45 Buy Now
KM-16412 19.000 18.250 3 $507.53 Buy Now
KM-16389 19.062 18.312 3 $509.60 Buy Now
KM-16420 19.125 18.375 3 $511.65 Buy Now
KM-16419 19.187 18.437 3 $513.73 Buy Now
KM-16418 19.250 18.500 3 $515.80 Buy Now
KM-16417 19.312 18.563 3 $516.93 Buy Now
KM-16416 19.375 18.625 3 $518.05 Buy Now
KM-16415 19.437 19.687 3 $519.15 Buy Now
KM-16414 19.500 18.750 3 $520.25 Buy Now
KM-16413 19.562 18.812 3 $521.38 Buy Now
KM-16400 19.625 18.875 3 $522.48 Buy Now
KM-16411 19.687 18.875 3 $523.55 Buy Now
KM-16422 19.750 19.000 3 $524.65 Buy Now
KM-16409 19.812 19.062 3 $526.05 Buy Now
KM-16408 19.875 19.125 3 $527.43 Buy Now
KM-16407 19.937 19.187 3 $528.83 Buy Now
KM-16406 20.000 19.250 3 $530.20 Buy Now



nominal inches,
diameter

plus or minus (±) tolerance, inches

ID inside diameter

OD outside diameter

steel
mandrel

built-up
mandrel

.125" -.749"

.003"

-

.005"

.750" - 1.999"

.004"

-

.005"

2.000" - 4.000"

.006"

-

.008"



*turned

*as wound

4.001" - 12.000"

.010"

-

.025"

plus only

12.001" - 18.000"

.030"

.060"

.030"

plus only

18.001" - 24.000"

.040"

.075"

.035"

plus only

24.001" - 48.000"

.060"

.090"

.040"

plus only

*Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request)
