316L (Stainless Steel Balls)

316 Stainless Steel Balls

316L Stainless Steel Balls
Stock # Grade # Diameter Pkg Qty.  Price/Pkg
KB-1637 100 .125" 100 $36.05
KB-674 100 .125" 35,000 $2,430.75
KB-664 200 .125" 35,000 $2,381.75
KB-654 500 .125" 35,000 $2,334.50
KB-666 1000 .125" 35,000 $2,287.25
KB-1638 100 .156" 100 $42.45
KB-667 100 .156" 15,000 $1,713.75
KB-668 200 .156" 15,000 $1,680.00
KB-669 500 .156" 15,000 $1,646.25
KB-670 1000 .156" 15,000 $1,613.25
KB-1639 100 .187" 100 $55.40
KB-671 100 .187" 10,000 $1,298.50
KB-672 200 .187" 10,000 $1,272.00
KB-644 500 .187" 10,000 $1,247.00
KB-665 1000 .187" 10,000 $1,221.50
KB-1640 100 .218" 100 $66.55
KB-663 100 .218" 6,400 $1,149.12
KB-635 200 .218" 6,400 $1,126.08
KB-636 500 .218" 6,400 $1,103.36
KB-637 1000 .218" 6,400 $1,081.28
KB-1651 100 .250" 100 $78.90
KB-638 100 .250" 4,350 $1,354.59
KB-639 200 .250" 4,350 $1,332.84
KB-640 500 .250" 4,350 $1,306.09
KB-641 1000 .250" 4,350 $1,279.99
KB-1642 100 .312" 50 $77.15
KB-653 100 .312" 2,200 $761.20
KB-643 200 .312" 2,200 $747.01
KB-634 500 .312" 2,200 $732.05
KB-645 1000 .312" 2,200 $717.42
KB-1633 100 .375" 25 $69.45
KB-646 100 .375" 1,300 $881.40
KB-647 200 .375" 1,300 $859.95
KB-648 500 .375" 1,300 $842.73
KB-649 1000 .375" 1,300 $825.89
KB-1644 100 .437" 25 $70.55
KB-650 100 .437" 810 $892.42
KB-651 200 .437" 810 $874.60
KB-652 500 .437" 810 $857.10
KB-676 1000 .437" 810 $839.93
KB-1645 100 .500" 10 $51.20
KB-707 100 .500" 550 $814.00
KB-673 200 .500" 550 $800.42
KB-698 500 .500" 550 $784.41
KB-699 1000 .500" 550 $768.71
KB-1646 100 .750" 5 $78.05

AISI type 316L stainless steel balls meet requirements for an unhardened ball with excellent toughness and resistance to corrosion. Corrosion resistance may be increased through annealing. Both non-annealed and annealed balls are widely used in valves and related equipment.

Type 316L is a low carbon austenitic, chromium-nickel-molybdenum stainless steel with general corrosion resistance similar to type 316, but with superior resistance to intergranular corrosion following welding or stress relieving.

It is suggested for use in certain corrosive environments for parts that are fabricated by welding and cannot be subsequently annealed. Parts made from 316L are generally limited to service temperatures up to 800ºF (425ºC).

Click here for sizes and pricing

316L Stainless Steel Balls:  Available Grades and Sizes

Grade

Size Range in Inches and Millimeters

100 - 200 - 1000

1/8 - 2                                3.175 - 50.800

Balls Pound

Size

Balls Pound

Inches

Millimeters

1/8

3.175

3,420

5/32

3.968

1,750

3/16

4.762

1,010

7/32

5.556

638

1/4

6.350

427

9/32

7.143

300

5/16

7.9.7

219

11/32

8.731

164

3/8

9.525

127

13/32

10.318

99.6

7/16

11.112

79.7

15/32

11.906

64.8

1/2

12.700

53.4

17/32

13.493

44.5

9/16

14.287

37.5

19/32

15.081

31.9

5/8

15.875

27.4

21/32

16.668

23.6

11/16

17.462

20.6

23/32

18.256

18.0

3/4

19.050

15.8

25/32

19.843

14.0

13/16

20.637

12.5

27/32

21.431

11.1

Balls Pound

Size

Balls Pound

Inches

Millimeters

7/8

22.225

9.97

29/32

23.018

8.97

15/16

23.812

8.10

31/32

24.606

7.35

1

25.400

6.68

1 1/8

28.575

4.69

1 1/4

31.750

3.42

1 3/8

34.925

2.57

1 1/2

38.100

1.98

1 5/8

41.275

1.56

1 3/4

44.450

1.26

1 7/8

47.625

1.02

2

50.800

.844

Material Analysis:
All sizes and grades are of the highest quality and in accordance with AISI type 316L. Passivation to ASTM A380 is available upon request..

Material

AISI

Federal

Military

ASTM

UNS

AMS

Stainless Steel Type 316L

316

QQ-S-763

-

A-493

S-31603

-

Chemical Analysis

Carbon................................................................

0.03% maximum

Chromium...........................................................

16.0% to 18.0%

Manganese.........................................................

2.0% maximum

Silicon..................................................................

1.0% maximum

Nickel

10.0% to 14.0%

Phosphorus.........................................................

0.045% maximum

Sulphur................................................................

0.03% maximum

Mechanical Properties
Hardness as measured on parallel flat surfaces is Rockwell “C” 25-39.

Tensile Strength..................................................

80,000 to 120,000 psi

Elongation in two inches....................................

10.0% to 15.0%

Reduction in area................................................

55.0% to 65.0%

Modulus of elasticity...........................................

28,000,000 psi

Density.................................................................

0.29 lbs./cu. in
