Canvas C Fabric Reinforced Phenolic Tubes .187" Wall Thickness

Ce canvas Tube .187 Wall

Canvas C Fabric Reinforced Phenolic Tubes - natural (light tan to brown) Technical Data Sheet
This grade is composed of a continuous cotton woven cloth impregnated with a phenolic resin binder. This grade contains a medium weave canvas and is known primarily for it's mechanical properties. This grade is not recommended for primary insulation.

NEMA grades C Canvas Cotton-Cloth Reinforced Phenolic -- natural color is typically light tan to brown. C grades are composed of a continuous cotton woven cloth impregnated with a phenolic resin binder. These grades contain a medium weave canvas and are known primarily for their mechanical properties. These grades are not recommended for primary electrical insulation.

NEMA C certs to Mil-I-13768/16 FBM, IEC 60893-3 Type 4, PF CC 201
 Chemical Resistance Chart

C Tubes    C/CE Sheets  C/CE Bar

Wall Thickness Options
.031" .062" .093" .125"
.187" .250" .375" .500"
.750" 1.00"

.187" Wall Thickness - Canvas Tubes
Stock # OD Inches ID Inches Min. Feet to Purchase  Price Per Foot Purchase Online
KM-4995 .625 .250 3 $23.80 Buy Now
KM-5198 .688 .313 3 $46.90 Buy Now
KM-5021 .750 .375 3 $28.32 Buy Now
KM-2024 .875 .500 33 $10.88 Buy Now
KM-2029 .938 .562 30 $11.63 Buy Now
KM-2035 1.000 .625 27 $12.35 Buy Now
KM-18180 1.062 .687 27 $13.00 Buy Now
KM-2044 1.125 .750 27 $13.73 Buy Now
KM-18182 1.187 .812 24 $14.33 Buy Now
KM-2049 1.250 .875 24 $15.13 Buy Now
KM-18099 1.312 .937 24 $15.90 Buy Now
KM-2055 1.375 1.000 21 $16.70 Buy Now
KM-18129 1.437 1.062 21 $17.45 Buy Now
KM-18056 1.500 1.125 21 $18.20 Buy Now
KM-18057 1.562 1.187 18 $18.95 Buy Now
KM-2059 1.625 1.250 18 $19.68 Buy Now
KM-18059 1.688 1.312 18 $20.40 Buy Now
KM-18060 1.750 1.375 18 $21.10 Buy Now
KM-18061 1.812 1.437 18 $21.80 Buy Now
KM-5054 1.875 1.500 18 $22.50 Buy Now
KM-18075 1.937 1.562 15 $23.18 Buy Now
KM-18064 2.000 1.625 15 $23.83 Buy Now
KM-18054 2.062 1.687 15 $24.48 Buy Now
KM-18066 2.125 1.750 15 $25.13 Buy Now
KM-18067 2.188 1.812 15 $25.75 Buy Now
KM-18068 2.250 1.875 15 $26.38 Buy Now
KM-18069 2.312 1.937 15 $26.98 Buy Now
KM-18070 2.375 2.000 15 $27.58 Buy Now
KM-18071 2.437 2.062 12 $28.18 Buy Now
KM-18072 2.500 2.125 12 $28.75 Buy Now
KM-18073 2.562 2.187 12 $29.30 Buy Now
KM-18044 2.625 2.250 12 $29.85 Buy Now
KM-18065 2.688 2.312 12 $30.40 Buy Now
KM-18063 2.75 2.375 12 $30.93 Buy Now
KM-18034 2.812 2.437 12 $31.43 Buy Now
KM-18035 2.875 2.500 12 $31.95 Buy Now
KM-18036 2.937 2.562 12 $32.43 Buy Now
KM-18037 3.000 2.625 12 $32.68 Buy Now
KM-18038 3.062 2.687 12 $33.35 Buy Now
KM-18039 3.125 2.750 12 $34.03 Buy Now
KM-18040 3.188 2.812 12 $34.70 Buy Now
KM-18041 3.250 2.875 12 $35.38 Buy Now
KM-18053 3.312 2.937 12 $36.05 Buy Now
KM-18043 3.375 3.000 12 $36.73 Buy Now
KM-18033 3.437 3.062 12 $37.40 Buy Now
KM-18045 3.500 3.125 9 $38.08 Buy Now
KM-18046 3.562 3.187 9 $38.75 Buy Now
KM-18047 3.625 3.250 9 $39.40 Buy Now
KM-18048 3.687 3.312 9 $40.08 Buy Now
KM-18049 3.750 3.375 9 $40.73 Buy Now
KM-18050 3.812 3.437 9 $41.40 Buy Now
KM-18051 3.875 3.500 9 $42.05 Buy Now
KM-18052 3.937 3.562 9 $42.70 Buy Now
KM-18077 4.000 3.625 9 $43.38 Buy Now
KM-18109 4.062 3.687 9 $44.03 Buy Now
KM-18074 4.125 3.750 9 $44.68 Buy Now
KM-18100 4.187 3.812 9 $45.33 Buy Now
KM-18101 4.250 3.875 9 $45.98 Buy Now
KM-18102 4.312 3.937 9 $46.60 Buy Now
KM-18103 4.375 4.000 9 $47.25 Buy Now
KM-18104 4.437 4.062 9 $47.90 Buy Now
KM-18105 4.500 4.125 9 $48.53 Buy Now
KM-18106 4.562 4.187 9 $49.18 Buy Now
KM-18119 4.625 4.250 9 $49.80 Buy Now
KM-18108 4.687 4.312 9 $50.45 Buy Now
KM-18098 4.750 4.375 9 $51.08 Buy Now
KM-18110 4.812 4.438 9 $51.70 Buy Now
KM-18111 4.875 4.500 9 $52.33 Buy Now
KM-18112 4.937 4.562 9 $52.95 Buy Now
KM-18113 5.000 4.625 9 $53.65 Buy Now
KM-18114 5.062 4.687 9 $54.20 Buy Now
KM-18115 5.125 4.750 9 $54.75 Buy Now
KM-18116 5.187 4.812 6 $55.30 Buy Now
KM-18117 5.250 4.875 6 $55.85 Buy Now
KM-18118 5.312 4.937 6 $56.38 Buy Now
KM-18087 5.375 5.000 6 $56.90 Buy Now
KM-18085 5.437 5.062 6 $57.43 Buy Now
KM-18107 5.500 5.125 6 $57.95 Buy Now
KM-18078 5.562 5.187 6 $58.48 Buy Now
KM-16785 5.625 5.250 6 $59.00 Buy Now
KM-17627 5.688 5.313 6 $59.50 Buy Now
KM-17640 5.750 5.375 6 $60.03 Buy Now
KM-17629 5.812 5.437 6 $60.53 Buy Now
KM-17619 5.875 5.500 6 $61.03 Buy Now
KM-17631 5.938 5.562 6 $61.53 Buy Now
KM-17600 6.000 5.625 6 $62.03 Buy Now
KM-17601 6.063 5.687 6 $62.50 Buy Now
KM-17602 6.125 5.750 6 $63.00 Buy Now
KM-17603 6.187 5.812 6 $63.48 Buy Now
KM-17604 6.250 5.875 6 $63.95 Buy Now
KM-17605 6.312 5.937 6 $64.43 Buy Now
KM-17606 6.375 6.000 6 $64.90 Buy Now
KM-17618 6.437 6.062 6 $65.38 Buy Now
KM-17608 6.500 6.125 6 $65.85 Buy Now
KM-17598 6.562 6.187 6 $66.30 Buy Now
KM-17610 6.625 6.250 6 $66.75 Buy Now
KM-17611 6.688 6.312 6 $67.20 Buy Now
KM-17612 6.750 6.375 6 $67.65 Buy Now
KM-17613 6.812 6.437 6 $68.10 Buy Now
KM-17614 6.875 6.500 6 $68.55 Buy Now
KM-17615 6.938 6.562 6 $69.00 Buy Now
KM-17616 7.000 6.625 6 $69.63 Buy Now
KM-17617 7.062 6.687 6 $70.23 Buy Now
KM-17642 7.125 6.750 6 $70.83 Buy Now
KM-17674 7.187 6.812 6 $71.45 Buy Now
KM-17639 7.250 6.875 6 $72.05 Buy Now
KM-17665 7.312 6.938 6 $72.65 Buy Now
KM-17666 7.375 7.000 6 $73.25 Buy Now
KM-17667 7.437 7.062 6 $73.85 Buy Now
KM-17668 7.500 7.125 6 $74.45 Buy Now
KM-17669 7.562 7.187 6 $75.05 Buy Now
KM-17670 7.625 7.250 6 $75.65 Buy Now
KM-17671 7.688 7.312 6 $76.25 Buy Now
KM-17684 7.750 7.375 6 $76.85 Buy Now
KM-17673 7.812 7.437 6 $77.45 Buy Now
KM-17663 7.875 7.500 6 $78.05 Buy Now
KM-17675 7.938 7.562 6 $78.65 Buy Now
KM-17676 8.000 7.625 6 $79.25 Buy Now
KM-17677 8.062 7.687 6 $79.85 Buy Now
KM-17678 8.125 7.750 6 $80.43 Buy Now
KM-17679 8.188 7.812 6 $81.03 Buy Now
KM-17680 8.250 7.875 6 $81.63 Buy Now
KM-17681 8.312 7.937 6 $82.23 Buy Now
KM-17682 8.375 8.000 6 $82.80 Buy Now
KM-17683 8.437 8.062 6 $83.40 Buy Now
KM-17652 8.500 8.125 6 $84.00 Buy Now
KM-17650 8.562 8.187 6 $84.58 Buy Now
KM-17672 8.625 8.250 6 $85.18 Buy Now
KM-17643 8.688 8.312 6 $85.78 Buy Now
KM-17644 8.750 8.375 6 $86.35 Buy Now
KM-17645 8.812 8.437 6 $86.95 Buy Now
KM-17646 8.875 8.500 6 $87.53 Buy Now
KM-17647 8.938 8.562 6 $88.13 Buy Now
KM-17648 9.000 8.625 6 $88.70 Buy Now
KM-17649 9.062 8.687 3 $152.55 Buy Now
KM-17662 9.125 8.750 3 $153.45 Buy Now
KM-17651 9.188 8.812 3 $154.35 Buy Now
KM-17641 9.250 8.875 3 $155.25 Buy Now
KM-17653 9.312 8.937 3 $156.15 Buy Now
KM-17654 9.375 9.000 3 $157.03 Buy Now
KM-17655 9.437 9.062 3 $157.93 Buy Now
KM-17656 9.500 9.125 3 $158.80 Buy Now
KM-17657 9.563 9.187 3 $159.70 Buy Now
KM-17658 9.625 9.250 3 $160.58 Buy Now
KM-17659 9.688 9.312 3 $161.45 Buy Now
KM-17660 9.750 9.375 3 $162.33 Buy Now
KM-17661 9.812 9.437 3 $163.20 Buy Now
KM-17577 9.875 9.500 3 $164.08 Buy Now
KM-17520 9.937 9.562 3 $164.95 Buy Now
KM-17607 10.000 9.625 3 $165.83 Buy Now
KM-17534 10.062 9.687 3 $166.68 Buy Now
KM-17535 10.125 9.750 3 $167.55 Buy Now
KM-17536 10.187 9.813 3 $168.40 Buy Now
KM-17537 10.250 9.875 3 $169.25 Buy Now
KM-17538 10.313 9.937 3 $170.13 Buy Now
KM-17539 10.375 10.000 3 $170.98 Buy Now
KM-17540 10.437 10.062 3 $171.83 Buy Now
KM-17553 10.500 10.125 3 $172.68 Buy Now
KM-17542 10.563 10.187 3 $173.53 Buy Now
KM-17532 10.625 10.250 3 $174.35 Buy Now
KM-17544 10.688 10.312 3 $175.20 Buy Now
KM-17545 10.750 10.375 3 $176.03 Buy Now
KM-17546 10.813 10.437 3 $176.88 Buy Now
KM-17547 10.875 10.500 3 $177.70 Buy Now
KM-17548 10.937 10.562 3 $178.55 Buy Now
KM-17549 11.000 10.625 3 $179.15 Buy Now
KM-17550 11.062 10.687 3 $180.20 Buy Now
KM-17551 11.125 10.750 3 $181.23 Buy Now
KM-17522 11.188 10.812 3 $182.28 Buy Now
KM-17543 11.250 10.875 3 $183.30 Buy Now
KM-17541 11.313 10.937 3 $184.33 Buy Now
KM-17512 11.375 11.000 3 $185.38 Buy Now
KM-17513 11.437 11.062 3 $186.40 Buy Now
KM-17514 11.500 11.125 3 $187.45 Buy Now
KM-17515 11.625 11.250 3 $189.53 Buy Now
KM-17516 11.687 11.312 3 $190.55 Buy Now
KM-17517 11.750 11.375 3 $191.58 Buy Now
KM-17518 11.812 11.437 3 $192.63 Buy Now
KM-17519 11.875 11.500 3 $193.65 Buy Now
KM-17531 11.937 11.562 3 $194.70 Buy Now
KM-17521 12.000 11.625 3 $195.73 Buy Now
KM-17511 12.062 11.687 3 $196.75 Buy Now
KM-17523 12.125 11.750 3 $197.80 Buy Now
KM-17524 12.187 11.812 3 $198.83 Buy Now
KM-17525 12.250 11.875 3 $199.88 Buy Now
KM-17526 12.313 11.937 3 $200.90 Buy Now
KM-17527 12.375 12.000 3 $201.95 Buy Now
KM-17528 12.437 12.062 3 $202.98 Buy Now
KM-17529 12.500 12.125 3 $204.00 Buy Now
KM-17530 12.562 12.187 3 $205.05 Buy Now
KM-17555 12.625 12.250 3 $206.08 Buy Now
KM-17587 12.687 12.312 3 $207.13 Buy Now
KM-17552 12.750 12.375 3 $208.15 Buy Now
KM-17578 12.812 12.437 3 $209.20 Buy Now
KM-17579 12.875 12.500 3 $210.23 Buy Now
KM-17580 12.937 12.562 3 $211.25 Buy Now
KM-17581 13.000 12.625 3 $212.30 Buy Now
KM-17582 13.062 12.687 3 $213.70 Buy Now
KM-17774 13.125 12.750 3 $215.13 Buy Now
KM-17775 13.187 12.813 3 $216.53 Buy Now
KM-17776 13.250 12.875 3 $217.95 Buy Now
KM-17777 13.312 12.937 3 $219.38 Buy Now
KM-17778 13.375 13.000 3 $220.80 Buy Now
KM-17779 13.437 13.062 3 $222.25 Buy Now
KM-17780 13.500 13.125 3 $223.68 Buy Now
KM-17792 13.562 13.187 3 $225.10 Buy Now
KM-17782 13.625 13.250 3 $226.55 Buy Now
KM-17772 13.687 13.312 3 $228.00 Buy Now
KM-17784 13.750 13.375 3 $229.45 Buy Now
KM-17785 13.812 13.437 3 $230.90 Buy Now
KM-17786 13.875 13.500 3 $232.35 Buy Now
KM-17787 13.937 13.562 3 $233.83 Buy Now
KM-17788 14.000 13.625 3 $235.28 Buy Now
KM-17789 14.062 13.687 3 $236.75 Buy Now
KM-17790 14.125 13.750 3 $238.23 Buy Now
KM-17791 14.187 13.812 3 $239.70 Buy Now
KM-17816 14.250 13.875 3 $241.18 Buy Now
KM-17848 14.312 13.937 3 $242.65 Buy Now
KM-17813 14.375 14.000 3 $244.15 Buy Now
KM-17839 14.437 14.062 3 $245.63 Buy Now
KM-17840 14.500 14.125 3 $247.13 Buy Now
KM-17841 14.562 14.187 3 $248.63 Buy Now
KM-17842 14.625 14.250 3 $250.13 Buy Now
KM-17843 14.687 14.312 3 $251.63 Buy Now
KM-17844 14.750 14.375 3 $253.13 Buy Now
KM-17845 14.812 14.437 3 $254.65 Buy Now
KM-17858 14.875 14.500 3 $256.15 Buy Now
KM-17847 14.937 14.562 3 $257.68 Buy Now
KM-17837 15.000 14.625 3 $259.20 Buy Now
KM-17849 15.062 14.687 3 $259.85 Buy Now
KM-17850 15.125 14.750 3 $260.53 Buy Now
KM-17851 15.187 14.812 3 $261.18 Buy Now
KM-17852 15.250 14.875 3 $261.83 Buy Now
KM-17853 15.312 14.937 3 $262.48 Buy Now
KM-17854 15.375 15.000 3 $263.13 Buy Now
KM-17855 15.437 15.062 3 $263.75 Buy Now
KM-17856 15.500 15.125 3 $264.40 Buy Now
KM-17857 15.562 15.187 3 $265.03 Buy Now
KM-17826 15.625 15.250 3 $265.65 Buy Now
KM-17824 15.687 15.312 3 $266.28 Buy Now
KM-17846 15.750 15.375 3 $266.90 Buy Now
KM-17817 15.812 15.437 3 $267.53 Buy Now
KM-17818 15.875 15.500 3 $268.13 Buy Now
KM-17819 15.937 15.562 3 $268.75 Buy Now
KM-17820 16.000 15.625 3 $269.35 Buy Now
KM-17821 16.062 15.687 3 $269.95 Buy Now
KM-17822 16.125 15.750 3 $270.55 Buy Now
KM-17823 16.187 15.812 3 $271.15 Buy Now
KM-17836 16.250 15.875 3 $271.75 Buy Now
KM-17825 16.312 15.937 3 $272.33 Buy Now
KM-17815 16.375 16.000 3 $272.93 Buy Now
KM-17827 16.437 16.062 3 $273.50 Buy Now
KM-17828 16.500 16.125 3 $274.08 Buy Now
KM-17829 16.562 16.187 3 $274.65 Buy Now
KM-17830 16.625 16.250 3 $275.23 Buy Now
KM-17831 16.687 16.312 3 $275.80 Buy Now
KM-17832 16.750 16.375 3 $276.35 Buy Now
KM-17833 16.812 16.437 3 $276.93 Buy Now
KM-17834 16.875 16.500 3 $277.48 Buy Now
KM-17835 16.937 16.562 3 $278.03 Buy Now
KM-17751 17.000 16.625 3 $278.58 Buy Now
KM-17694 17.062 16.687 3 $279.23 Buy Now
KM-17781 17.125 16.750 3 $280.65 Buy Now
KM-17708 17.187 16.812 3 $282.05 Buy Now
KM-17709 17.250 16.875 3 $283.48 Buy Now
KM-17710 17.312 16.937 3 $284.90 Buy Now
KM-17711 17.375 17.000 3 $286.30 Buy Now
KM-17712 17.437 17.062 3 $287.73 Buy Now
KM-17713 17.500 17.125 3 $289.15 Buy Now
KM-17714 17.562 17.187 3 $290.58 Buy Now
KM-17727 17.625 17.250 3 $292.03 Buy Now
KM-17716 17.687 17.312 3 $293.45 Buy Now
KM-17706 17.750 17.375 3 $294.88 Buy Now
KM-17718 17.812 17.437 3 $296.33 Buy Now
KM-17719 17.875 17.500 3 $297.78 Buy Now
KM-17720 17.937 17.562 3 $299.20 Buy Now
KM-17721 18.000 17.625 3 $300.65 Buy Now
KM-17722 18.062 17.687 3 $302.10 Buy Now
KM-17723 18.125 17.750 3 $303.58 Buy Now
KM-17724 18.187 17.812 3 $305.03 Buy Now
KM-17725 18.250 17.875 3 $306.48 Buy Now
KM-17696 18.312 17.937 3 $307.95 Buy Now
KM-17717 18.375 18.000 3 $309.40 Buy Now
KM-17715 18.437 18.062 3 $310.88 Buy Now
KM-17686 18.500 18.125 3 $312.35 Buy Now
KM-17687 18.562 18.187 3 $313.83 Buy Now
KM-17688 18.625 18.250 3 $315.30 Buy Now
KM-17689 18.687 18.312 3 $316.78 Buy Now
KM-17690 18.750 18.375 3 $318.25 Buy Now
KM-17691 18.812 18.437 3 $319.73 Buy Now
KM-17692 18.875 18.500 3 $321.23 Buy Now
KM-17693 18.937 18.563 3 $322.70 Buy Now
KM-17705 19.000 18.625 3 $324.20 Buy Now
KM-17695 19.062 19.687 3 $325.70 Buy Now
KM-17685 19.125 18.750 3 $327.20 Buy Now
KM-17697 19.187 18.812 3 $328.70 Buy Now
KM-17698 19.250 18.875 3 $330.20 Buy Now
KM-17699 19.312 18.875 3 $331.70 Buy Now
KM-17700 19.375 19.000 3 $333.20 Buy Now
KM-17701 19.437 19.062 3 $334.73 Buy Now
KM-17702 19.500 19.125 3 $336.23 Buy Now
KM-17703 19.625 19.250 3 $339.28 Buy Now
KM-17704 19.687 19.312 3 $340.80 Buy Now
KM-16784 19.750 19.375 3 $342.33 Buy Now
KM-16783 19.812 19.437 3 $343.85 Buy Now
KM-16782 19.875 19.500 3 $345.38 Buy Now
KM-16781 19.937 19.562 3 $346.90 Buy Now
KM-16780 20.000 19.625 3 $349.75 Buy Now

nominal inches,
diameter

plus or minus (±) tolerance, inches

ID inside diameter

OD outside diameter

steel
mandrel

built-up
mandrel

.125" -.749"

.003"

-

.005"

.750" - 1.999"

.004"

-

.005"

2.000" - 4.000"

.006"

-

.008"



*turned

*as wound

4.001" - 12.000"

.010"

-

.025"

plus only

12.001" - 18.000"

.030"

.060"

.030"

plus only

18.001" - 24.000"

.040"

.075"

.035"

plus only

24.001" - 48.000"

.060"

.090"

.040"

plus only

*Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request)
