Canvas C Fabric Reinforced Phenolic Tubes .093" Wall Thickness

Ce Canvas Tubes 093 Wall

Canvas C Fabric Reinforced Phenolic Tubes - natural (light tan to brown) Technical Data Sheet
This grade is composed of a continuous cotton woven cloth impregnated with a phenolic resin binder. This grade contains a medium weave canvas and is known primarily for it's mechanical properties. This grade is not recommended for primary insulation.

NEMA grades C Canvas Cotton-Cloth Reinforced Phenolic -- natural color is typically light tan to brown. C grades are composed of a continuous cotton woven cloth impregnated with a phenolic resin binder. These grades contain a medium weave canvas and are known primarily for their mechanical properties. These grades are not recommended for primary electrical insulation.

NEMA C certs to Mil-I-13768/16 FBM, IEC 60893-3 Type 4, PF CC 201
 Chemical Resistance Chart

C Tubes    C/CE Sheets  C/CE Bar Stock


Wall Thickness Options
.031" .062" .093" .125"
.187" .250" .375" .500"
.750" 1.00"




.093" Wall Thickness - Canvas Tubes
Stock # OD Inches ID Inches Min. Feet to Purchase  Price Per Foot Purchase Online
KM-2002 .375 .187 12 $7.93 Buy Now
KM-2006 .438 .250 9 $8.58 Buy Now
KM-2010 .500 .312 9 $8.85 Buy Now
KM-2018 .625 .437 33 $10.08 Buy Now
KM-2014 .656 .375 6 $10.15 Buy Now
KM-2022 .688 .500 51 $6.93 Buy Now
KM-18241 .750 .562 51 $7.13 Buy Now
KM-2033 .813 .625 48 $7.25 Buy Now
KM-18239 .875 .687 48 $7.88 Buy Now
KM-2042 .938 .750 45 $8.13 Buy Now
KM-18237 1.000 .812 42 $8.58 Buy Now
KM-2047 1.063 .875 39 $8.88 Buy Now
KM-18235 1.125 .937 36 $9.38 Buy Now
KM-2053 1.187 1.000 36 $9.88 Buy Now
KM-18233 1.250 1.062 36 $10.35 Buy Now
KM-18242 1.312 1.125 36 $10.83 Buy Now
KM-18231 1.375 1.187 33 $11.30 Buy Now
KM-18230 1.437 1.250 30 $11.75 Buy Now
KM-18229 1.500 1.312 30 $12.23 Buy Now
KM-18228 1.562 1.375 30 $12.65 Buy Now
KM-18227 1.625 1.437 27 $13.10 Buy Now
KM-18226 1.688 1.500 27 $13.53 Buy Now
KM-18296 1.750 1.562 27 $13.93 Buy Now
KM-18352 1.812 1.625 24 $14.35 Buy Now
KM-18262 1.875 1.687 24 $14.75 Buy Now
KM-18332 1.937 1.750 24 $15.13 Buy Now
KM-18331 2.000 1.812 24 $15.53 Buy Now
KM-18330 2.062 1.875 24 $15.90 Buy Now
KM-18329 2.125 1.937 21 $16.25 Buy Now
KM-18328 2.188 2.000 21 $16.63 Buy Now
KM-18327 2.250 2.062 21 $16.98 Buy Now
KM-18317 2.312 2.125 21 $17.30 Buy Now
KM-18325 2.375 2.187 21 $17.65 Buy Now
KM-18334 2.437 2.250 21 $17.98 Buy Now
KM-18323 2.500 2.312 21 $18.28 Buy Now
KM-18322 2.562 2.375 21 $18.60 Buy Now
KM-18321 2.625 2.437 21 $18.90 Buy Now
KM-18320 2.688 2.500 18 $19.18 Buy Now
KM-18319 2.750 2.562 18 $19.45 Buy Now
KM-18318 2.812 2.625 18 $19.73 Buy Now
KM-18343 2.875 2.687 18 $20.00 Buy Now
KM-18345 2.937 2.750 18 $20.25 Buy Now
KM-18326 3.000 2.812 18 $20.53 Buy Now
KM-18351 3.062 2.875 18 $20.93 Buy Now
KM-18350 3.125 2.937 18 $21.30 Buy Now
KM-18349 3.188 3.000 18 $21.68 Buy Now
KM-18348 3.250 3.062 18 $22.05 Buy Now
KM-18347 3.312 3.125 18 $22.43 Buy Now
KM-18346 3.375 3.187 15 $22.80 Buy Now
KM-17499 3.437 3.250 15 $23.18 Buy Now
KM-17498 3.500 3.312 15 $23.53 Buy Now
KM-17497 3.562 3.375 15 $23.90 Buy Now
KM-17496 3.625 3.437 15 $24.25 Buy Now
KM-17495 3.687 3.500 15 $24.63 Buy Now
KM-17494 3.750 3.562 15 $24.98 Buy Now
KM-18344 3.812 3.625 15 $25.33 Buy Now
KM-17493 3.937 3.750 15 $26.03 Buy Now
KM-17492 4.000 3.812 15 $26.38 Buy Now
KM-17491 4.062 3.875 15 $26.73 Buy Now
KM-17479 4.125 3.937 15 $27.08 Buy Now
KM-17489 4.187 4.000 15 $27.40 Buy Now
KM-17500 4.250 4.062 15 $27.75 Buy Now
KM-17487 4.312 4.125 15 $28.08 Buy Now
KM-17486 4.375 4.187 12 $28.43 Buy Now
KM-17485 4.437 4.250 12 $28.75 Buy Now
KM-17484 4.500 4.312 12 $29.08 Buy Now
KM-17483 4.562 4.375 12 $29.40 Buy Now
KM-17482 4.625 4.438 12 $29.73 Buy Now
KM-17481 4.687 4.500 12 $30.05 Buy Now
KM-17480 4.75 4.562 12 $30.38 Buy Now
KM-18335 4.812 4.625 12 $30.68 Buy Now
KM-17490 4.875 4.687 12 $31.00 Buy Now
KM-18353 4.937 4.750 12 $31.30 Buy Now
KM-18342 5.000 4.812 12 $31.63 Buy Now
KM-18341 5.062 4.875 12 $32.08 Buy Now
KM-18340 5.125 4.937 12 $32.53 Buy Now
KM-18339 5.187 5.000 12 $33.00 Buy Now
KM-18338 5.250 5.062 12 $33.48 Buy Now
KM-18337 5.312 5.125 12 $33.93 Buy Now
KM-18336 5.375 5.187 12 $34.40 Buy Now
KM-17501 5.437 5.250 12 $34.88 Buy Now
KM-18315 5.500 5.313 12 $35.33 Buy Now
KM-18287 5.562 5.375 12 $35.80 Buy Now
KM-17510 5.625 5.437 12 $36.28 Buy Now
KM-17509 5.688 5.500 12 $36.75 Buy Now
KM-17508 5.750 5.562 12 $37.23 Buy Now
KM-17507 5.812 5.625 12 $37.70 Buy Now
KM-17506 5.875 5.687 9 $38.18 Buy Now
KM-17505 5.938 5.750 9 $38.68 Buy Now
KM-17504 6.000 5.812 9 $39.15 Buy Now
KM-17503 6.063 5.875 9 $39.63 Buy Now
KM-17468 6.125 5.937 9 $40.13 Buy Now
KM-18324 6.187 6.000 9 $40.60 Buy Now
KM-17488 6.250 6.062 9 $41.08 Buy Now
KM-17455 6.312 6.125 9 $41.58 Buy Now
KM-17454 6.375 6.187 9 $42.08 Buy Now
KM-17453 6.437 6.250 9 $42.55 Buy Now
KM-17452 6.50 6.312 9 $43.05 Buy Now
KM-17451 6.562 6.375 9 $43.55 Buy Now
KM-17450 6.625 6.437 9 $44.05 Buy Now
KM-17449 6.688 6.500 9 $44.55 Buy Now
KM-17448 6.750 6.562 9 $45.05 Buy Now
KM-17447 6.812 6.625 9 $45.55 Buy Now
KM-18585 6.875 6.687 9 $46.05 Buy Now
KM-18584 6.938 6.750 9 $46.55 Buy Now
KM-18574 7.000 6.812 9 $47.03 Buy Now
KM-18582 7.062 6.875 9 $47.30 Buy Now
KM-18591 7.125 6.938 9 $47.60 Buy Now
KM-18580 7.187 7.000 9 $47.88 Buy Now
KM-18579 7.250 7.062 9 $48.15 Buy Now
KM-18578 7.312 7.125 9 $48.43 Buy Now
KM-18577 7.375 7.187 9 $48.70 Buy Now
KM-17445 7.500 7.312 9 $48.98 Buy Now
KM-17456 7.562 7.375 9 $49.25 Buy Now
KM-17443 7.625 7.437 9 $49.53 Buy Now
KM-17442 7.688 7.500 9 $49.78 Buy Now
KM-17441 7.750 7.562 9 $50.05 Buy Now
KM-17440 7.812 7.625 9 $50.55 Buy Now
KM-17439 7.875 7.687 9 $50.80 Buy Now
KM-17438 7.938 7.750 9 $51.05 Buy Now
KM-17437 8.000 7.812 9 $51.30 Buy Now
KM-17466 8.062 7.875 9 $51.55 Buy Now
KM-17444 8.125 7.937 9 $51.80 Buy Now
KM-17446 8.188 8.000 9 $52.05 Buy Now
KM-17477 8.250 8.062 9 $52.28 Buy Now
KM-17476 8.312 8.125 9 $52.53 Buy Now
KM-17475 8.375 8.187 9 $52.75 Buy Now
KM-17474 8.437 8.250 9 $52.98 Buy Now
KM-17473 8.500 8.312 9 $53.23 Buy Now
KM-17472 8.562 8.375 9 $53.45 Buy Now
KM-17471 8.625 8.437 9 $53.68 Buy Now
KM-17470 8.688 8.500 9 $53.90 Buy Now
KM-17469 8.750 8.562 9 $54.10 Buy Now
KM-17457 8.812 8.625 9 $54.33 Buy Now
KM-17467 8.875 8.687 9 $54.55 Buy Now
KM-17478 8.938 8.750 9 $54.75 Buy Now
KM-17465 9.000 8.812 9 $54.98 Buy Now
KM-17464 9.062 8.875 3 $112.45 Buy Now
KM-17463 9.125 8.937 3 $113.23 Buy Now
KM-17462 9.188 9.000 3 $114.03 Buy Now
KM-17461 9.250 9.062 3 $114.80 Buy Now
KM-17460 9.312 9.125 3 $115.58 Buy Now
KM-17459 9.375 9.187 3 $116.38 Buy Now
KM-18295 9.437 9.250 3 $117.15 Buy Now
KM-17436 9.500 9.312 3 $117.93 Buy Now
KM-17502 9.563 9.375 3 $118.73 Buy Now
KM-18294 9.625 9.437 3 $119.50 Buy Now
KM-18293 9.688 9.500 3 $120.28 Buy Now
KM-18292 9.750 9.562 3 $121.08 Buy Now
KM-18291 9.812 9.625 3 $121.85 Buy Now
KM-18290 9.875 9.687 3 $122.63 Buy Now
KM-18280 9.937 9.750 3 $123.43 Buy Now
KM-18288 10.00 9.813 3 $124.20 Buy Now
KM-18297 10.062 9.875 3 $125.00 Buy Now
KM-18286 10.125 9.937 3 $125.78 Buy Now
KM-18285 10.187 10.000 3 $126.55 Buy Now
KM-18284 10.250 10.062 3 $127.35 Buy Now
KM-18283 10.313 10.125 3 $128.13 Buy Now
KM-18282 10.375 10.187 3 $128.90 Buy Now
KM-18281 10.437 10.250 3 $129.70 Buy Now
KM-18306 10.500 10.312 3 $130.48 Buy Now
KM-18308 10.563 10.375 3 $131.25 Buy Now
KM-18289 10.625 10.437 3 $132.05 Buy Now
KM-18314 10.688 10.500 3 $132.83 Buy Now
KM-18313 10.750 10.562 3 $133.60 Buy Now
KM-18312 10.813 10.625 3 $134.40 Buy Now
KM-18311 10.875 10.687 3 $135.18 Buy Now
KM-18310 10.937 10.750 3 $135.95 Buy Now
KM-18309 11.000 10.812 3 $136.75 Buy Now
KM-18298 11.062 10.875 3 $137.53 Buy Now
KM-18307 11.125 10.937 3 $138.30 Buy Now
KM-18316 11.188 11.000 3 $139.10 Buy Now
KM-18305 11.250 11.062 3 $139.88 Buy Now
KM-18304 11.313 11.125 3 $140.65 Buy Now
KM-18303 11.375 11.187 3 $141.45 Buy Now
KM-18302 11.437 11.250 3 $142.23 Buy Now
KM-18301 11.500 11.312 3 $143.00 Buy Now
KM-18300 11.562 11.375 3 $143.80 Buy Now
KM-18553 11.625 11.437 3 $144.58 Buy Now
KM-18259 11.687 11.500 3 $145.35 Buy Now
KM-18480 11.750 11.562 3 $146.15 Buy Now
KM-18700 11.812 11.625 3 $146.93 Buy Now
KM-18699 11.875 11.687 3 $147.73 Buy Now
KM-18698 11.937 11.750 3 $148.50 Buy Now
KM-18697 12.000 11.812 3 $149.28 Buy Now
KM-18696 12.062 11.875 3 $150.08 Buy Now
KM-18695 12.125 11.937 3 $150.85 Buy Now
KM-18694 12.187 12.000 3 $151.63 Buy Now
KM-18684 12.250 12.062 3 $152.43 Buy Now
KM-18692 12.313 12.125 3 $153.20 Buy Now
KM-18701 12.375 12.187 3 $153.98 Buy Now
KM-18690 12.437 12.250 3 $154.78 Buy Now
KM-18689 12.500 12.312 3 $155.55 Buy Now
KM-18688 12.562 12.375 3 $156.33 Buy Now
KM-18687 12.625 12.437 3 $157.13 Buy Now
KM-18686 12.687 12.500 3 $157.90 Buy Now
KM-18685 12.750 12.562 3 $158.68 Buy Now
KM-18710 12.812 12.625 3 $159.48 Buy Now
KM-18712 12.875 12.687 3 $160.25 Buy Now
KM-18693 12.937 12.750 3 $161.03 Buy Now
KM-18718 13.000 12.813 3 $161.83 Buy Now
KM-18717 13.062 12.875 3 $166.13 Buy Now
KM-18716 13.125 12.937 3 $166.93 Buy Now
KM-18715 13.187 13.000 3 $167.73 Buy Now
KM-18714 13.250 13.062 3 $168.53 Buy Now
KM-18713 13.312 13.125 3 $169.33 Buy Now
KM-18702 13.375 13.187 3 $170.13 Buy Now
KM-18711 13.437 13.250 3 $170.93 Buy Now
KM-18720 13.500 13.312 3 $171.73 Buy Now
KM-18709 13.562 13.375 3 $172.53 Buy Now
KM-18708 13.625 13.437 3 $173.33 Buy Now
KM-18707 13.687 13.500 3 $174.13 Buy Now
KM-18706 13.750 13.562 3 $174.93 Buy Now
KM-18705 13.812 13.625 3 $175.73 Buy Now
KM-18704 13.875 13.687 3 $176.53 Buy Now
KM-18675 13.937 13.750 3 $177.33 Buy Now
KM-18719 14.000 13.812 3 $178.13 Buy Now
KM-18691 14.062 13.875 3 $178.93 Buy Now
KM-18664 14.125 13.937 3 $179.73 Buy Now
KM-18663 14.187 14.000 3 $180.53 Buy Now
KM-18662 14.250 14.062 3 $181.33 Buy Now
KM-18661 14.312 14.125 3 $182.15 Buy Now
KM-18660 14.375 14.187 3 $182.95 Buy Now
KM-18659 14.437 14.250 3 $183.75 Buy Now
KM-18658 14.500 14.312 3 $184.55 Buy Now
KM-18648 14.562 14.375 3 $185.35 Buy Now
KM-18656 14.625 14.437 3 $186.15 Buy Now
KM-18665 14.687 14.500 3 $186.95 Buy Now
KM-18654 14.750 14.562 3 $187.75 Buy Now
KM-18653 14.812 14.625 3 $188.55 Buy Now
KM-18652 14.875 14.687 3 $189.35 Buy Now
KM-18651 14.937 14.750 3 $190.15 Buy Now
KM-18650 15.000 14.812 3 $190.95 Buy Now
KM-17458 15.062 14.875 3 $191.75 Buy Now
KM-18673 15.125 14.937 3 $192.55 Buy Now
KM-18655 15.187 15.000 3 $193.35 Buy Now
KM-18657 15.250 15.062 3 $194.15 Buy Now
KM-18682 15.312 15.125 3 $194.95 Buy Now
KM-18681 15.375 15.187 3 $195.75 Buy Now
KM-18680 15.437 15.250 3 $196.55 Buy Now
KM-18679 15.500 15.312 3 $197.35 Buy Now
KM-18678 15.562 15.375 3 $198.15 Buy Now
KM-18677 15.625 14.437 3 $198.95 Buy Now
KM-18676 15.687 15.500 3 $199.75 Buy Now
KM-18666 15.750 15.562 3 $200.55 Buy Now
KM-18674 15.812 15.625 3 $201.35 Buy Now
KM-18683 15.875 15.687 3 $202.15 Buy Now
KM-18672 15.937 15.750 3 $202.95 Buy Now
KM-18671 16.031 15.812 3 $203.75 Buy Now
KM-18670 16.062 15.875 3 $204.55 Buy Now
KM-18669 16.125 15.937 3 $205.35 Buy Now
KM-18668 16.187 16.000 3 $206.15 Buy Now
KM-18667 16.250 16.062 3 $206.95 Buy Now
KM-18737 16.312 16.125 3 $207.75 Buy Now
KM-18793 16.375 16.187 3 $208.55 Buy Now
KM-18703 16.437 16.250 3 $209.35 Buy Now
KM-18773 16.500 16.312 3 $210.15 Buy Now
KM-18772 16.562 16.375 3 $210.95 Buy Now
KM-18771 16.625 16.437 3 $211.75 Buy Now
KM-18770 16.687 16.500 3 $212.55 Buy Now
KM-18769 16.750 16.562 3 $213.35 Buy Now
KM-18768 16.812 16.625 3 $214.15 Buy Now
KM-18758 16.875 16.687 3 $214.95 Buy Now
KM-18766 16.937 16.750 3 $215.78 Buy Now
KM-18775 17.000 16.812 3 $216.58 Buy Now
KM-18764 17.062 16.875 3 $217.38 Buy Now
KM-18763 17.125 16.937 3 $218.18 Buy Now
KM-18762 17.187 17.000 3 $218.98 Buy Now
KM-18761 17.250 17.062 3 $219.78 Buy Now
KM-18760 17.312 17.125 3 $220.58 Buy Now
KM-18759 17.375 17.187 3 $221.38 Buy Now
KM-18784 17.437 17.250 3 $222.18 Buy Now
KM-18786 17.500 17.312 3 $222.98 Buy Now
KM-18767 17.562 17.375 3 $223.78 Buy Now
KM-18792 17.625 17.437 3 $224.58 Buy Now
KM-18791 17.687 17.500 3 $225.38 Buy Now
KM-18790 17.750 17.562 3 $226.18 Buy Now
KM-18789 17.812 17.625 3 $226.98 Buy Now
KM-18788 17.875 17.687 3 $227.78 Buy Now
KM-18787 17.937 17.750 3 $228.58 Buy Now
KM-18776 18.000 17.812 3 $229.38 Buy Now
KM-18785 18.062 17.875 3 $230.18 Buy Now
KM-18794 18.125 17.937 3 $230.98 Buy Now
KM-18783 18.187 18.000 3 $231.78 Buy Now
KM-18782 18.250 18.062 3 $232.58 Buy Now
KM-18781 18.312 18.125 3 $233.38 Buy Now
KM-18780 18.375 18.187 3 $234.18 Buy Now
KM-18779 18.437 18.250 3 $234.98 Buy Now
KM-18774 18.500 18.312 3 $235.78 Buy Now
KM-18777 18.562 18.375 3 $236.58 Buy Now
KM-18823 18.625 18.437 3 $237.38 Buy Now
KM-18728 18.687 18.500 3 $238.18 Buy Now
KM-18765 18.750 18.563 3 $238.98 Buy Now
KM-18736 18.812 18.625 3 $239.78 Buy Now
KM-18735 18.875 19.687 3 $240.58 Buy Now
KM-18734 18.937 18.750 3 $241.38 Buy Now
KM-18733 19.000 18.812 3 $242.18 Buy Now
KM-18732 19.062 18.875 3 $242.98 Buy Now
KM-18731 19.125 18.937 3 $243.78 Buy Now
KM-18721 19.187 19.000 3 $244.58 Buy Now
KM-18576 19.250 19.062 3 $245.38 Buy Now
KM-18575 19.312 19.125 3 $246.18 Buy Now
KM-18600 19.375 19.187 3 $246.98 Buy Now
KM-18602 19.437 19.250 3 $247.78 Buy Now
KM-18583 19.500 19.312 3 $248.60 Buy Now
KM-18608 19.562 19.375 3 $249.40 Buy Now
KM-18607 19.625 19.437 3 $250.20 Buy Now
KM-18606 19.687 19.500 3 $251.00 Buy Now
KM-18605 19.750 19.562 3 $251.80 Buy Now
KM-18729 19.812 19.625 3 $252.60 Buy Now
KM-18738 19.875 19.687 3 $253.40 Buy Now
KM-18727 19.937 19.750 3 $254.20 Buy Now
KM-18726 20.000 19.812 3 $255.00 Buy Now



nominal inches,
diameter

plus or minus (±) tolerance, inches

ID inside diameter

OD outside diameter

steel
mandrel

built-up
mandrel

.125" -.749"

.003"

-

.005"

.750" - 1.999"

.004"

-

.005"

2.000" - 4.000"

.006"

-

.008"



*turned

*as wound

4.001" - 12.000"

.010"

-

.025"

plus only

12.001" - 18.000"

.030"

.060"

.030"

plus only

18.001" - 24.000"

.040"

.075"

.035"

plus only

24.001" - 48.000"

.060"

.090"

.040"

plus only

*Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request)
